22.2.防音カバー(WAF)
22.2.Noise reduction cover(WAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
6 WAF4920 2 BKT BKT FE
9 WAF6271 1 PLATE ﾌﾟﾚｰﾄ FE
19 WAF3400 2 COVER ｶﾊﾞｰ FE
29 WAF3010 1 DOOR 扉 FE
31 WAF3020 1 DOOR 扉 FE
32 WAF3030 1 DOOR 扉 FE
33 WAF3040 1 DOOR 扉 FE
34 AWAF8670 2 WINDOW 窓 OT
45 AWAF8660 2 WINDOW 窓 OT
46 WAF3200 4 HOLDER ﾎﾙﾀﾞ FE
47 WAF4202 8 HOLDER ﾎﾙﾀﾞ FE
48 WAF3210 4 HOLDER ﾎﾙﾀﾞ FE
71 WAF4582 4 BKT BKT FE
73 WAF4601 4 BKT BKT FE
74 WAF4632 4 BKT BKT FE
79 WAF4693 1 STOPPER ｽﾄｯﾊﾟ FE
80 WAF4703 1 BKT BKT FE
84 WAF4721 2 STOPPER ｽﾄｯﾊﾟ FE
86 WAF4773 1 STOPPER ｽﾄｯﾊﾟ FE
87 WAF4783 1 BKT BKT FE
109 H5069C 4 BALL CATCH ﾎﾞｰﾙ ｷｬｯﾁ TL-91-1 OT
110 T5004T 4 HANDLE 取手 THA-211 OT
111 H3133T 6 PLUG ﾌﾟﾗｸﾞ TM-90-9 OT
120 WAF6350 16 PULLEY ﾌﾟｰﾘ OT
121 WAF6340 32 PULLEY ﾌﾟｰﾘ OT
123 S31971 4
SW, LIMIT
SW ﾘﾐｯﾄ ZCK-Y07 OT
124 WAF4562 4 BKT BKT FE
125 WAF4572 4 BKT BKT FE
126 WAF4612 4 BKT BKT FE
127 WAF4623 4 BKT BKT FE
132 K5359E
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿       
M4X8L FE
133 N1085A
NUT, HEX
ﾅｯﾄ 六角         
M6 FE
135 N1079A
NUT, HEX
ﾅｯﾄ 六角         
M4 FE
137 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
138 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
CP-642ME PARTS LIST ver06
22 - 2 - 2
22.2.防音カバー(WAF)
22.2.Noise reduction cover(WAF)
22.2.防音カバー(WAF)
22.2.Noise reduction cover(WAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
139 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
141 W1045A
WASHER, FLAT
ﾜｯｼｬ 平         
4W-6 FE
142 W1044A
WASHER, FLAT
ﾜｯｼｬ 平         
4W-5 FE
145 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-6-H FE
151 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X15L FE
152 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X12L FE
154 H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X15L FE
155 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X12L FE
156 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X10L FE
160 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X8L FE
161 KPA0890 4 SEAL ｼｰﾙ PL
162 WAF6480 4 PLATE 銘板 PL
