6-5
CP-642 PARTS LIST ver08
6.2.Board clamping unit(WSS) 基板クランプ
6.2.Board clamping unit(WSS) 基板クランプ
逆流れ
Right-to-Left Board Flow
正逆流れ
Board Flow Changeover Manual
122
18
40
39
48
110
20
127
141
99
36
38
127
139
121
109
108
121
105
142
157
114
113
49
154
99
37
38
127
139
20
127
141
153
48
39
41
19
122
99
36
38
127
139
20
127
141
156
49
48
39
121
105
116
115
108
109
121
99
37
38
127
139
20
127
141
111
48
39
40
19
122
99
36
38
127
139
20
127
141
110
48
39
40
18
122
108
109
121
121
107
106
105
153
48
39
19
122
108
109
121
111
48
39
112
122
20
127
141
99
37
38
127
139
122
18
73
73
155
149
149
149
73
49
154
41
41
143
142
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No. QTY Description Rating Remarks
18WSS4302 1 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ
19WSS4312 1 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ
20WSS4351 2 PLATE, STOPPER ﾌﾟﾚｰﾄ ｽﾄｯﾊﾟ
36WSS4720 1 BKT, SENSOR BKT ｾﾝｻ
37WSS4730 1 BKT, SENSOR BKT ｾﾝｻ
38WSS4742 2 PLATE ﾌﾟﾚｰﾄ
39WSS4750 2 DOG ﾄﾞｯｸﾞ
40WSS4760 1 PIN, LOCATING ﾋﾟﾝ 位置決め φ3 注1. Note1.
41AWSS8510 1 PIN, DIAMOND-SHAPED ﾋﾟﾝ ﾀﾞｲﾔ φ3 注2. Note2.
48GPT0550 2 SPRING ｽﾌﾟﾘﾝｸﾞ
49GPT0560 1 SPRING ｽﾌﾟﾘﾝｸﾞ
73S1021A 3 SIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-3
99S4032T 1 SENSOR ｾﾝｻ UM-T50N
105WSS4842 1 GUIDE ｶﾞｲﾄﾞ
106WSS4851 1 COVER 蓋
107WSS4863 1 COVER 蓋
108WSS4874 1 CLAMPER ｸﾗﾝﾊﾟ
109WSS4884 1 CLAMPER ｸﾗﾝﾊﾟ
110WSS4892 1 BLOCK ﾌﾞﾛｯｸ
111WSS4902 1 BLOCK ﾌﾞﾛｯｸ
112WSS4911 1 COVER ｶﾊﾞｰ
113WSS4921 1 COVER 蓋
114WSS4933 1 COVER 蓋
115WSS4941 1 COVER 蓋
116WSS4953 1 COVER 蓋
121K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ    M5X10L
122K5255T
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ    M3X6L
127W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
139H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X10L
141H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X6L
142W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-5-L
143H5304A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X25L
149WSS5250 1 PIN, PIVOT ﾋﾟﾝ 支点
153WSS5340 1 BLOCK ﾌﾞﾛｯｸ
154WSS5350 1 LEVER ﾚﾊﾞｰ
155WSS5360 1 BLOCK ﾌﾞﾛｯｸ
156WSS5370 1 LEVER ﾚﾊﾞｰ
157H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X15L
[注1.仕様選択部品]WSS4760(3ﾟ),WSS4781(4ﾟ),WSS5000(3.2ﾟ),WSS5020(2.4ﾟ),WSS5040(2.5ﾟ),WSS5060(3.07ﾟ),WSS5080(3.4ﾟ)
WSS5100(3.9ﾟ),WSS5120(3.95ﾟ),WSS5140(3.5ﾟ),WSS5310(3.4ﾟ)
[注2.仕様選択部品]AWSS8510(3ﾟ),AWSS8520(4ﾟ),AWSS8530(3.2ﾟ),AWSS8540(2.4ﾟ),AWSS8550(2.5ﾟ),AWSS8560(3.07ﾟ),AWSS8570(3.4ﾟ)
6-6
6.2.Board clamping unit(WSS) 基板クランプ
CP-642 PARTS LIST ver08
6.2.Board clamping unit(WSS) 基板クランプ
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No. QTY Description Rating Remarks
AWSS8580(3.9ﾟ),AWSS8590(3.95ﾟ),AWSS8600(3.5ﾟ),AWSS8610(3.45ﾟ)
[Note.1:(Specified part selection)]WSS4760(3ﾟ),WSS4781(4ﾟ),WSS5000(3.2ﾟ),WSS5020(2.4ﾟ),WSS5040(2.5ﾟ),WSS5060(3.07ﾟ),WSS5080(3.4ﾟ)
WSS5100(3.9ﾟ),WSS5120(3.95ﾟ),WSS5140(3.5ﾟ),WSS5310(3.4ﾟ)
[Note.2:(Specified part selection)]AWSS8510(3ﾟ),AWSS8520(4ﾟ),AWSS8530(3.2ﾟ),AWSS8540(2.4ﾟ),AWSS8550(2.5ﾟ),AWSS8560(3.07ﾟ),AWSS8570(3.4ﾟ)
AWSS8580(3.9ﾟ),AWSS8590(3.95ﾟ),AWSS8600(3.5ﾟ),AWSS8610(3.45ﾟ)
･
