39
Standard List
The following functions are included with the SIPLACE D2i as standard at no additional cost:
SIPLACE D2i standard features
Vacuum sensor X
Force sensor X
Fiducial & ink spot recognition X
Set of standard nozzles per head X
Service box X
Single conveyor, stationary side right X
Single conveyor, stationary side left X
Wide board configuration X
Buffer function X
PCB stopper laser light barrier X
Operation on both sides X
LCD monitors X
Touch-screen monitor X
Indicator lamp X
Tape cutter with reject bin X
Tape separating plates X
Magnetic pin support X
40
List of Options
SIPLACE D2i options
Transport height (900, 930, 950) X
Flexible dual conveyor, fixed side right X
Flexible dual conveyor, fixed side left X
SMEMA-Siemens adapter box X
PCB alignment, single conveyor X
PCB alignment, flexible dual conveyor X
Long board option for single conveyor X
Long board option for flexible dual conveyor X
1D PCB barcode scanner X Restrictions for a PCB longer than 430 mm
2D PCB barcode scanner X Restrictions for a PCB longer than 430 mm
Head reconfiguration kits X
SIPLACE 12-nozzle Collect&Place head X
High-resolution camera, type 30 X
Component sensor C& P12 X
01005 package X
0201 package X
SIPLACE 6-nozzle Collect&Place head X
Nozzle changer (according to the head) X
SIPLACE component changeover table X
Dip module X
External power supply for the component change-
over table
X
Compressed air distributor for bulk case feeder
modules
X
Second level reel holder X
Feeder module cover flap X
Feeder module fixing X
Splice detection X
Setup Center X
110/208 V conversion kit X
Vacuum pump X
Productivity lift X Max. PCB width: single track 460 mm
double track 216 mm
Max. CO height: 17 mm on the under-
floor section
41
List of Languages
Other language available upon request
Documentation
packages
SIPLACE
Pro 10
SIPLACE
OIS 10
Station software
605.03 SP2
German X X X X
English X X X X
French X X X X
Italian X X X X
Spanish X
a
a) On request
XX X
Portuguese X
a
XX X
Hungarian X X X X
Czech X
a
X
a
X
a
X
Russian X
a
X
a
X
a
X
a
Turkish – X
a
X
a
–
Polish X
a
X
a
X
a
X
Estonian X
a
X
a
X
a
X
Finnish X
a
–– –
Swedish X – – –
Danish X – – –
Dutch X
a
–– –
Korean X X X X
Simplified Chinese X X X X
Japanese X X X X
