1 1 Base Assy. Base KKU-1 102 19 18 19 47 40 28 40 27 47 47 18 47 47 30 44 49 10 44 8 9 43 38 12 44 53 7 2 13 30 46 16 15 45 41 36 17 42 46 16 45 15 17 41 36 44 44 44 42 14 17 50 44 44 55 29 39 56 51 48 6 4 35 3 35 57 58…
Contents
5 Magazine Section
Magazine Assy. ....................................................5-1
Shutter+Rack Lock ..............................................5-2
6 Hook Section
Hook-axis Assy. ...................................................6-1
Hook-axis sub Assy. / Hand Assy.(-2014/March) .6-2
Hook-axis sub Assy. / Hand Assy.(2014/April-) ....6-3
Hook-Base ...........................................................6-4
7 System Parts Section
System Parts .......................................................7-1
1 Base Section
Base Assy. ...........................................................1-1
2 Cover Section
Cover Assy. ..........................................................2-1
Cover Door ...........................................................2-2
3 Z-axis Section
Z-axis Assy. ..........................................................3-1
4 Rack Section / Pallet Section
Rack Assy. / Pallet Assy. ......................................4-1
KKU-1005
1
1
Base Assy.
Base
KKU-1102
19
18
19
47
40
28
40
27
47
47
18
47
47
30
44
49
10
44
8
9
43
38
12
44
53
7
2
13
30
46
16
15
45
41
36
17
42
46
16
45
15
17
41
36
44
44
44
42
14
17
50
44
44
55
29
39
56
51
48
6
4
35
3
35
57
58
5
35
35
40
54
52
17
14
42
50
52
15
16
46
45
14
42
15
16
46
45
50
41
36
31
41
33
32
34
40
21
23
44
26
45
45
22
37
40
20
25
23
24
52
41
36
50
52
14
2
2
38
8
43
38
9
2
38
41
11
43
8
43
10
44
49
44
59
8
1
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKU-M1102-00 PLATE, BASE 1
2 KKU-M1103-00 FOOT, LEVELING 4
3 KHF-M1105-00 PLATE I/O BOARD 1
4 KJM-M1106-00 BRACKET, RELAY 1
5 KHF-M1110-01 COVER, EL. 1
6 KHF-M1111-01 SHAFT, STAND 1
7 KKU-M1122-00 BRACKET 4
8 KJD-M1123-10 CASTER 4
9 KJM-M1124-00 PLATE, CASTER 2
10 KKU-M1125-00 BRACKET, CASTER 2
11 KKU-M1127-00 BRACKET, SUPPORT 1
12 KKU-M1129-00 BOLT, LEVELING 4
13 KKU-M1130-00 PLATE, BASE 2 1
14 KKU-M1131-00 HOLDER 4
15 KKU-M1132-00 STOPPER, A 4
16 KKU-M1133-00 STOPPER, B 4
17 KKU-M1138-00 CAM FOLLOWER 4
18 KKU-M1141-00 STAY, BASE 2
19 KKU-M1142-00 PLATE 2
20 KKU-M1151-00 HOLDER, SCREW FR. 1
21 KKU-M1152-00 HOLDER, SCREW RR. 1
22 KKU-M115C-00 FEED SCREW ASSY. 1
23 90933-01J801 BEARING 2
24 KKU-M1155-00 HOLDER, NUT 1
25 KKU-M115D-00 HANDLE ASSY. 1
26 KKU-M1158-00 PLATE, BRG. 1
27 KKU-M1159-00 HOLDER, HANDLE 1
