Operation Manual
General Contents
About this manual
1. About this manual i
1.1 Contents of each chapter i
1.2 Page layout ii
Chapter 1 Part names and functions
1. Machine main unit 1-1
2. Operation panel and data input unit 1-3
2.1 Operation panel buttons 1-4
2.2 Keyboard (option) 1-5
3. Head assembly 1-6
3.1 Dispenser head 1-6
3.2 Nozzle types 1-7
3.2.1 Two-shot nozzles 1-7
3.2.2 One-shot nozzles 1-8
3.2.3 Narrow-pitch type nozzles 1-9
3.3 Dot plate 1-10
3.4 Dot station (option) 1-11
4. Front panel switches 1-12
5. Conveyor unit 1-13
6. Axis configuration 1-14
7. Air regulator unit 1-15
8. Connection between machines 1-16
8.1 PREVIOUS INTERFACE connector 1-17
8.2 NEXT INTERFACE connector 1-18
9. Power connection terminals 1-19
Chapter 2 Basic operation
1. Before operation 2-1
1.1 Starting the machine 2-1
1.2 Canceling emergency stop 2-3
1.3 Clearing an error 2-4
1.4 Turning off the machine power 2-5
EUN7192200
2. Operation screen and buttons 2-7
2.1 Basic configuration of operation screen 2-7
2.2 Setup screen 2-10
2.3 Unit screen 2-12
3. Machine operation from start to finish 2-16
3.1 Pre-operation check 2-17
3.2 Selecting the board data 2-18
3.3 Changing the conveyor unit setup 2-19
3.3.1 Conveyor unit setup flow 2-19
3.3.2 Changing the conveyor width 2-20
3.3.3 Adjusting the board hold plates 2-21
3.3.4 Arranging the push-up pins 2-22
3.4 Head unit setup 2-24
3.5 Starting and warming up the machine 2-27
3.6 Bleeding the nozzle air 2-29
3.7 Performing a dispensing test 2-32
3.8 Starting board production 2-34
3.9 Displaying the production monitors 2-35
3.10 Finishing board production 2-44
4. Basic tasks for optional units 2-46
4.1 Low-liquid sensor 2-46
4.1.1 Adjusting the low-liquid sensor 2-48
4.2 Dot station 2-50
4.2.1 Replacing the paper 2-50
4.3 Laser displacement meter 2-52
4.3.1 Initialization 2-52
Chapter 3 Q & A
1. Troubleshooting 3-1
1.1 Typical errors and troubleshooting 3-1
1.2 Mark recognition errors 3-4
1.3 Conveyor operation errors 3-4
1.4 Other errors 3-5
2. Handling dispensing errors 3-6
3. Reducing paper consumption 3-10
3.1 Predispensing interval setting 3-10
