3 1 - 1 3 1 . I n c o n v e y o r ( C o v e r ) ( O p t i o n ) ( W Q C ) インコンベア( カバー) ( オプション) CP-642 P ARTS LIST ver08 3 1 . I n c o n v e y o r ( C o v e r ) ( O p t i o n ) ( W Q C ) インコンベア( カバー) ( オプション) 1 9 1 3 2 5…
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No. QTY Description Rating Remarks
1WAB0023 1 COVER ｶﾊﾞｰ WAB0023
2H3149A 1 PLUG, COUPLER ﾌﾟﾗｸﾞ ｶﾌﾟﾗ 20PM
3H1046A 1 VALVE, STOP ﾊﾞﾙﾌﾞ ｽﾄｯﾌﾟ A318X100
4T4038A 1 TEE ﾃｨｰ 1/4.
5A4053A 1 ELBOW ｴﾙﾎﾞ 1/4.
6A4081A 1 ELBOW, DIFFERENT DIAMETERSｴﾙﾎﾞ異径 3/8X1/4
7H3030A 1 FILTER REGULATOR ﾌｨﾙﾀﾚｷﾞｭﾚｰﾀ AW3000-02-BDG
8S3157H 1 SW, PRESSURE SW ﾌﾟﾚｯｼｬ IS3000-02L5
9S2176A 4 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TS6-01
10S2172A 1 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL6-02
11S2171A 1 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL6-01
12S2173A 3 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL8-01
13S2174A 1 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL8-02
14H1215A 2 PIPE, DOUBLE ENDED ﾊﾟｲﾌﾟ 両口 1/4X30
15H1220A 2 PIPE, DOUBLE ENDED ﾊﾟｲﾌﾟ 両口 1/4X65
16H1282A 1 PIPE, DOUBLE ENDED ﾊﾟｲﾌﾟ 両口 3/8X25
17H3075A 1 BUSHING ﾌﾞｯｼｭ 3/8X1/4
18H5295A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X35L
19H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
20W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
21W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
22W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
23GXA0110 1 TERMINAL, PIPING ﾀｰﾐﾅﾙ 配管
24S2153A 1 JOINT ｼﾞｮｲﾝﾄ TS8-02 ･
30-2
30.Air device(WPI) エアー機器
CP-642 PARTS LIST ver08
30.Air device(WPI) エアー機器
31-1
31.In conveyor(Cover)(Option)(WQC) インコンベア(カバー)(オプション)
CP-642 PARTS LIST ver08
31.In conveyor(Cover)(Option)(WQC) インコンベア(カバー)(オプション)
19
13
25
22
19
11
25
22
15
19
13
25
22
19
10
25
22
24
20
19
10
25
22
24
20
28
5
27
3
25
20
2
16
28
4
7
27
6
26
25
23
14
17,18
26
25
22
30
29
21
1
12
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No. QTY Description Rating Remarks
1WQC4362 1 BKT BKT
2AWQC8051 1 COVER ｶﾊﾞｰ
3AWQC8020 1 COVER ｶﾊﾞｰ
4WQC4381 1 BAR ﾊﾞｰ
5WQC0251 1 BAR ﾊﾞｰ
6WQC4390 1 HINGE 蝶番
7WQC4400 1 BKT BKT
10WQC0301 2 BKT, COVER BKT ｶﾊﾞｰ
11WQC0310 1 BKT, COVER BKT ｶﾊﾞｰ
12CLC4251 1 STOPPER ｽﾄｯﾊﾟ
13MQC6031 2 BKT BKT
14IPK8090 1 PLATE, SW ﾌﾟﾚｰﾄ SW (Option)
15IPK8510 1 BOLT ﾎﾞﾙﾄ
16T5011S 1 HANDLE, ROUND 取手 丸 TTHA-00425
17S3160H 1 SW, MICRO SW ﾏｲｸﾛ V-15-1B6
18A1002A 1 ACTUATOR ｱｸﾁｭｴｰﾀ VAL-2
19IQC6072 10 NUT ﾅｯﾄ
20H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
21H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
22H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
23H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
24W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
25W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
26W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
27K5257A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L
28. SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X15L
29W1001F WASHER ﾜｯｼｬ ﾊﾂｷｻﾞｶﾞﾈ(B)M5
30CLC4261 1 NUT, ROUND ﾅｯﾄ 丸 ･
31-2
31.In conveyor(Cover)(Option)(WQC) インコンベア(カバー)(オプション)
CP-642 PARTS LIST ver08
31.In conveyor(Cover)(Option)(WQC) インコンベア(カバー)(オプション)
