0003-003 2-2 ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨ PART No. PART NAME REMARKS CT-1252S,L,PS,PL CT-1260S,L CT-1261S,L CT-1280S,L,PS,PL CT-1281S,L,PS,PL CT-1252TS,TL,HS,HL CT-1260TS,TL CT-1261TS,TL CT-1280TS,TL,HS,HL CT-1281TS,TL,HS,HL 30 411 08…
0108-004
2-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨
PART No. PART NAME REMARKS
CT-1252S,L,PS,PL
CT-1260S,L
CT-1261S,L
CT-1280S,L,PS,PL
CT-1281S,L,PS,PL
CT-1252TS,TL,HS,HL
CT-1260TS,TL
CT-1261TS,TL
CT-1280TS,TL,HS,HL
CT-1281TS,TL,HS,HL
2 630 039 4115 LEVER(LOCATE NOTCH) 1 1 1 1 671G--01B-021
2 630 061 0598 LEVER(LOCATE NOTCH) 1 1 1 1 671H--01B-021
3 630 037 0218 PIN,LOCATE 1111 1111 671G--01B-024
4 411 141 3902 WASHER V 3X7X0.5 1111 1111 FW3
5 411 141 2806 WASHER SPR 3 1111 1111 SW3
6 411 140 9905 NUT HEX 3 1111 1111 M3
7 411 152 7906 SCR TRS 3X12 1111 1111 671G--01H-008
8 630 039 5167 SPRING,TENSION 1111 1111 671G--01B-023
9 -1 411 141 3902 WASHER V 3X7X0.5 1111 1111 FW3
9 -2 411 141 2806 WASHER SPR 3 1111 1111 SW3
9 -3 411 140 9905 NUT HEX 3 1111 1111 M3
11 630 037 0256 PIN,GUIDE 1111 1111 671G--01B-027
12 411 141 3902 WASHER V 3X7X0.5 1 1 1 1 1 1 1 1 FW3
13 411 141 2806 WASHER SPR 3 1 1 1 1 1 1 1 1 SW3
14 411 140 9905 NUT HEX3 1 1 1 1 1 1 1 1 M3
16 630 050 7034 LEVER(ASSY SHUTTER) 1 1 1 1 1 1 1 1
16 -1 630 050 7201 LEVER(ASSY LOCATE NOTCH) 1 1
17 630 039 4146 PIN,LOCATE 1 1 1 1 1 1 1 1 671G--01B-026
17 -1 630 037 0898 PIN,LOCATE 1 1 582J--01B-024
18 411 141 3902 WASHER V 3X7X0.5 1111111111 FW3
19 411 141 2806 WASHER SPR 3 1111111111 SW3
20 411 140 9905 NUT HEX 3 1111111111 M3
21 411 152 8101 SCR TRS 3X6 1111111111 671G--01H-007
22 630 037 0386 SPRING,TENSION 1 1 1 1 671G--01B-040
22 630 041 0778 SPRING, TENSION 1 1 1 1 671H--01B-040
22 630 037 0881 SPRING, TENSION 1 1 582J--01B-023
26 630 050 7003 SPROCKET(ASSY SPROCKET) 1 1 1 1
26 630 061 2066 SPROCKET(SPROCKET ASSY) 1 1 1 1
26 630 050 7126 SPROCKET(ASSY SPROCKET) 1 1
27 630 077 6904 LEVER(SWING PLATE ASSY) 1 1
27
630 060 6003 LEVER(SWING PLATE ASSY) 1 1
27
-1
630 077 6928 LEVER(SWING PLATE ASSY) 1 1
27
-1
630 060 6041 LEVER(SWING PLATE ASSY) 1 1
27
-1
630 050 7133 LEVER(ASSY SWING PLATE) 1 1
28
630 010 6015 COLLAR 1111111111 671G--01B-012
29 630 039 3040 LEVER(RATCHET CLICK) 1111111111 671G--01B-019
ᵈᗧ
NOTE
ᢙ㊂
Q'ty
⇟
ภ
Key No.
