15-D 全 体 カバー:NPM-W W hole Cover:NPM-W パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N610120842AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S55 ( KN610120842AA-16-4 )
Ref
No.
Remarks
R
1
Q'ty
15-C
全
体
カバー:NPM-W
Whole Cover:NPM-W
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610120842AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
2
1 N210149683AB
FRAME
2
3 N210143034AH
COVER
2
4 N210143036AA
BRACKET
2
5 N210143037AC
NUT-PLATE
2
6 N210143038AA
COVER
2
7 N210147088AB
COVER
2
8 N610124212AA
COVER
2
9 N610142966AA
COVER
2
10 N610124214AA
COVER
2
11 N610124215AA
NUT
80
14 KXF0ATGAA00 SFB-002
CAP
110
15 KXF0ATFAA00 SFA-906
GAS-SPRING
4
16 KXF0E381A00
S
KMF70-40M
SPACER
4
17 N510017106AA CF-418E
PULL
2
18 KXF0DX62A00 AP-829-2
SCREW
58
20 N510049926AA
Cross recessed Truss head machine screw M4X10-4.8 A2J (Trivalent)
SCREW
2
21 N510018257AA
Cross recessed Truss head machine screw M4X10-4.8 A2J (Trivalent)
BOLT
8
22 N510020762AA MMSB10-10
WASHER
16
23 N510018506AA
Round finish plain washer (JIS B 1256:1978) 10 10H A2J (Trivalent)
BOLT
8
24 N510017430AA
Hexagon socket head cap screw M6X14-10.9 A2J (Trivalent)
HINGE
4
26 N610124459AA
PLATE
4
29 N210164816AA
S54
--
( KN610120842AA-16-3 )
15-D
全
体
カバー:NPM-W
Whole Cover:NPM-W
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610120842AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S55
( KN610120842AA-16-4 )
Ref
No.
Remarks
R
1
Q'ty
15-D
全
体
カバー:NPM-W
Whole Cover:NPM-W
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610120842AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
2
1 N210143031AE
BRACKET
2
2 N210147084AB
BRACKET
2
3 N210152699AA
BRACKET
4
4 N210146154AB
LEVER
2
5 N210092154AD
BRACKET
4
6 N210147089AA
BRACKET
4
7 N210147090AA
COVER
1
8 N610120787AB
CAP
4
9 KXF0ARXAA00 SFA-005
NUT
18
10 KXF0ATHAA00 SFB-001
NUT
12
11 KXF0ATJAA00 SFB-006
BRACKET
16
12 KXF0ATEAA00 SFJ-018
BRACKET
8
13 KXF0DTWAA00 SFJ-N03
SWITCH
2
14 N510034226AA
S
D4NH-9BBC
SPACER
2
15 N510030914AA CB-307E
WASHER
2
16 N510018472AA
Iron round plain washer3X10X1.0(chromeite) A2J (Trivalent)
BOLT
4
17 N510001582AA SRBS-M4X30
BOLT
2
18 N510026881AA SRBS-M3X12
SPACER
2
19 N510030906AA CB-350E
BOLT
2
20 N510017335AA
Hexagon socket head cap screw M3X55-10.9 A2J (Trivalent)
CABLE-SUPPORT
2
21 N510048516AA FT3
CABLE-SUPPORT
15
22 N510025949AA C1P-004C
NUT
2
23 N510013282AA SFN-TS4
FRAME
2
24 N510057898AA SFF-364 L=1133
FRAME
4
25 N510057899AA SFF-364 L=162
FRAME
2
26 N510057900AA SFF-364 L=793
S56
--
