7-8
7
Editing the board data
When "Insert Paste" is selected:
The data rows below the insertion point will be shifted down by the number of inserted rows. A confirmation message
will appear. Click the [Yes] button to paste the data while keeping the data number matching or click the [No] button to
paste the data without keeping the data number matching.
Confirmation dialog box for numbering correction
64708-N7-00
• When [Yes] is selected:
The data will be pasted while keeping the data number matching.
• When [No] is selected:
The current data numbers will be changed, so the data number matching will be lost. This might
cause data errors in some cases.
When "Overwrite Paste" is selected:
The data rows below the insertion point will be overwritten by the number of inserted rows.
c
CAUTION
The previous data in the paste range will be lost.
7-9
7
Editing the board data
1.5 Find and replace
You can search for a data item from the main view and replace it with another item. This find and replace
function can be used in the main view on the "Mount", "Offset", "Fiducial", "Badmark", “Height”, "Pre
Dispense" and "Dot Dispense" tabs.
1.5.1 Find
To find a data item in the main view, proceed as follows.
1
Display the data grid in the main view where you want to find a data item.
2
Click any row in the main view.
The clicked row becomes a starting point.
3
Find the data.
1. Select "Find" from the Edit menu.
The "Find" dialog box appears.
Copying the data in the selected range
64509-N7-00
2. From the "Find what" drop-down list, select the item to find.
Selecting the item to find
64510-N7-00
7-10
7
Editing the board data
3. In the "Find value" box, specify the character string or value to find.
4. To distinguish between uppercase and lowercase letters, select the "Match Case" check box to
place a check mark.
5. Select the direction to perform search.
Click the "To Up" radio button to perform search backward (toward the beginning of the data rows),
starting from the row you selected in step 2.
Click the "To Down" radio button to search forward (toward the end of the data rows), starting from
the row you selected in step 2.
6. Click the [Find] button to start a search.
When the target item is found, the row of the target item is highlighted. When you want to continue
to search under the same conditions, click the [Find] button again.
If no target item has been found, a message dialog box appears. Click the [OK] button to close the
message dialog box, and change the search conditions in the "Find" dialog box.
4
Close the "Find" dialog box.
Click the [Close] button to close the "Find" dialog box.
1.5.2 Replace
To find a data item in the main view and replace it with the specified content, proceed as follows.
1
Display the data grid in the main view where you want to perform a replace.
2
Click any row in the main view.
3
Perform replace.
1. Select "Replace" from the Edit menu.
The "Replace" dialog box appears.
Selecting the "Replace" command
Select the direction to perform search.Select these options as needed.
64511-N7-00
2. From "Item" drop-down box in the "Find what" group box, select the item to find.
3. In the "Value" box in the "Find what" group box, specify the character string or value find.
n
NOTE
Select "ALL" if you want to find the target value or character string from among all items.
