63-D 3ノズルヘッド:NPM-W 3 NOZZLE HEAD:NPM-W パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N610157754AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - O235 ( KN610157754AA-04-4 )
Ref
No.
Remarks
R
1
Q'ty
63-C
3ノズルヘッド:NPM-W
3 NOZZLE HEAD:NPM-W
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610157754AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
3
1 N210154809AC
NUT
3
2 KXFB0APSA00
HOLDER
3
3 N210017657AB
RING
3
4 KXFB0APTB00
HOLDER
3
5 KXFB0APUB00
CYLINDER
3
6 KXFB0APVA00
PISTON
3
7 KXFB0ATVA00
HOUSING
3
8 N210154811AD
COLLAR
3
9 KXFB0ATXA00
CLAMP
6
10 KXFB00L1A02
A
RING
3
11 KXFB0ATYA00
ARM
3
12 KXFB00HMA02
PIECE
3
13 N210110278AA
RING
3
14 KXFB0ATZA00
SCREW
3
15 N210133825AA
COUPLING
3
16 KXFB0HBTA00
SPRING
3
17 N210076717AA
A
DOG
3
18 N210026984AA
FILTER
3
19 N610009394AB
BEARING
6
20 N510033224AA 6803ZZCM
C-RING
6
21 KXF0A74AA00 STW-9
PACKING
12
22 KXF05YHAA00 MYA-6
JOINT
3
23 N431PLH4M5M PLH4-M5M
DIAPHRAGM
3
24 KXF0DZHVA00
DM2-13-13-T2.NN501(Delivery drawing available)
BALL-SPLINE
3
25 N510037999AA LF6SGCSM+66LPM(12028716X002)
BEARING
12
26 KXF0DZXDA00 F-679
SHIM
9
27 N510029738AA FRS-9-12-0.3
FASTENER
6
28 KXF0DKMAA00 BX2.5-8(Drawing available 0DKMA)
TUBE(170mm CUT)
3
29 N610144924AA
BOLT
18
30 XVE26B6FTC
Hexagon socket head cap screw M2.6X6-12.9 SOB
BOLT
3
31 XVE2B5FTC Hexagon socket head cap screw M2X5-12.9 SOB
BOLT
12
32 XVE26B12FTC
Hexagon socket head cap screw M2.6X12-12.9 SOB
BOLT
6
33 XVE25B8FTC
Hexagon socket head cap screw M2.5X8-12.9 SOB
O-RING
3
34 KXF0DJ1AA00 CO0614A
JOINT
3
35 KXF02T4AA00 M-5AU-6
MOTOR
3
36 N510043455AA
S
P50BA2002BXS3D
PIN
3
37 N510020590AA MMS3-10
O234
--
( KN610157754AA-04-3 )
63-D
3ノズルヘッド:NPM-W
3 NOZZLE HEAD:NPM-W
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610157754AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
O235
( KN610157754AA-04-4 )
Ref
No.
Remarks
R
1
Q'ty
63-D
3ノズルヘッド:NPM-W
3 NOZZLE HEAD:NPM-W
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610157754AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
POST
3
1 KXFB0AU3A00
BRACKET
3
2 N210142974AA
PLATE
3
3 N210082178AA
STOPPER
6
4 N210016069AA
PLATE
3
5 N210026982AA
DOG
3
6 N210148248AA
REFLECTOR
2
7 N610123388AB
REFLECTOR
1
8 N610123390AB
SPACER
9
9 N510019911AA CB-302E
SPRING
6
10 KXF0E07FA00 SP(Drawing available KXF0E07FA00)
SCREW
3
11 N510018279AA
Cross recessed Truss head machine screw M4X6-4.8 A2J (Trivalent)
SPACER
12
12 N510026809AA ASB-325E
CLIP
3
13 KXF08EUAA00 NK-4N
SPACER
3
14 N510017047AA ASB-3100E
SPACER
3
15 N510059493AA CL-310E
BOLT
6
16 N510017312AA
Hexagon socket head cap screw M3X15-10.9 A2J (Trivalent)
BOLT
12
18 N510017338AA
Hexagon socket head cap screw M3X6-10.9 A2S (Trivalent)
WASHER
12
19 N510033304AA
Small round-plain washer 3 10H A2S (Trivalent)
SENSOR
3
20 N510067405AA PFMV530F-1-N-X518
SENSOR
3
21 N610078616AA
ELEMENT
10
22 N510059196AA ZS-36-A-X264
O-RING
10
23 N510059865AA ZS-36-A-X271
CAP
1
24 N510067900AA ZS-36-A-X314
O236
--
( KN610157754AA-04-4 )
