ASYMTEK Quantum® Q-6800 Series Spares List

February 2024 4

PS2 GREASE,NSK LINEAR

BEARING

1

199560

BOX,11X6.5X2 WITH CHERRY

LOCKS

1

382827

PUMP,NSK GREASE

1

392455

NOZZLE,3MM NSK GREASE

1

392456

WIPER,10ct LINT FREE DURX 570

1

7282236

FRU, ASSY, MAIN AIR

REGULATOR, S-9XXN

6105624

SCREW, M5 X .8 X 8 SHCS

2

7245989

WASHER, M4,12MM OD

2

7220757

SCREW, M4 X 0.7, SOCKET X 10

2

388027

MAIN AIR REGULATOR

1

6120507

LARGE OD FLAT WASHER,M5,15MM

2

7251823

KIT, FRU, NANO CAMERA

UPGRADE, Q68

6651777

CAMERA, NANO M640, W/O

LICENSE

2

6143618

CABLE, ADAPTER, NANO-CAMERA

2

6126314

LENS EXTENSION,1.5MM,25MM ID

2

7212939

EXTENSION TUBE, 5MM

2

7243556

CD, S/W, FM 6.3.2.171, WIN10

2

6146351

KIT, 3MM, O-RING BELT

7238960

SCREW, M3 X. 05 FLAT

22

392120

SCREW, M4 X 0.7 SOCKET FLAT X

12

24

388012

SCREW, M4 X 0.7,SOCKET FLAT X

25, SS

4

7257530

SCREW, M4 X 0.7, SET, CUP X 10

2

388039

NUT, SQUARE, M4, 7 X 7 X 2

4

7207258

SHIM, SS, 4 X 8 X 1MM THICK

8

7208064

BELT, ORING, 3 X 2198, ESD

4

7237633

ASSY, O-RING BELT PULLEY

8

7237778

INSERT, BOTTOM, FLAT, O-RING

2

7238661

CONV RAIL INSRT, EDGE, O-RING

2

7238662

PULLEY, DRIVE, FLAT, ORING, CMP

2

7239006

KIT, Q-68XX 4MM BELT CNVYR

7238961

SCREW, M4 X 0.7 SOCKET FLAT X

12

24

388012

SCREW, M4 X 0.7,SOCKET FLAT X

25,SS

4

7257530

SCREW, M4 X 0.7, SET, CUP X 10

2

388039

NUT, SQUARE, M4, 7 X 7 X 2

4

7207258

BELT, FLAT 3.6 X 1.4 X 2340, ESD

4

7213126

RETAINER, BELT, CMP

8

7238733

ASSY, 4MM BELT PULLEY

8

7238967

KIT, Q-68XX 6MM BELT CNVYR

7238962

SCREW, M3X.05 FLAT

22

392120

SCREW, M4X0.7 SOCKET FLAT X 12

24

388012

SCREW,M4X0.7,SOCKET FLAT

X25,SS

4

7257530

SCREW, M4 X 0.7, SET, CUP X 10

2

388039

NUT,SQUARE,M4,7X7X2

4

7207258

BELT,FLAT,5.7X1.4X2350

4

7214245

RETAINER,BELT,CMP

8

7238733

ASSY,6MM BELT PULLEY

8

7238970

CONV RAIL INSERT,6MM FLAT BELT

2

7238973

KIT, X-Y-Z CABLES

7204437

CABLE, 30FT MECHANICAL

1

199986

CABLE, 27.0 FT, MECHANICAL

1

200210

CABLE, 54FT MECH, PRECISION

1

7202995

BOX, 11 X 6.5 X 2 WITH CHERRY

LOCKS

1

382827

ATS, FRU, PULLEY REPLCMNT,

Q68

7296336

