LIS T -MA GNETIK 7 With the Magnet permeability meter Fer r omaster you can easily measure the relative magnetic permeability µr of feebly magnetic materials and workpieces with a permeability between 1 .0 0 1 and 1 .999…
6
LIST-MAGNETIK
MP-80
Residual magnetic field meter
With the handy, battery-operated List-Magnetik MP-80 residual
magnetic field meter, you can quickly and reliably determine the
residual magnetism, also known as remanence, on ferromagnetic
iron and steel parts. The measuring device can also be used to check
demagnetized parts.
The „little brother“ of the MP-800 has its particular strength in the
area of weak magnetic fields. With its compact design and metal
housing, the device is robust and insensitive to harsh environments
such as oily vapors or moisture.
The supplied calibration standard of 5 A/cm always gives you the
certainty that your device is working correctly.
The Fluxmeter FL-4 is a measuring device for
the determination of the magnetic flux Φ (Phi)
of a magnet system or a single magnet.
In combination with the List-Magnetik Helm-
holtz moment coil HM-1, the magnetic flux
of permanent magnets can be determined
very accurately, since the entire volume
of the magnet is measured independently
of position. The effect of the magnet on the
coil is determined in the form of an electrical
voltage and converted into the flux value.
FL-4 – Fluxmeter
MP-1000
Magnetic Field Meter
The List-Magnetik MP-1000 magnetic field meter is a handy uni-
versal device with externally connectable transversal and axial field
probes for the precise measurement of all types of magnetic fields:
steady DC fields, alternating AC fields and pulsed fields.
A separate built-in micro controller in the MP-1000‘s measuring
probes digitizes and linearizes the analog measurement signals of the
hall sensor into the probe. This gives an extremely trouble-free and
precise measurement, especially at high magnetic field strengths.
The probe cable is pluggable at both ends, at the display unit and the
probe, which is particularly service-friendly, as the cable can simply
be replaced if it becomes faulty. Applications of the MP-1000 are the
test for residual magnetism, the measurement of magnetic fields of
all kinds, as well as the localization of stray fields for crack detection.
LIST-MAGNETIK
7
With the Magnet permeability meter
Ferromaster you can easily measure the
relative magnetic permeability µr of feebly
magnetic materials and workpieces with a
permeability between 1.001 and 1.999.
The permeability is measured by touching the
workpiece with the probe tip and reading
the result from the display.
Typical applications are: non-destructive
testing of materials, e. g. quality control of
stainless steel, material selection for electron-
/ion-beam equipment, detection of material
defects induced by mechanical or thermal
stress.
FerroPro compact
Magnet Permeability Meter
MP-80
Residual magnetic field meter
MP-1000
Magnetic Field Meter
With the Magnet permeability meter
Ferromaster you can easily measure the
relative magnetic permeability µr of feebly
magnetic materials and workpieces with a
permeability between 1.001 and 1.999.
The permeability is measured by touching the
workpiece with the probe tip and reading
the result from the display.
Typical applications are: non-destructive
testing of materials, e. g. quality control of
stainless steel, material selection for electron-
/ion-beam equipment, detection of material
defects induced by mechanical or thermal
stress.
Ferromaster
Magnet Permeability Meter
8
www.list-magnetik.com
List-Magnetik
Dipl.-Ing. Heinrich List GmbH
Max-Lang-Straße 56/2
D-70771 Leinfelden-Echterdingen
Telefon +49 (711) 90 36 31-0
info@list-magnetik.de
www.list-magnetik.com
1 A/cm = 0.1 kA/m = 1.256 Gauss = 1.256 Oersted = 0.1256 mT (Millitesla)
Performance table and technical Data
MP-4000 · MP-810 · MP-80 · MP-1000
MP-4000 MP-810A / MP-810T MP-80 MP-1000
Measuring units A/cm – kA/m – Gauss / Oersted – Tesla A/cm – Gauss / Oersted
Applicable probes
Axial probes PM2-A and PM4-A,
Transversal probes PM2-T, PM2-TR,
PM4-T and PM4-TR
MP-810A:
integrated axial probe
MP-810T:
integrated transversal probe
integrated axial probe
Axial probes P-A2 and
P-W2, Transversal probes
P-T2 and P-Z2
Measuring range
direct field / DC
0-40,000 A/cm 0-20,000 A/cm 0-100 A/cm 0-20,000 A/cm
Measuring range
alternating field / AC
0-20,000 A/cm 2-20,000 A/cm – 20-20,000 A/cm
Accuracy in
homogeneous field
± 1 A/cm to 50 A/cm,
± 2% measured value
from 50 A/cm,
± 3% measured value
from 20,000 A/cm
± 1 A/cm up to 50 A/cm,
± 2% of measured value
from 50 A/cm
± 0,3 A/cm up to 10 A/cm,
± 3% of measured value
from 10 A/cm
± 1 A/cm up to 50 A/cm,
± 2% of measured value
from 50 A/cm
Resolution
0-200 A/cm: 0.1 A/cm,
> 200 A/cm: 1 A/cm,
> 10,000 A/cm: 10 A/cm
0,1 A/cm
0–100 A/cm: 0,1 A/cm,
>= 100 A/cm: 1 A/cm,
>= 1,000 A/cm: 10 A/cm,
>= 10,000 A/cm: 100 A/cm
Frequency range AC 2 Hz – 20 kHz 20-100 Hz – 10 Hz – 5 kHz
Display LCD Touch panel color 320x480 pixe OLED Graphic Display illuminated LCD display 3 digit
Multilingual menu
navigation
English, German, French, Italian,
Spanish
English, German, French, Italian, Spanish, Hungarian,
Polish, Dutch
–
Data logger 10,000 measurements, flexibly divisible 4,000 measurements, flexibly divisible –
Statistics Count / maximum / minimum / average / standard deviation –
Interface Bluetooth Low Energy interface for communication with Android, iOS and Windows –
App for Android,
iOS, Windows
free of charge via Google Play Store, Apple App Store, List-Magnetik website –
Power supply
3x 1.5 V AA Mignon. External power
supply can be connected via USB-C
1x 1.5V AA Mignon 2x 1.5 V AA Mignon
Dimensions 150 x 85 x 35 mm Ø 28 x 180 mm Ø 28 x 103 mm 105 x 65 x 26 mm
Weight 320 g with batteries
73 g with batteries 70 g with batteries 137 g with batteries