28 KKU-M115B-00 PLATE, HNS. 1
29 KH2-M7101-00 VALVE 1 1
30 90K41-001070 STICKER, CAUTION 2
31 KKU-M1847-00 BRKT., DAMPER 1 1
32 KV7-M2651-00 DAMPER, STOPPER 1
33 KHW-M2654-00 PLATE , DAMPER 1
34 KHW-M2656-00 SPACER 2
35 90990-11J001 SCREW, PAN HEAD W/W 9
36 90990-21J001 PIN 4
37 90990-28J004 WASHER, PLAIN 1
38 90990-28J142 WASHER, PLAIN 4
39 91312-03030 BOLT HEX. SOCKET HEAD 4
40 91312-04008 BOLT HEX. SOCKET HEAD 10
41 91312-05010 BOLT HEX. SOCKET HEAD 10
42 91312-05025 BOLT HEX. SOCKET HEAD 8
43 91312-06008 BOLT HEX. SOCKET HEAD 16
44 91312-06012 BOLT HEX. SOCKET HEAD 38
45 91312-06020 BOLT HEX. SOCKET HEAD 12
46 91312-08025 BOLT HEX. SOCKET HEAD 4
47 92012-08012 BOLT, BUTTON HEAD 8
48 92902-04200 WASHER, PLAIN 2
49 92902-06200 WASHER, PLAIN 4
50 92902-08600 WASHER, PLAIN 4
51 90172-00J040 WASHER, EXTL. TOOTHED 2
52 95302-08600 NUT, HEXAGON 4
53 99712-20600 NUT, HEXAGON 4
54 $SL6-01 JOINT 1
55 $KM-11 MUFFLER 1
56 KHW-M8582-40 VALVE 1 1 Spare
57 90990-11J003 SCREW, PAN HEAD W/W 10 MG40142-2010/5/10
58 $NK-2N NYLON CLIP 10 MG40142-2010/5/10
59 UYD8-6 JOINT 1 For main bady divergence
1
2
Cover Assy.
Cover
KKU-1102
24
7
27
15
14
1
25
23
27
25
25
25
25
17
18
19
2
31
11
28
29
25
10
20
25>33
27
30
25
21
25
12
9
16
25
25
25
25
25
4
6
13
5
8
3
22
32
25
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKU-M1301-00 COVER, FRONT 1
2 KJM-M1302-00 FRONT COVER, UP 1
3 KJM-M1303-00 SIDE COVER, LOW 1
4 KKU-M1304-00 COVER, SIDE UPR. 1
5 KKU-M1307-00 BOX, SWITCH 1
6 KJM-M1308-00 COVER, TOP 1
7 KJM-M1309-00 COVER REAR, LOW 1
8 KKU-M1310-00 COVER, REAR UPR. 1
9 KKU-M1311-00 BRKT., INDICATOR 1
10 KHF-M1315-00 BRACKET HINGE 2
11 KKU-M1317-00 COVER 17 1
12 KHF-M1319-01 PLATE, BOARD 1
13 KJM-M1320-00 COVER 20 1
14 KKU-M1324-00 COVER, SIDE UPR. 2 1
15 KJM-M1325-00 SIDE COVER, LOW 1
16 KKU-M1326-00 COVER, HNS. 1
17 KKU-M1327-01 COVER, FRONT UPR. 1 1
18 KKU-M1328-00 COVER, FRONT UPR. 2 1
19 KKU-M1329-01 PLATE, JOINT 1
20 KG2-M1372-00 PIECE B, HINGE 2
21 K46-M1373-00 SHAFT, HINGE 2
22 KH1-M1396-00 WASHER 2
23 90990-11J001 SCREW, PAN HEAD W/W 1
24 90990-11J003 SCREW, PAN HEAD W/W 2
25
90990-12J001 SCREW, BIN. HEAD W/W 87 OK MGX0077-2010/11/19
90990-12J001 SCREW, BIN. HEAD W/W 83
26
27 91312-04008 BOLT HEX. SOCKET HEAD 6
28 91312-04020 BOLT HEX. SOCKET HEAD 2
29 91312-04035 BOLT HEX. SOCKET HEAD 2
30 92902-04200 WASHER, PLAIN 4
31 98502-03006 SCREW, PAN HEAD 2
32 90K41-000960 LABEL, ALERT 1
33 90990-12J006 SCREW, BIND HEAD W/W 4 MGX0077-2010/11/19
