番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No. QTY Description Rating Remarks
1AWPH9514 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-007
2AWPH9011 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-007
3WPH8291 20 SEAL ｼｰﾙ R012-007
4AWPH9524 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-010
5AWPH9021 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-010
6WPH8301 20 SEAL ｼｰﾙ R012-010
7AWPH9534 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-013
8AWPH9031 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-013
9WPH8311 20 SEAL ｼｰﾙ R012-013
10AWPH9545 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY M012-013
11AWPH9081 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し M012-013
12WPH8318 20 SEAL ｼｰﾙ M012-013
13AWPH9554 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-018
14AWPH9077 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-018
15WPH8320 20 SEAL ｼｰﾙ R012-018
16AWPH9563 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R016-025
17AWPH9125 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R016-025
18WPH8201 20 SEAL ｼｰﾙ R016-025
19AWPH9572 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R016-037
20AWPH9134 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R016-037
21WPH8211 20 SEAL ｼｰﾙ R016-037
22AWPH9583 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R020-025
23AWPH9041 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R020-025
24WPH8081 20 SEAL ｼｰﾙ R020-025
25AWPH9593 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY M020-025
26AWPH9098 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し M020-025
27WPH8081 20 SEAL ｼｰﾙ M020-025
28AWPH9602 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R020-037
29AWPH9050 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R020-037
30WPH8121 20 SEAL ｼｰﾙ R020-037
31AWPH9612 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S020-050
32AWPH9069 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し S020-050
33WPH8101 20 SEAL ｼｰﾙ S020-050
34AWPH9662 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S022-050
35AWPH9153 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し S022-050
36WPH8231 20 SEAL ｼｰﾙ S022-050
37AWPH9672 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B022-050
38AWPH9153 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し B022-050
39WPH8221 20 SEAL ｼｰﾙ B022-050
40AWPH9682 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S022-070
41AWPH9163 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し S022-070
42WPH8181 20 SEAL ｼｰﾙ S022-070
43AWPH9694 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B022-070
44AWPH9175 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し B022-070
1-2
1.Nozzles(WPH) ノズル一覧
CP-642 PARTS LIST ver08
1.Nozzles(WPH) ノズル一覧
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No. QTY Description Rating Remarks
45WPH8171 20 SEAL ｼｰﾙ B022-070
46AWPH9701 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-004
47AWPH9181 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-004
48WPH8330 20 SEAL ｼｰﾙ R012-004
1-3
1.Nozzles(WPH) ノズル一覧
CP-642 PARTS LIST ver08
1.Nozzles(WPH) ノズル一覧
2-1
2.Placing head,drum(WPH) プレーシングヘッド,ドラム
CP-642 PARTS LIST ver08
2.Placing head,drum(WPH) プレーシングヘッド,ドラム
6
3
67
5
68
4
65
56
10
9
8
1
5
68
67
2
6
11
12
13
14
14
79
80
81
7
61
68
18
19
20
18
27
75
71
55
24
21
58
57
70
22
23
90
25
57
94
92
28
77
57
93
95
51
96
83
56
65
84
85
注1
Note1
97
A
B
A
B
98
67
56
47
64
56
40
41
65
60
42
39
56
65
45
86
55
66
46
74
43
59
63
44
51
99
73
49
50
62
72
