xxiii Safety instructions Potential hazard Could cause machine damage (collisions with head, etc.). T o avoid hazard V erify that no objects have been placed on the batch change carrier's (for YSM40 and Z:LEX (YSM20…
xxii
Safety instructions
Potential
hazard
Could cause machine damage (collisions with head, etc.).
To avoid
hazard
Verify that no objects have been placed on the batch change carrier's (for YSM40) top cover.
Applicable
machines
Batch change carrier (YSM40)
Case
Setup
Potential
hazard
The carrier tape could make contact with the head, possibly causing machine damage.
To avoid
hazard
When a feeder is extracted from its loaded position, be sure that the feeder has been completely
extracted before pressing it back into its loaded position.
Applicable
machines
YSM40
Case
Setup
Potential
hazard
Pallet may drop if setting up parts on the parts supply station.
To avoid
hazard
Remove pallets before setting up parts.
Applicable
machines
cATS (YSM40)
Case
Setup
xxiii
Safety instructions
Potential
hazard
Could cause machine damage (collisions with head, etc.).
To avoid
hazard
Verify that no objects have been placed on the batch change carrier's (for YSM40 and Z:LEX (YSM20))
top cover.
Applicable
machines
Batch change carrier (YSM40, Z:LEX (YSM20))
Case
Setup
Potential
hazard
Could cause machine damage (collisions with head, etc.).
To avoid
hazard
Verify that no objects have been placed on the batch change carrier's (for YSM40 and Z:LEX (YSM20))
top cover.
Applicable
machines
Batch change carrier (YSM40, Z:LEX (YSM20))
Case
Setup
xxiv
Safety instructions
3.4 Label positions
The following warning/caution labels are attached to the YAMAHA products to ensure safe and correct use.
Check that the information on each label is clearly legible and comply with the instructions.
For safety precautions other than those on the labels shown in this section, see the instructions in "1. Safety".
n
NOTE
Basically, labels are attached to the positions shown below, although they may differ slightly depending on the
machine model.
n
NOTE
When connecting power to this equipment, refer to "Power connection terminals" described in the appendix of the
maintenance manual or user's manual.
Warning/caution labels
Front
■ Open/close cover inner side
■ Open/close cover, conveyor opening
■ Front lower panel
■ Main switch
■ Lower side panel
93201-N7-10