0003-003
2-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨
PART No. PART NAME REMARKS
CT-1252S,L,PS,PL
CT-1260S,L
CT-1261S,L
CT-1280S,L,PS,PL
CT-1281S,L,PS,PL
CT-1252TS,TL,HS,HL
CT-1260TS,TL
CT-1261TS,TL
CT-1280TS,TL,HS,HL
CT-1281TS,TL,HS,HL
30 411 088 9005 WASHER F 3X6X0.5 1111111111 FWS3 F
31 411 000 9304 RING E 2 1111111111 671G--01H-011
32 630 039 3033 SPRING,TORSION 1111111111 671G--01B-018
33 630 037 0379 PIN,LOCATE 1111111111 671G--01B-038
34 411 141 4008 WASHER V 4X9X0.8 1111111111 FW4
35 411 141 2905 WASHER SPR 4 1111111111 SW4
36 411 141 0307 NUT HEX 4 1111111111 M4
37 630 061 1762 PIN,GUIDE 1111 1111 671G--01B-020
37 630 037 0140 PIN,GUIDE 1 1 582J--01B-020
38 411 141 4008 WASHER V 4X9X0.8 1111111111 FW4
39 411 141 2905 WASHER SPR 4 1111111111 SW4
40 411 141 0307 NUT HEX 4 1111111111 M4
46 630 060 5976 LEVER(SUPPRESSOR ASSY) 1 1 1 1
46 630 060 6027 LEVER(SUPPRESSOR ASSY) 1 1 1 1
46 630 050 7164 LEVER(ASSY SUPPRESSOR) 1 1
47 630 040 7464 LEVER 1111111111 671G--01B-031
48 630 040 6986 SPRING,TORSION 1111111111 671G--01B-057
49 630 039 4153 HOOK 1111111111 671G--01B-032
50 411 152 8101 SCR TRS 3X6 1111111111 671G--01H-007
51 630 037 0348 PIN,LOCATE 1111111111 671G--01B-037
52 411 108 7103 SCR FLT 3X10 1111 1111 M3X10 FLT
52 630 037 5688 BOLT(FLT HEX-SCT) 1 1 582J--01H-015
55 630 039 3835 SPRING,FLAT 2121221212 671G--01B-066
56 630 050 7072 HOOK(ASSY HOOK) 1111111111
57 411 141 3902 WASHER V 3X7X0.5 2222222222 FW3
58 411 141 2806 WASHER SPR 3 2222222222 SW3
59 630 000 7503 BOLT,HEX-SCT 2222222222 M3X6
63
411 119 1909 WASHER V 3X7X0.5 1111111111 FW3 F
64
411 086 4408 WSHER SPR 3 1111111111 SW3 F
65
630 037 0690 PIN,GUIDE 1111111111 671G--01B-086
66
630 039 3224 PIN,GUIDE 1111111111 671G--01B-052
67 411 141 4008 WASHER V 4X9X0.8 1111111111 FW4
ᵈᗧ
NOTE
ᢙ㊂
Q'ty
⇟
ภ
Key No.
0108-004
2-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨
PART No. PART NAME REMARKS
CT-1252S,L,PS,PL
CT-1260S,L
CT-1261S,L
CT-1280S,L,PS,PL
CT-1281S,L,PS,PL
CT-1252TS,TL,HS,HL
CT-1260TS,TL
CT-1261TS,TL
CT-1280TS,TL,HS,HL
CT-1281TS,TL,HS,HL
68 411 141 2905 WASHER SPR 4 1111111111 SW4
69 630 000 7602 BOLT,HEX-SCT 1111111111 M4X6
71 630 060 5990 LEVER(SWING ARM ASSY) 1 1 1 1
71 630 060 6034 LEVER(SWING ARM ASSY) 1 1 1 1
71 630 050 7140 LEVER(ASSY SWING ARM) 1 1
71 -1 630 066 4034 ROLLER 1111 1111 671G--01B-113
71 -2 411 000 9304 RING E 2 1111 1111 671G--01H-011
72 630 068 9822 PIN,LOCATE 1111 1111 671G--01B-015
72 630 040 8911 PIN,LOCATE 1 1 582J--01B-015
72 -1 630 066 4010 ROLLER 1111 1111 671G--01B-114
72 -2 630 068 9815 PIN,GUIDE 1 1 1 1 1 1 1 1 671G--01B-115
73 411 035 2707 SCR FLT 4X8 1 1 1 1 1 1 1 1 M4X8 FLT
73 630 036 0967 BOLT(FLT HEX-SCT) 1 1 582J--01H-004
74 630 051 8245 PIN,GUIDE 1 1 1 1 671G--01B-109
75 411 144 3107 SCR FLT 3X5 1 1 1 1 671G--01H-014
76 630 075 4278 PIN,LOCATE 1 1 725G--01B-011
76 630 060 3651 PIN,LOCATE 1 1 671G--01B-011
76 -1 411 141 3902
WASHER V 3X7X0.5
11 11
FW3
76 -2 411 141 2806
WASHER SPR 3
11 11
SW3
76 -3 411 140 9905
NUT HEX 3
11 11
M3
77 -1 630 075 4285 PIN,LOCATE 1 1 725H--01B-011
77 -1 630 060 3620 PIN,LOCATE 1 1 671H--01B-011
77 -1 630 041 1133 PIN,LOCATE 1 1 582J--01B-011
78 -1 630 051 8245 PIN,GUIDE 1 1 1 1 671H--01B-109
78 -1 630 037 0935 SHAFT 1 1 582J--01B-090
80 630 037 0706 COLLAR 1111111111 671G--01B-087
81 630 060 5983 LEVER(LINK ASSY) 1 1 1 1 1 1 1 1
81 630 050 7089 LEVER(ASSY LEVER) 1 1
82 630 037 0713 PIN,LOCATE 1111111111 671G--01B-088
83 411 144 3107 SCR FLT 3X5 1 1 1 1 1 1 1 1 671G--01H-014
83 630 037 5671 PIN,LOCATE 1 1 582J--01H-014
91
630 060 6010 LEVER(LEVER ASSY) 1 1 1 1 1 1 1 1
91
630 050 7065 LEVER(ASSY RATCHET ARM) 1 1
ᵈᗧ
NOTE
ᢙ㊂
Q'ty
⇟
ภ
Key No.
