4  Automatic nozzle changers for both changeover and storage of nozzles.  PCB Barcode Reader used for product controlled production changeover.  Component Bar Code Scanner used for feeder set-up verification.  XXXCer…

Machine Description

Technical Data

Type of placement head 12-Nozzle Collect & Place Head

Number of gantries 4

Benchmark placement rate

60,000 cph

Component Range 0.6 x 0.3 mm

(0201) to 18.7 x 18.7 mm

Max. placement accuracy (at 4 σ)

80/75 µm

PCB dimensions (L x W)

Single conveyor

Dual conveyor

Dual conveyor in

single conveyor mode

50 x 50 mm

to 368 x 460 mm

2" x 2" to 14.5" x 18";

LBO

: 50 x 110 mm

to 610 x 460 mm

width up to 508 mm on request.

50 x 50 mm

to 368 x 216 mm

2" x 2" to 14.5" x 8.5";

LBO

: 50 x 110 mm

to 610 x 216 mm

width up to 242 mm on request.

50 x 50 mm

to 368 x 380 mm

2" x 2" to 14.5" x 15";

LBO

: 50 x 110 mm

to 610 x 380 mm

width up to 430 mm on request.

Feeding capacity 144 tracks, 8 mm tape

Component table Quick changeover table with integrated

wheels, reel holder and scrap bin

Types of Feeder modules Tapes, Bulk Cases, Surf Tape feeders,

application-specific OEM feeders

Operating system Microsoft Windows / RMOS

Power 4 kW

Compr. air requirements 6.5 - 10 bar, 950 Nl/min, tube ¾"

Vacuum pump (Option) 6 - 10 bar, 400 Nl/min, tube ¾"

a) As defined in Scope of Service and Delivery SIPLACE.

b) Long Board Option.

Description

The SIPLACE HS-60 SMD place-

ment system combines very high

placement speed with both accu-

racy and flexibility.

SIPLACE HS-60 machines are

equipped with four X-Y-main gan-

tries. Each gantry features a star-

shaped

12-Nozzle Collect & Place Head. The

placement heads alternately pick up

components from a stationary feeder

bank and place these components

on the stationary PCB.

Due to the efficient heads as well as

the high acceleration the benchmark

placement rate of 60,000 cph of the

SIPLACE HS-60 is uncompared.

The SIPLACE HS-60 funds upon the

modular SIPLACE platform and thus

shows distinct advantages:

 Component tapes of all sizes

can be replenished by splicing a

new reel of components to the

end of a depleting reel. This eli-

minates machine stoppage due

to component replenishment.

 Stationary, vibration-free feed-

ers ensure a reliable pick-up of

even the smallest components

(e.g., 0201 chips).

 Thanks to the Collect & Place

principle the path can be mini-

mized and the sequence of

placement optimally adjusted.

 With the linear drive SIPLACE

HS-60 reaches an impressive

placement accuracy and lowest

dpm rates.

Speed coupled with economic ef-

ficiency and set-up reliability is the

SIPLACE HS-60´s recipe for suc-

cess. Components are pre-picked

as the PCB is transported into the

placement area. The placement

sequence is optimized for speed:

While one Collect & Place Head is

placing components, the second

head is picking up the next series

of components to be placed.

Among others, the following

options are available for the

SIPLACE HS-60:

 Additional changeover tables

enables the reduction of job

set-up time increasing machine

utilisation.

 Dual Conveyor eliminates the

non-productive PCB loading

times thus increasing machines

operating efficiency.

 Automatic nozzle changers for

both changeover and storage of

nozzles.

 PCB Barcode Reader used for

product controlled production

changeover.

 Component Bar Code Scanner

used for feeder set-up verification.

 XXXCeramic Substrat Centering.

 Component sensor.

Line Design

Description

Flexibility and adaptability charac-

terize the modular SIPLACE de-

sign. Each production line can be

individually composed of similar

and different modules.

Because of the small size and ro-

bust construction of the SIPLACE

modules, they can be recombined

quickly and easily to accommodate

changes in production requirements.

The SIPLACE family of placement

machines offers the right product

for each purpose – from the very

high-speed placement system

SIPLACE HS-60 to the high-speed

SMD placement system SIPLACE

S-27 HM and the flexible place-

ment systems SIPLACE F

and SIPLACE HF.

SIPLACE line-level optimization

tools generate single set-ups for

single products or for several

products as well as several set-

ups for several products. Also,

product programs can be trans-

ferred from line to line even when

the machine configurations are dif-

ferent.

The innovative SIPLACE SMT

platform guarantees maximum

productivity. The fully modular

concept allows quick adjustment

and optimization to new produc-

tions. With SIPLACE you benefit

from a global service network.

Magazine

Loader

Reflow Oven

SIPLACE S-27 HM

SIPLACE HS-60

Bare

Board

Loader

Screen Printer

Example of a SIPLACE Placement Line
