4 - 1 4 . O u t c o n v e y o r ( W Q C ) アウトコンベア CP-642 P ARTS LIST ver08 4 . O u t c o n v e y o r ( W Q C ) アウトコンベア H E L P S 8 7 9 6 4 6 9 0 4 7 9 4 8 1 4 6 9 0 4 8 9 4 8 1 1 6 3 8 6 8 3 1 0 0 9 1 8 2 8 5 4 5 4 4 1 6…

100%1 / 156
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No. QTY Description Rating Remarks
92H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
93K5261A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X10L
94K5208A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L
95K5186T SCREW, COUNTERSUNK 小ﾈｼﾞ 皿 M4X6L
96K5177A SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M2.5X14L
97MQC1160 4 PULLEY ﾌﾟｰﾘ
98MQC1170 4 BOLT ﾎﾞﾙﾄ
99MQC1181 4 COLLAR ｶﾗｰ
100H4129A 8 BEARING ﾍﾞｱﾘﾝｸﾞ LF950ZZ
101WQC0120 2 HOLDER 受け
102WQC0521 1 COVER, CHAIN ｶﾊﾞｰ ﾁｪｰﾝ HELPS
103MQC0141 1 BKT, SENSOR BKT ｾﾝｻ HELPS
104WQC0130 1 BKT BKT
109GVC4070 1 SPACER ｽﾍﾟｰｻ HELPS
112S4040X 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX306-W2A HELPS
114H5332A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X50L
115. SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X15L
116W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
117MQC4092 1 BKT BKT HELPS
118GVC2182 1 BKT, SENSOR BKT ｾﾝｻ HELPS
119WQC0560 1 BKT BKT
125H5181A BOLT, HEX ﾎﾞﾙﾄ 六角 M6X12L
126WQC4100 1 BRIDGE ﾌﾞﾘｯｼﾞ
127IQC6290 1 NUT ﾅｯﾄ
128WQC0111 1 BKT BKT
129GVC2311 1 SHAFT ｼｬﾌﾄ
130H1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8
131WQC4160 1 BKT BKT
132WQC4340 1 BKT BKT
133S3130T 1 SW, PHOTOELECTRIC SW 光電 PS-49
134A1040H 1 AMPLIFIER ｱﾝﾌﾟ PS2-61
135H5279A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X20L
136WQC5091 2 BELT ﾍﾞﾙﾄ
137H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L ･
3-4
