135- A 検 査BOX 部 In sp ect ion BO X パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N6 10 097 13 5AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - O437 ( KN610097135AA-09-1 )
Ref
No.
Remarks
R
1
Q'ty
134
配
線
付
属
:NPM-W(2D)
Wiring Assy OP for NPM-W_2D
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610142243AC
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
CONNECTOR
1
1 N3225637-859 56377-1200
CABLE
1
2 N510051164AA RM-LAN2-PB-L0700
CABLE
1
3 N510045153AA CAML-K-0400
CONNECTOR
1
4 N510051861AA B841S-88GF-H001
CLIP
5
5 N510014805AA THM1SC
CABLE
1
6 N610142824AB A1-R/B4010AC-R
LABEL
1
7 N610142964AA CONNECTOR LABEL ASSY FOR NPM-W_2D
O436
--
( KN610142243AC-01 )
135-A
検
査BOX
部
Inspection BOX
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610097135AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
O437
( KN610097135AA-09-1 )
Ref
No.
Remarks
R
1
Q'ty
135-A
検
査BOX
部
Inspection BOX
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610097135AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
1
1 N210124371AD
BASE-PLATE
1
2 N210124041AD
GUIDE
2
3 N210118626AA
GUIDE
2
4 N210121927AA
COLLAR
2
5 N210125131AA
BRACKET
3
6 N210118655AB
COVER
1
7 N210124063AC
BRACKET
1
8 N210125130AA
COVER
1
9 N210121402AA
REAR-COVER
1
10 N210124065AC
COVER
1
11 N210124082AC
BRACKET
2
12 N210124389AA
BUSH
1
13 N610097161AB
CAP
42
14 N510052984AA CP-328-B-5-G hole process gray
CASTER
2
15 N510045731AA 413SA-UB 50mm
CASTER
2
16 N510045733AA 420SA-UB 50mm
SPACER
6
17 N510049422AA 3382330-50025
URETHANE
2
18 N510052316AA 87AZFH-D24-V7-H4-G12-L11
FRAME
4
20 N510050630AA SFF-304B L=407
FRAME
2
21 N510049429AA SFF-304B L=450
FRAME
2
22 N510014679AA SFF-304B L=340
BRACKET
22
23 N510005830AA SFJ-018B
NUT
37
24 N510013440AA SFN-AS5
SUPPORT
75
25 KXF0DWJ9A00 SFA-9A2
NUT
36
26 N510013438AA SFN-AS6
GROMMET
2
27 N510056668AA C-30-SG-42A-EP-UL
SPACER
8
28 N510009129AA SFJ-401S
NUT
24
29 N510013304AA SFN-LS5
CAP
4
30 N510057510AA SFA-033B
FRAME
2
31 N510050631AA SFF-304B L=504
ADJUST-BOLT
2
32 N510052597AA D-C12X75
NUT
2
33 N510013441AA SFN-AS4
BOLT
34
34 N510017630AA
Hexagon socket Flat head bolt M5X12-10.9 A2J (Trivalent)
BOLT
8
36 N510017632AA
Hexagon socket Flat head bolt M5X16-10.9 A2J (Trivalent)
CLAMP
2
37 N510045728AA UL-23
SCREW
2
38 N510018158AA
Cross recessed Countersunk head machine screw M3X6-4.8 A2J (Trivalent)
NUT
4
39 N510017905AA
Hexagon nut Type-1 Best class M16-6H-4T A2J (Trivalent)
WASHER
4
40 N510018509AA
Round finish plain washer 16 10H A2J (Trivalent)
CABLE-SUPPORT
15
41 N510048517AA FT4
O438
--
( KN610097135AA-09-1 )
