YSi-V_KLT_pl - 第42页
24 5 26 17 25 28 27 24 8 18 12 15 7 6 9 2 23 1 3 21 11 4 22 20 19 16 19 14 10 15 13 24 5 26 17 25 28 27 24 8 18 12 15 7 6 9 2 23 1 3 21 11 4 22 20 19 16 19 14 10 15 13 T ype HS (7μm) 3D Projecter KL T-1707 9-3 NO Parts_N…
9
5
12
17
25
24
23
22
14
16
6
15
7
20
11
8
3
21
18
13
10
9
19
7
7
2
4
11
2
1
9
5
12
17
25
24
23
22
14
16
6
15
7
20
11
8
3
21
18
13
10
9
19
7
7
2
4
11
2
1
3D Projecter (5M)
3D Projecter
KLT-1506
9-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90115-02J006
BOLT, HEX. SOCKET HEAD
12
2
90166-02J204
SCREW, PAN HEAD
24
3
90169-02J205
SCREW, BINDING HEAD
8
4
90171-02J026
WASHER,PLAIN
12
5
90990-01J039
BOLT HEX,SOCKET HEAD
8
6
90990-01J044
BOLT HEX,SOCKET HEAD
16
7
91312-03006
BOLT HEX,SOCKET HEAD
16
8
91312-04005
BOLT HEX,SOCKET HEAD
4
9
92902-03200
WASHER,PLAIN
8
10
KLT-M45DG-00
3D CTRL BOARD ASSY
4
11
KLT-M45DJ-00
3D FLEXIBLE BRD ASSY
4
12
KLT-M45DL-00
3D LED BOARD ASSY
4
13
KLT-M66JE-00
HNS,3D LED
4
14
KLT-M7316-00
HOOD,LENS 17
1
15
KLT-M7F01-10
UNIT,PROJECTOR
4
16
KLT-M7F30-00
BRKT.,PROJECTOR
4
17
KLT-M7F31-00
BRACKET,P.C.B.
4
18
KLT-M7F32-00
COVER,PROJECTOR
4
19
KLT-M7F33-00
HEAT SINK
4
20
92902-03600
WASHER,PLAIN
8
21
92902-04200
WASHER,PLAIN
4
22
KLT-M7FR1-E0
3D SUB ASSY.
1
23
KLT-M7FR1-N0
3D SUB ASSY.
1
24
KLT-M7FR1-S0
3D SUB ASSY.
1
25
KLT-M7FR1-W0
3D SUB ASSY.
1
24
5
26
17
25
28
27
24
8
18
12
15
7
6
9
2
23
1
3
21
11
4
22
20
19
16
19
14
10
15
13
24
5
26
17
25
28
27
24
8
18
12
15
7
6
9
2
23
1
3
21
11
4
22
20
19
16
19
14
10
15
13
Type HS (7μm)
3D Projecter
KLT-1707
9-3
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLT-M451H-10
0.45 WXGA DMD
4
2
KLT-M45DL-02
3D LED BOARD ASSY
4
3
KLT-M45EG-03
3D H.CTRL BOARD ASSY
4
4
KLT-M45EJ-02
3D H.FLEXIBLE BRD ASSY
4
5
KLT-M731B-00
HOOD,LENS 20
4
6
KLT-M7F33-01
HEAT SINK
4
7
KLT-M7FB1-00
UNIT,PROJECTOR
4
8
KLT-M7FA2-00
PLATE,PROJECTOR
4
9
KLT-M7FA3-01
BRACKET,PROJECTOR
4
10
KLT-M7FA5-00
PLATE,SPRING
4
11
KLT-M7FB4-00
COVER,PROJECTOR
4
12
90115-02J006
BOLT, HEX. SOCKET HEAD
12
13
90166-02J203
SCREW, PAN HEAD
8
14
90166-02J206
SCREW, PAN HEAD
8
15
90171-02J026
WASHER,PLAIN
20
16
90K41-001320
LABEL,CAUTION
4
17
91312-03010
BOLT HEX,SOCKET HEAD
12
18
91312-03012
BOLT HEX,SOCKET HEAD
16
19
92012-03006
BOLT BUTTON HEAD
24
20
92902-03100
WASHER SPRING
16
21
92902-03600
WASHER,PLAIN
16
22
98902-03004
SCREW BINDING HEAD
8
23
98902-03006
SCREW BINDING HEAD
16
24
99480-03008
PIN,PARALLEL
16
25
KLT-M7FBS-N0
3D SUB ASSY.
1
26
KLT-M7FBS-S0
3D SUB ASSY.
1
27
KLT-M7FBS-E0
3D SUB ASSY.
1
28
KLT-M7FBS-W0
3D SUB ASSY.
1
12
11
10
9,13
8
7
4
1
2
3
1
5
5
5
6
12
11
10
9,13
8
7
4
1
2
3
1
5
5
5
Controller
Controller
KLT-1509
10-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLA-M5840-22
SERVO BOARD ASSY
2
1-1
KLA-M5840-24
SERVO BOARD ASSY
2
OK
MLX0160-2015/3/13
1-2
KLA-M5840-26
SERVO BOARD ASSY
2
OK
MM70194-2015/8/3
2
KLA-M4510-01
MOTHER BOARD ASSY
1
3
KLA-M5880-02
D.POWER UNIT ASSY
1
4
97602-03308
SCREW PAN HEAD W/WASHER
9
5
97602-04308
SCREW PAN HEAD W/WASHER
8
6
KLT-M4209-00
SYSTEM UNIT ASSY
1
6-1
KLT-M4209-01
SYSTEM UNIT ASSY
1
OK
MM20248-2015/3/5
7
KLT-M4299-10
LAN CARD ASSY
1
8
KLB-M4530-31
REMOTE IF BOARD ASSY
1
9
KLT-M441H-00
VISION BOARD ASSY
1
STD
10
KLT-M53J1-00
HDD UNIT
1
11
KLT-M65E5-00
ATX POWER SUPPLY
1
12
KLT-M53A9-00
MEDIA FILTER
1
13
KLT-M441S-00
OPT.PC BOARD ASSY
1
5M
