SAFETY FEATURES
HIGH VOLTAGE PROTECTION
Chapter Issue 15, Nov 19 Installation Manual 1.19
Mains Isolator (cover removed) Showing Earth Loom Arrangement
1 Earth Lead to Chassis M5 Stud and TB3
2 Earth Label
3 Earth Lead to Chassis M6 Stud (Protective Earth)
SAFETY FEATURES
HIGH VOLTAGE PROTECTION
1.20 Installation Manual Chapter Issue 15, Nov 19
Earth Studs and Labels on the Print Carriage
1 Earth Studs and Labels
Earth Studs and Labels on the Vacuum Pump
1 Earth Studs and Labels
SAFETY FEATURES
HIGH VOLTAGE PROTECTION
Chapter Issue 15, Nov 19 Installation Manual 1.21
Typical Module Earth Stud and Label
1 Earth Studs and Labels (PC/M27/M36/M37/M39)
