SP28P-DH - 第173页
番号 品番 ランク 備考 NO PART NUMBER RANK REMARKS 1 01PFA 2 01QQA 3 01JQB 4 01JVB 5 01JXA 6 01K1B 7 01KFB 8 01KGB 9 00ALA 10 11 086RA 12 13 14 15 16 01KLB 17 01N8A 18 01NAA 19 01NCB 20 01NGB 21 01P3B 22 01NMB 23 01NLB 24 01NJB 25…
0 1 Q Q A
DANGER
PRESS
MACHINE
0 1 P F A
DANGER
PRESS
MACHINE
0 1 J X A
DANGER
DO NOT TOUCH
ACTIVE PART
WHEN
OPERATING
You will have serious
injury if you touch the
active part.
0 1 J Q B
DANGER
WATCH YOUR
HANDS
Caught hands between
right feeder and left
feeder tables will have
serious injury.
0 1 J V B
DANGER
ROTATIONAL
ACTIVE PART
INSIDE
You will have serious
injury if you open the
cover and touch the
active part inside.
21
22
23
24
25
0 1 P 6 A
WARNING
MAGAZINE LIFT
MOVING UP AND
DOWN
You will have serious
injury if you touch
moving magazine lift.
0 1 P 3 B
WARNING
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
burn by high
temperature part inside.
0 1 N M B
WARNING
WORKER
OPERATING
IN THE BACK
Make sure that no
worker is in the back
when machine
starting.
0 1 N L B
WARNING
WORKER
OPERATING
IN THE FRONT
Make sure that no
worker is in the front
when machine
starting.
0 1 N J B
WARNING
MACHINE
FALLING DOWN
Machine will fall down
if you slant machine
more than 15 degrees
in machine installation
or removal.
16 17
18
19
20
0 1 N 8 A
WARNING
WATCH YOUR
HANDS OR
FINGERS
You will have serious
injury if you touch
active part.
0 1 N A A
WARNING
OUTBREAK OF
FIRE
Keep away
inflammables from
heat sources.
0 1 K L B
WARNING
DO NOT TURN
OFF Z-AXIS
SERVO SWITCH
Head will be broken and
you will be injured when
the machine is operated
with Z-axis servo switch
turned off.
0 1 N C B
WARNING
ELECTRIC
SHOCK
You will have serious
electric shock if you
touch electric active
part inside.
0 1 N G B
WARNING
HIGH VOLTAGE
You will have serious
electric shock if you
touch electric power
supply inside.
11
0 0 A L A
ELECTRIC
SHOCK
You will have serious
burn or injury if you
touch the torch rod
part.
DANGER
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
0 1 K F B
DANGER
HOT SURFACE
You will have serious
burn if you touch the
hot surface.
0 1 K G B
DANGER
NITROGEN GAS
You will be in lack of
oxygen when operating.
Keep on ventilation
when operating.
6
7
8 9
1
2
3 4
5
DANGER
DON'T TOUCH THIS PART
WHEN OPERATING
0 8 6 R A
番号 品番 ランク 備考
NO
PART NUMBER
RANK
REMARKS
1 01PFA
2 01QQA
3 01JQB
4 01JVB
5 01JXA
6 01K1B
7 01KFB
8 01KGB
9 00ALA
10
11 086RA
12
13
14
15
16 01KLB
17 01N8A
18 01NAA
19 01NCB
20 01NGB
21 01P3B
22 01NMB
23 01NLB
24 01NJB
25 01P6A
- 6 - (02-0002)
パーツリスト
PART LIST
MO機番
MODULE NUMBER
ユニット名称
UNIT NAME
10HAC0M0000
警告表示ラベル
Safety indication label
ユニットNo.
UNIT NUMBER
2-A
数量
Q'TY
LABEL
LABEL
1
部品名
PART NAME
型式
TYPE
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
LABEL
01PFA (DA) English type
01QQA (DA) English type
01JQB (DA) English type
01JVB (DA) English type
01JXA (DA) English type
01K1B (DA) English type
01KFB (DA) English type
01KGB (DA) English type
00ALA (DA) English type
086RA (DA) English type
01KLB (DA) English type
01N8A (DA) English type
01NAA (DA) English type
01NCB (DA) English type
01NGB (DA) English type
01P3B (DA) English type
01NMB (DA) English type
01NLB (DA) English type
01NJB (DA) English type
01P6A (DA) English type
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
SPEED
CONTROLLER
DO NOT
ADJUST
0 1 P E A
0 7 R 3 A
CAUTION
IPA
USE ONLY
The corrosion damage
to the hose may cause
the machine to catch
fire.
31
32
33
34
26
27 28
30
WARNING
HOLD THE COVER
WITH THE BAR
WHILE OPEN
Otherwise the cover
may shut and you may
sustain serious injuries.
0 6 0 T A
BAR
0 1 N 6 B
WARNING
MAGAZINE
MOVING
UP AND DOWN,
RIGHT AND LEFT
You will have serious
injury if you touch
moving magazine.
0 1 P 9 B
WARNING
DO NOT DISABLE
SAFETY SENSOR
You will have serious
injury by active part
if you disable safety
sensor.
0 8 F 1 A
NO OPEN
FLAME
Solvent may catch
fire.
Keep away from fire.
WARNING
DANGER
HOT
SURFACE
0 7 S E A
0 9 F N A
WARNING
DO NOT DISABLE SAFETY
SENSOR
You will have serious injury by active part
if you disable safety sensor.
0 9 C E A
DANGER
PULL OUT THE POWER
KEY OF MOUNTER FOR
MAINTAINING THE BACK
SIDE OF MACHINE
Otherwise, you may be
caught in the feeder
table of mounter and
injured.
0 9 C J A
DANGER
PULL OUT THE POWER
KEY OF MOUNTER FOR
MAINTAINING THE
BACK SIDE OF BOND
DISPENSER
Otherwise, you may be
caught in the feeder
table of machine and
injured.
0 9 C N A
DANGER
TURN OFF THE MAIN
BREAKER OF MOUNTER
FOR MAINTAINING THE
BACK SIDE OF MACHINE
Otherwise, you may be
caught in the feeder
table of mounter and
injured.
35
36
37
38
39 40
41
42
0 9 0 Z A
CAUTION
ONLY USE
RECOMMENDED
CLEANING
SOLVENT
Use of other cleaning
solvents may corrode
the hose, resulting in
causing the machine to
catch fire.
0 9 8 3 A
WARNING
WATCH YOUR
HANDS
Caught hands between
board holder and this
cover will have serious
injury.
0 9 C S A
DANGER
TURN OFF THE MAIN
BREAKER OF MOUNTER
FOR MAINTAINING THE
BACK SIDE OF BOND
DISPENSER
Otherwise, you may be
caught in the feeder
table of machine and
injured.
0 A 5 F B
WARNING
TAKE CARE NOT
TO TOUCH CUTTER
You will have serious
injury if you touch
cutter.
43
0 D P 3 A
TURN OFF THE POWER AND
AIR BEFORE TOUCHING
THE CUTTER AREA DURING
MAINTENANCE
You may potentially
be injured by the
cutter area if the
machine is actuated.
WARNING
0 C Z T A
WARNING
AVOID LOOKING
INSIDE THE
OPENING FOR
UNLOADING
You may potentially
be injured if an
unloaded board hits
your eyes.
0 B 3 7 A
You will have serious
burn if you touch the
hot surface.
HOT SURFACE
WARNING
44
45
46
47
