4 4 - 1 4 4 . V a c u u m b a c k u p ( O p t i o n ) ( W S Z ) バキュームバックアップ( オプション) CP-642 P ARTS LIST ver08 4 4 . V a c u u m b a c k u p ( O p t i o n ) ( W S Z ) バキュームバックアップ( オプション) 1 2 3 3 5 5 4 3 7 6 3 5 7 3 8 6 3 5…
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No. QTY Description Rating Remarks
54H5294A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X30L
71H5145H 6 BOLT, LEVELING ﾎﾞﾙﾄ ﾚﾍﾞﾘﾝｸﾞ TM-257-No3 (Option)
73S2037A 1 SEAL ｼｰﾙ DE9-PL113043
74WAF0572 1 FENCE ﾌｪﾝｽ (Option)
75WAF0582 1 FENCE ﾌｪﾝｽ (Option)
76WAF0620 4 JOINT ｼﾞｮｲﾝﾄ (Option)
77AGPZ8141 2 COVER ｶﾊﾞｰ (Option)
78GPZ4320 4 RETAINER, COVER 押え ｶﾊﾞｰ (Option)
87H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
88W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
89W1042A WASHER, FLAT ﾜｯｼｬ 平 W4-3
90K5207A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X5L
91. SCREW, COUNTERSUNK 小ﾈｼﾞ 皿 M3X4L
100WAF0660 2 COVER ｶﾊﾞｰ H=900∼965 (Option)
101Y3033A 2 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KCH06-00
102WAF0800 3 BKT, SENSOR BKT ｾﾝｻ
104S4036T 3 SENSOR, AREA ｾﾝｻ ｴﾘｱ NA40-8 Set parts
110H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
111GXZ2240 4 RETAINER, RAIL 押え ﾚｰﾙ (Option)
112WAF2093 12 BKT, SENSOR BKT ｾﾝｻ For GL-Ⅱ (Option)
113WAF0651 1 FENCE ﾌｪﾝｽ For GL-Ⅱ (Option)
114WAF0660 1 COVER ｶﾊﾞｰ For GL-Ⅱ (Option)
115WAF0620 2 JOINT ｼﾞｮｲﾝﾄ For GL-Ⅱ (Option)
116GXZ2240 2 RETAINER, COVER 押え ｶﾊﾞｰ For GL-Ⅱ (Option)
117GXZ2300 1 COVER ｶﾊﾞｰ For GL-Ⅱ (Option)
118GXZ2310 2 RETAINER, COVER 押え ｶﾊﾞｰ For GL-Ⅱ (Option)
119H5145H 2 BOLT, LEVELING ﾎﾞﾙﾄ ﾚﾍﾞﾘﾝｸﾞ TM-257-No3 For GL-Ⅱ (Option)
120M6X10L SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋
121MPZ6321 1 HOOK ﾌｯｸ
122H5175A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
123WAF0551 1 FENCE, SAFETY ﾌｪﾝｽ 安全
124WAF0561 1 FENCE, SAFETY ﾌｪﾝｽ 安全
125WAF0670 1 FENCE ﾌｪﾝｽ For GL-541E (Option)
126WAF0680 1 COVER ｶﾊﾞｰ For GL-541E (Option)
127AWAF8530 1 COVER ｶﾊﾞｰ For GL-541E (Option)
128WAF0700 2 COVER, RETAINER ｶﾊﾞｰ 押え For GL-541E (Option)
129WAF0620 2 JOINT ｼﾞｮｲﾝﾄ For GL-541E (Option)
130GXZ3020 2 COVER, RETAINER ｶﾊﾞｰ 押え For GL-541E (Option)
131H5145H 1 BOLT ﾎﾞﾙﾄ TM-257-No.3 For GL-541E (Option)
.
43-3
43.Fence(Option)(WAF) フェンス(オプション)
CP-642 PARTS LIST ver08
43.Fence(Option)(WAF) フェンス(オプション)
44-1
44.Vacuum back up(Option)(WSZ) バキュームバックアップ(オプション)
CP-642 PARTS LIST ver08
44.Vacuum back up(Option)(WSZ) バキュームバックアップ(オプション)
1
2
3
35
5
4
37
6
35
7
38
6
35
8
43
9
10
32
11
12
13
15
36
33
17
16
18
39
19
20
21
22
31
24
25
26
27
49
29
29
28
14
27
51
23
30
A
A
45
47
42
34
48
40
32
41
32
42
44
32
42
38
33
46
46
33
36
49
50
32
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1WSZ5012 1 PLATE ﾌﾟﾚｰﾄ
2WSZ5102 10 BOLT ﾎﾞﾙﾄ
3WSZ5130 1 DOG, SW ﾄﾞｯｸﾞ SW
4WSZ5150 1 BKT BKT
5WSZ5160 1 SPACER ｽﾍﾟｰｻ
6WSZ5180 2 PLATE ﾌﾟﾚｰﾄ
7WSZ5191 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ
8WSZ5201 1 PLATE ﾌﾟﾚｰﾄ
9WSZ5210 1 BKT BKT
10WSZ5221 1 BKT BKT
11WSZ5243 10 LEVER ﾚﾊﾞｰ
12WSZ5250 10 BOLT ﾎﾞﾙﾄ
13WSZ5261 10 PIN, BACKUP ﾋﾟﾝ ﾊﾞｯｸｱｯﾌﾟ
14WSZ5280 10 TUBE ﾁｭｰﾌﾞ
15PPT1490 88 PLUG ﾌﾟﾗｸﾞ
16WSY4491 1 HOLDER ﾎﾙﾀﾞ
17WSY4502 1 SPACER ｽﾍﾟｰｻ
18WSY4510 1 BKT BKT
19H1189A 10
PAD
ﾊﾟｯﾄ VP-15RS
20S2173A 1
JOINT, ONE-TOUCH
ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL8-01
21A4047A 1
ELBOW
ｴﾙﾎﾞ PLJ-8
22Y3026A 1
UNION
ﾕﾆｵﾝ PMP8
23H1037E 1 VALVE, MANUAL ﾊﾞﾙﾌﾞ 手動 HV6-6
24H1006T 1
GENERATOR, VACUUM
発生器 真空
VDBL12P8-06SA
25A4106S 10 X RING X ﾘﾝｸﾞ X013
26A4106T 10 X RING X ﾘﾝｸﾞ X014
27A4067H 20
ELBOW
ｴﾙﾎﾞ M-3AU-4
28T2063A 1
TUBE
ﾁｭｰﾌﾞ TU0604B-20
29T2064A 1
TUBE
ﾁｭｰﾌﾞ TU0805B-20
30T4022T 1
TEE
ﾃｨｰ UTD8-6
31W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
32W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
33W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
34W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
35W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
36W1044A
WASHER, FLAT
ﾜｯｼｬ 平
4W-5
37W1045A
WASHER, FLAT
ﾜｯｼｬ 平
4W-6
38W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L
39K5208A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M4X6L
40H5281A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X25L
41H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
42H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
43H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L
44H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L
44-2
44.Vacuum back up(Option)(WSZ) バキュームバックアップ(オプション)
CP-642 PARTS LIST ver08
44.Vacuum back up(Option)(WSZ) バキュームバックアップ(オプション)
