2 7 - 1 2 7 . P n e u m a t i c c i r c u i t d i a g r a m ( W P I ) エアー配管図 CP-642 P ARTS LIST ver08 2 7 . P n e u m a t i c c i r c u i t d i a g r a m ( W P I ) エアー配管図 φ6 φ6 φ6 φ6 φ8 φ6 φ6 φ6 A P φ8 φ8 φ8 φ6 φ8 4 . 0 …

番号図番 & ｺｰﾄﾞ番号個数品名規格備考

No. Drg. No. & Code No. QTY Description Rating Remarks

1WPA0911 1 DISTRIBUTOR 分配器

2WPA0930 2 HOLDER 受け

3WPA1451 1 ELBOW ｴﾙﾎﾞ

4WPA1460 1 PIPE, DOUBLE ENDED ﾊﾟｲﾌﾟ両口

5WPA1470 1 PIPE, DOUBLE ENDED ﾊﾟｲﾌﾟ両口

6WPA1481 1 PIPE ﾊﾟｲﾌﾟ

7WPA1491 1 PIPE ﾊﾟｲﾌﾟ

8WPA1581 1 DISTRIBUTOR 分配器

9H3057T 1 BUSHING ﾌﾞｯｼｭ SBU06-02J

10A4085E 4 ELBOW, MALE AND FEMALE ｴﾙﾎﾞｵｽﾒｽ 516-018KN3

11H1150N 4 BAND, HOSE ﾊﾞﾝﾄﾞﾎｰｽ HS16

12H5004T 1 HOSE ﾎｰｽ Mﾟ25Xﾟ30 (1.5m)

13H5038T 1 HOSE, HYDRAULIC ﾎｰｽ油圧 716-M200

14H5041A 1 HOSE, HYDRAULIC ﾎｰｽ油圧 716-M700

15H5044R 1 HOSE, HYDRAULIC ﾎｰｽ油圧 718-720MK

16S4033T 1 SENSOR, PRESSURE ｾﾝｻ圧力 AP-13

17A1038T 1 AMPLIFIER ｱﾝﾌﾟ AP-70

18A4024A 1 ELBOW ｴﾙﾎﾞ SLA06-000J

19A4084A 2 ELBOW, MALE AND FEMALE ｴﾙﾎﾞｵｽﾒｽ SLC06-000J

20A4085N 1 ELBOW ｴﾙﾎﾞ 3/4.

21A3035A 1 PLUG 埋栓 PS3/4

22A3032A 2 PLUG 埋栓 PT1/2

23H3060T 1 BUSHING ﾌﾞｯｼｭ SBU08-060J

24S2164T 2 JOINT, MALE AND FEMALE ｼﾞｮｲﾝﾄｵｽﾒｽ 408054KN

26A50032 1 OIL, COOLANT ｵｲﾙｸｰﾗﾝﾄ SCFB-01

27WPA0942 4 NIPPLE ﾆｯﾌﾟﾙ

49H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M3X8L

53H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M5X10L

54H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M5X12L

59H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M6X15L

62W1023A WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M

63W1024A WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 6M/M

69WAC0151 4 BOLT ﾎﾞﾙﾄ

70WAC0210 4 SHEET, RUBBER ｼｰﾄｺﾞﾑ

71WAC0200 4 BUSHING ﾌﾞｯｼｭ

72WAC0120 1 PLATE ﾌﾟﾚｰﾄ

73WAC0190 2 COLLAR ｶﾗｰ

82WPA1810 1 HOSE ﾎｰｽ

83A4044A 1 ELBOW ｴﾙﾎﾞ PL6-01M

84T4022A 1 TEE ﾃｨｰ TT6-01

86WAC0111 1 BKT BKT

87N1011A 4 NUT ﾅｯﾄ 406-002

88S3083A 4 SLEEVE ｽﾘｰﾌﾞ 406-001 ･

26-5

26.2.Cam box 3(WPA) カムボックス 3

CP-642 PARTS LIST ver08

26.2.Cam box 3(WPA) カムボックス 3

27-1

27.Pneumatic circuit diagram(WPI) エアー配管図

CP-642 PARTS LIST ver08

27.Pneumatic circuit diagram(WPI) エアー配管図

φ6

φ8

φ6

φ8

φ6

φ8

4.0kgf/cm

φ8

R1P

3/8

PT3/8

メカニカルバルブ

Mechanical valbes

φ6

φ8

φ6

配管タ−ミナル

Conduct terminal

φ8 φ8

5kgf/cm

配管タ−ミナル

Conduct terminal

配管タ−ミナル

Conduct terminal

φ6

φ4

φ6

φ4

φ6

φ6 φ6

φ8

R2 R2

φ8

1ST駆動部(WPL)

PCBストッパ− 1

PCB stopper 1

(φ16x10）

PCBストッパ− 2

PCB stopper 2

(φ16x10）

XYテ−ブル

XY table

1ST Mechanizm

カ−トリッジ送り

Tape feeding lever

送りレバ−後退時

Feeding lever retracted



Pθ旋回

Pθ rotation

(φ25x40)

90°旋回時

While rotating 90°

PRθ旋回

PRθ rotation

(φ25x40)

