i Before using this machine 1. About this manual This manual is comprised of the following chapters. Before using this machine T his section shows a list of maintenance items and maintenance points. Chapter 1 Maintenance…
The instruction manual of this machine is written for those who operate
this machine.
Please read this manual carefully for correct operations and pay
special attention to safety precautions.
After reading through this manual, please use this manual as an
occasional reference and keep it within reach.
Before using this machine
Contents
1. About this manual i
2. Maintenance list ii
i
Before using this machine
1. About this manual
This manual is comprised of the following chapters.
Before using this machine
This section shows a list of maintenance items and maintenance points.
Chapter 1 Maintenance
Describes conditions and environments to use for maintaining equipment performance. The importance of making daily
checks and performing cleaning tasks is explained. Setups to make before starting maintenance work, consumable parts
and maintenance tools as well as the necessary tools are also described.
Chapter 2 Daily maintenance items
Making checks and cleaning the machine are essential daily maintenance tasks for maintaining equipment performance.
Performing these tasks prevents unforeseen trouble and allows using the machine in an optimum state.
Chapter 3 Periodic maintenance items
Describes maintenance tasks that should be performed periodically to maintain equipment performance. Periodic
maintenance includes "weekly", "monthly" and "yearly" maintenance tasks such as inspection, cleaning and lubrication
of the ball screws and guides.
Chapter 4 Maintenance of options
This chapter describes the maintenance of options.
Chapter 5 Lubrication points
Describes the lubrication points, lubrication tools, lubrication intervals for each axis explained in Chapter 3 "Periodic
maintenance items".
w
WARNING
BEFORE PERFORMING ANY MAINTENANCE TASK, BE SURE TO READ “SAFETY INSTRUCTION” AT THE BEGINNING OF THIS
MANUAL.
c
CAUTION
The contents of these manuals are subject to change without prior notice. Please be sure to contact our sales office or
representative to obtain the latest information on part names and part numbers.
ii
Before using this machine
2. Maintenance list
n
Maintenance list
Maintenance tasks listed in the table below are classified as follows:
S: Inspection C: Cleaning L: Lubrication E: Replacement Task in parentheses: Perform if necessary
n
NOTE
For example, the task "Others – Air/mist filter – Filter" in the table below is classified as C (E). This means that the filter
should be cleaned once a year, and if the filter does not become clean, it should be replaced.
Section Unit name Check items Daily Weekly Monthly 6 Mon. 1 year 3 years
Head
assembly
parts
Nozzle Nozzle hole SC
Z-axis
Ball screw CL
Guide CL
Spline shaft Appearance CL
X and Y axes
X-axis
Ball screw SCL
Guide SCL
Y-axis
Ball screw SCL
Guide SCL
Conveyor
units
Board transport unit
Board sensor SC
Board clamped SC
Conveyor belt SC E
PU axis
Ball screw CL
Ball guide CL
W-axis
Ball screw CL
Guide CL
Hex spline CL
Others
Base Filter C (E)
Controller unit Filter C (E)
Air/mist filter Filter C (E)
UPS Battery E
