11 WF3 JTF-ML2 Maintenance Switch on machine and return the tables 6 min 1 / 1
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status ON Conveyor Empty
NOTICE! ESD guidelines are to be followed Tool: Wear Part: Consumables:
www.asm-smt.com
1 Switch on machine. 2 Cut the Tape. 3 Return COT.
4 Close the covers. 5 Press and hold COT button to dock table.
www.asm-smt.com
12 WF3 JTF-ML2 Maintenance Conduct reference run for JTF-ML2 and refill cassettes 6 min 1 / 4
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status ON Conveyor Empty
NOTICE! ESD guidelines are to be followed Tool: Wear Part: Consumables:
www.asm-smt.com
1 Select check sensors and functions icon. 2 Select "Do not change production status". 3 Select sensors and special functions.
4 Select location icon. 5 Select "JTF-ML2". 6 Select "Details" icon.