90°旋回時

While rotating 90°

シャッタ−左

Left shutter

(φ20x250)

シャッタ−右

Right shutter

(φ20x250)

基準側

Operator side board clamp

従属側

Back side board clamp

バキュ−ム系

Vacuum

20ヘッド

20 heads

バキュームバックアップピン

(オプション)

Vacuum backup pin (Option)

φ6

φ6φ6

12 12

35 35

35 35 35 3535 35

35 35 35 35

リアフェンス(WAF)

Rear Fence

エア−源

Air supply

基板クランプ(WSS)

Board clamp

防音BOX(WPV)

Noise reduction box

ロ−ダ(WQL)

Loder

θ軸(WPQ)

Pθ rotation

16st真空破壊

16st vacuum cut off

16st(WPU)

16st vacuum cut

11st真空破壊

11st vacuum cut off

1st送り上下

1st feed lever up/down

(φ25x12)

レバー上昇時

While lever ascends

1stノズル上下

1st nozzle up/down

(φ25x12)

レバー上昇時

While lever ascends

18stノズル切替前後

18st nozzle change fwd/bwd

(φ25x12)

レバー上昇時

While lever ascends

3stPθ上下

3st Pθ up/down

(φ25x12)

レバー上昇時

While lever ascends

10stFθ上下

10st Fθ up/down

(φ25x12)

レバー上昇時

While lever ascends

11stノズル上下

11st nozzle up/down

(φ25x12)

レバー上昇時

While lever ascends

13stPRθ上下

13st PRθ up/down

(φ25x12)

レバー上昇時

While lever ascends

11st(WPS)

11st vacuum cut

カムBOX(WPA)

Cam box

カムBOX(WPA)

Cam box

番号図番 & ｺｰﾄﾞ番号個数品名規格備考

No. Drg. No. & Code No. QTY Description Rating Remarks

1H1046A 1 VALVE, STOP ﾊﾞﾙﾌﾞｽﾄｯﾌﾟ A318X100

2H3030A 1 FILTER, REGULATOR ﾌｨﾙﾀﾚｷﾞｭﾚｰﾀ AW3000-02-BDG

3S3153A 1 SW, PRESSURE SW ﾌﾟﾚｯｼｬ IS300-02

4. 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ VV5Z3-41-031-M5

6H1130Z 2 VALVE, SOLENOID ﾊﾞﾙﾌﾞ SOL VZ3140-5MZ

7WQL4080 1 ASSY ASSY (4+6)

8K5337A 4 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗｽﾋﾟｰﾄﾞ AS1200F-M5-06

9H1083T 1 VALVE, SOLENOID ﾊﾞﾙﾌﾞ SOL SS22J-M5-D24UP-Z

11S2113H 2 CYLINDER, AIR ｼﾘﾝﾀﾞｴｱｰ CDQ2D16-10D-F7BV

12K5339T 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗｽﾋﾟｰﾄﾞ AS1311F-M5-06

14H10246 1 REGULATOR ﾚｷﾞｭﾚｰﾀ R002-01G

15H5447A 1 VACUUM PUMP ﾎﾟﾝﾌﾟﾊﾞｷｭｰﾑ KHA750A-302-G1

16. 1 VACUUM GAUGE 真空ｹﾞｰｼﾞ No.15.16set

17S3158A 1 PRESSURE SWITCH 圧力ｽｲｯﾁ ISG190-030

18H1077T 1 VALVE, SOLENOID ﾊﾞﾙﾌﾞ SOL PCS242-M5-D24-SP

19H1068Z 2 VALVE, SOLENOID ﾊﾞﾙﾌﾞ SOL PCD2413-02-D24SP

20WPA5142 7 CYLINDER, AIR ｼﾘﾝﾀﾞｴｱｰ

21. 2 CYLINDER, AIR ｼﾘﾝﾀﾞｴｱｰ DAD-25X40-3731W

23S1056A 5 SILENCER ｻｲﾚﾝｻ AN101-01

24S1058A 2 SILENCER ｻｲﾚﾝｻ AN120-M5

26. 4 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗｽﾋﾟｰﾄﾞ SC6-01-UB

27S2100A 2 CYLINDER, AIR ｼﾘﾝﾀﾞｴｱｰ CDM2B20-250-H7A1

28H1073F 2 VALVE, SOLENOID ﾊﾞﾙﾌﾞ SOL PCD345-01D-D24SP

29K5338A 1 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗｽﾋﾟｰﾄﾞ AS-1211F-M5-06

31H1063T 2 VALVE, MECHANICAL ﾊﾞﾙﾌﾞﾒｶﾆｶﾙ VM133-M5-01

32H1006T 1 GENERATOR, VACUUM 発生器真空 VDBL12P8-06-SA

33S1053T 4 SILENCER ｻｲﾚﾝｻ KM-23

34H1037E 1 VALVE, MANUAL ﾊﾞﾙﾌﾞ手動 HV6-6

35S1052A 14 SILENCER ｻｲﾚﾝｻ SL-M5 ･

27-2

27.Pneumatic circuit diagram(WPI) エアー配管図

CP-642 PARTS LIST ver08

27.Pneumatic circuit diagram(WPI) エアー配管図