ASYMTEK Quantum® Q-6800 Series Spares List

February 2024 5

SCREW, M6-1.0 X 35 SHCS, ALLOY

1

193127

SCREW, M6 BHCS X 35 BLK ALLOY

1

194535

CABLE, 54FT MECH, PRECISION

1

7202995

ASSY, X AXIS PULLEY

12

7237230

SPACER, PULLEY DRAGON

2

7237251

ASSY, Y AXIS LARGE PULLEY

1

7237260

ASSY, Y AXIS,PULLEY

10

7255499

ASSY, IDLE PULLEY

9

7255500

CABLE, 30FT MECHANICAL

1

199986

CABLE, 27.0 FT, MECHANICAL

1

200210

GREASE, MOLLY-GRAPH, 3 OZ

TUBE

1

198773

SHIM, SHORTENING, 1/4 ID X .03

THK

50

387950

NUT, HEX M6 X 1.0, SS

17

388086

WASHER, FLAT M6

2

388088

SCREW, M6 X 1.0 SOCKET X 16

6

7243615

SCREW, M6 X 1.0, SOCKET X 20, SS

7

388103

SCREW, M6 X 1.0, SOCKET X 20, SS

2

388103

SCREW, M6 X 1.0 SOCKET X 25, SS

2

388104

BUMPER, 0.23, GREY

2

7244905

STOP-IT, LU-15, THREADED

2

7238838

STOP-IT, LU-15, NUT BLOCK

2

7238839

FRU, FRONT PANEL KIT,S2&Q68

6652113

SWITCH,EMO ACTUATOR

1

198870

WASHER, FLAT M4

1

387998

SCREW, M3X.05 FLAT

1

392120

LABEL,E-STOP,16mm

1

7209411

BUSHING,OPEN/CLOSED,1.09D

1

7209414

PLUG,DOME,1.093 DIA,BLACK

1

7209415

SNAP,ESD FEMALE

1

7209416

GUARD,EMO CMP

1

7210753

SWITCH,EMO CONTACT BLOCK

1

198871

SWITCH,3P-NO,MOM,24V

LED,GREEN

1

7204788

SWITCH,2P-NC,MOM,BLACK FLUSH

1

7204789

USB-A MALE TO USB-A FEM,PNL MT

1

7225734

JACK,BANANA,INSULATED BLACK

1

7257497

NUT,M4,W/LOCKWASHER,ZPL-ST

1

7208192

FRU,BLKHD Q-DS KIT,S2&Q68

6652114

FITNG,Q-D BLKHD FEM 10-32 BLUE

1

195401

FITNG,Q-D BLKHD FEM 10-32 BLK

1

195402

FITTING,Q-D BLKHD,CPC

1

195525

FITT'G, 1/4Q-DISC X 10-32 UNC

1

383010

FITNG,Q-D BLKHD FEM,M5 CLEAR

1

7209918

FITNG,Q-D BLKHD FEM,GREEN

2

7201192

FRU,CONVEYOR WIDTH

REBUILD,Q6800

6654434

ASSY,PULLEY TIRE

6

7239008

SPACER,1/2ODX1/4IDX1/8LG

2

7239027

SPACER,SHAFT,1/2ODX1/4IDX3/8

3

7237769

SPACER,1/2ODX1/4IDX11/16LG

1

7237772

SCREW M6.10 BUTTON X30,SS

4

7244275

TURNBUCKLE,MECH.CABLE,M4

2

7237762

SCREW, M4X0.7X25MM SHCS, SS

1

388033

SCREW,M4X0.7,SET,CAPX25,SS

1

7253635

NUT,M4,W/LOCKWASHER,ZPL-ST

1

7208192

ASSY,MECHANICAL CABLE,1588MM

1

6654435

ASSY,MECHANICAL CABLE,1640MM

1

6654436

TIE WRAP, 20", 120 LB.

8

7279071

PULLEY,3MM PITCH,.25"ID

2

7239007

BLT,WDTH ADJ.,3MM PITCH,312MM

1

7239043

MOTOR,NEMA 23 STEPPER

W/CONN

1

7263550

SCREW, M4 X 0.7, SOCKET CAP,X8

4

388026

ASYMTEK Quantum® Q-6800 Series Spares List

February 2024 6

CABLE,CONVEYOR MOTOR FRONT

1

7238778

LEADSCREW,0.1"PITCHX625MM

1

7207858

PWA,HOME SENSOR

1

7207355

Conv Home Flag

1

7238994

FRU, ASSY,LHS,KEY,IL-065,Q68

6112655

ASSY,LHS,KEY,IL-065,700UM,Q68

1

6133181

CABLE, KEYENCE HS, CT, Q-68XX

1

6112682

CABLE, ADPTR, AMP-CT, LHS, IL-65,

Q-6800

1

6112683

ASSY, LASER HS AMP, Q-6800

1

6112656

SCREW, M4 X 0.7, SOCKET CAP,X8

4

388026

CLIP, WIRE HARNESS

2

387922

CABLE, ADPTR, CT-LHS, IL-65, Q-

6800

1

6112684

ASSY, HUB&POWSUP, E14, Q68

6133120

CABLE TIE,4",BLACK

1

382767

CLIP,WIRE HARNESS,1"DIA

1

7226307

NUT, HEX M4 X 0.7

1

7243842

SCREW, M4 X 0.7, SOCKET CAP,X8

1

388026

WIRE MARKERS,10AWG,#6

2

6105102

WIRE MARKERS,10AWG,#7

1

7257507

ADAPTER,USB TO CAN

1

7205214

CABLE,LAPTOP AC POWER

1

7243488

CABLE-P, USB, 6FT,REVERSIBLE A

TO B

1

6133114

PLATE,MOUNT,ACCESSORIES

1

7238705

CABLE,CAN INTERFACE STP

1

7238770

ADAPTOR,FTDI,RS232-USB

1

7253995

FERRITE,SNAP-ON,7MM DIA

1

7257597

LABEL,BLANK,SELF LAMINATE

2

7270901

ADAPTER,USB TO ETHERNET

1

7296110

HUB,USB,2.0,7 PORT

1

7296111

CBL TIE,STD,BLACK,24",HK & LP

1

7296112

CABLE,USB EXT,6FT,RIGHT ANGLE

1

7296808

ASSY,LIGHT BOX VOF,DRAGON

7238697

LOCTITE 222MS,50ML BOTTLE

1

7252898

CABLE TIE, 3/16" ROUND

1

387910

SCREW,M2X.40X6 FLTHD. PH. REC.

4

387957

SCREW,M2-0,4X6 SOCKET CAP

8

7275113

WASHER, FLAT M3

1

387964

SCREW, M3X6 BUTTON HEAD

1

7244697

ASSY,RGB LED

1

7213695

LENS,FRESNEL,RECT.LIGHTBOX

1

7214495

DIFFUSER,RECT.LIGHTBOX

1

7214496

BEAMSPLITTER,VOF LIGHTBOX

1

7214512

SCREW,FLAT,M2 X 0.4 X 4SST

2

7217764

BLOCK,VOF LIGHT BOX

1

7238890

SETTING,STAR LED LIGHTBOX

1

7238891

BLOCK,BEAMSPLITTER LIGHTBOX

1

7238892

SPR,Q68XX,DRAGON SERV

STATION

7279327

BOOT,VAC .120 ID OLIVE

1

381523

GENERATOR,VACUUM,PIAB M10

1

392234

FITTING,1/8NPT X DUAL-Y 1/4OD

1

392803

TUBING,PU,TR GRN 1/4"OD 1/8"ID

0.75

7242173

PLUG, ONE TOUCH

1

383428

O-RING, 1 7/8 OD X 1/16

1

381649

CABLE CLAMP, 1/8" ROUND BLACK

1

7244930

SCREW, M3X6 BUTTON HEAD

1

7244697

SCREW, M4X0.7, BUTTON HEAD, X8

2

388040

SCREW, M5X25 CUP END SET, SS

1

7275147

COUPLING, 3/8 TO 1/8 NPT

1

7203338

SCREW,THUMB,M3X16MM

2

7203341

ASSY,Z TACTILE,CERAMIC INSERT

1

7224748

BUSHING,TACTILE SENSOR

1

7237812
