30.カバー(WPZ)
30.Cover(WPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 WPZ2407 1 COVER ｶﾊﾞｰ FE
2 WPZ2412 1 SEAL ｼｰﾙ OT
3 WPZ2065 1 SEAL ｼｰﾙ OT
4 WPZ2254 1 COVER ｶﾊﾞｰ FE
5 WPZ2490 2 BOLT ﾎﾞﾙﾄ FE
6 WPZ2031 1 PLATE ﾌﾟﾚｰﾄ FE
7 WPZ3411 1 COVER ｶﾊﾞｰ FE
8 WPZ3403 1 SPACER ｽﾍﾟｰｻ FE
9 WPZ3312 1 COVER, REAR ｶﾊﾞｰ ﾘﾔｰ FE
18 AWPZ8010 1 COVER ｶﾊﾞｰ WPZ4122+WWM0210 OT
19 WPZ5140 1 BKT BKT FE
20 WPZ5133 1 COVER ｶﾊﾞｰ FE
21 WPZ4060 1 PLATE ﾌﾟﾚｰﾄ FE
22 WPZ4055 1 PLATE ﾌﾟﾚｰﾄ FE
23 GPZ0052 1 ARM ｱｰﾑ FE
24 GPZ0064 1 ARM ｱｰﾑ FE
29 T5014W 2 HANDLE, FLUSH 取手 埋込み THA-173-2 OT
30 WPZ3228 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
31 WPZ3130 3 SEAL ｼｰﾙ OT
33 WPZ3141 1 SEAL ｼｰﾙ OT
34 WPZ3460 1 NAMEPLATE 銘板 PL
35 AWPZ8021 1 PLATE ﾌﾟﾚｰﾄ WPZ3091+WWM0210 OT
36 WPZ3100 2 PLATE ﾌﾟﾚｰﾄ FE
37 WPZ3110 2 PLATE ﾌﾟﾚｰﾄ FE
38 WPZ3051 1 BKT BKT FE
39 WPZ3040 1 BKT BKT FE
40 WPZ3031 1 PLATE ﾌﾟﾚｰﾄ FE
41 S31970 2 SW, LIMIT SW ﾘﾐｯﾄ XCS-A501 OT
42 S31973 2 SW, LIMIT SW ﾘﾐｯﾄ XCS-Z03 OT
43 MPZ1310 2 BKT BKT FE
44 M1012B 2 MAGNET CATCH ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-272-2 OT
45 WPZ3062 1 BKT BKT FE
46 MPZ1201 1 BKT BKT FE
47 WPZ3072 2 STOPPER ｽﾄｯﾊﾟ FE
48 MPZ1171 2 PLATE ﾌﾟﾚｰﾄ FE
CP-642ME PARTS LIST ver06
30 - 2
30.カバー(WPZ)
30.Cover(WPZ)
30.カバー(WPZ)
30.Cover(WPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
49 GPZ0090 2 BKT BKT FE
50 CSPZ0124 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
51 WPZ4531 1 COVER ｶﾊﾞｰ FE
52 MPZ1411 8 HINGE 蝶番 FE
53 MPZ1550 1 PLATE ﾌﾟﾚｰﾄ FE
54 MPZ1640 2 PLATE ﾌﾟﾚｰﾄ FE
56 AWPZ8032 1 COVER ｶﾊﾞｰ WPZ3242+WWM0210 OT
57 T5006B 2 HANDLE 取手 THA-240-7 OT
58 GPZ0841 1 PLATE ﾌﾟﾚｰﾄ FE
59 WPZ3020 2 BKT BKT FE
60 MPZ1160 4 PIN ﾋﾟﾝ FE
61 MPZ1150 2 BKT BKT FE
62 H2026A 8 PIN, SNAP ﾋﾟﾝ ｽﾅｯﾌﾟ SSP-8 OT
63 T1068A 2 DAMPER ﾀﾞﾝﾊﾟ GS0683255A OT
64 A1004F 2 LEG, RUBBER 脚 ｺﾞﾑ TK-15 OT
65 MPZ1325 1 COVER ｶﾊﾞｰ FE
66 A1007T 2 LEG, RUBBER 脚 ｺﾞﾑ TK-2320 OT
67 H5273A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L FE
68 H5278A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X15L FE
69 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
70 H5294A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X30L FE
71 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
72 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
73 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L FE
74 H5307A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X40L FE
75 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L FE
76 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
78 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
80 H5304A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X25L FE
81 K5183A SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X6L FE
82 . SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X8L FE
83 . SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X8L FE
84 K5207A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X5L FE
85 K51711 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M5X6L FE
88 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
CP-642ME PARTS LIST ver06
30 - 3
30.カバー(WPZ)
30.Cover(WPZ)
30.カバー(WPZ)
30.Cover(WPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
89 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
90 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
91 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
92 W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
93 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
94 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
95 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
96 N1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8 FE
97 WQC6080 1 COVER ｶﾊﾞｰ FE
98 WQC6500 1 COVER ｶﾊﾞｰ FE
99 WPZ4071 1 BKT BKT FE
100 WPZ4080 2 WASHER ﾜｯｼｬ FE
103 WPZ5151 1 BKT, SUPPORT BKT, 支え FE
104 MPZ7050 1 NAMEPLATE 銘板 PL
105 WQC6510 1 BKT BKT FE
106 WPZ2520 4 SEAL ｼｰﾙ PL
107 MPZ6220 4 WASHER ﾜｯｼｬ FE
108 K5215C 4 SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M5X12L FE
109 W1001E 4 WASHER ﾜｯｼｬ M4 FE
110 W1001G 6 WASHER ﾜｯｼｬ M6 FE
111 H3080A 1 BUSHING, RUBBER ﾌﾞｯｼｭ ｺﾞﾑ 30MM OT
112 H5417A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M16X55L FE
113 H5419A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M16X70L FE
114 W1029A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ M16 FE
115 W1058T WASHER, FLAT ﾜｯｼｬ 平 16M/MX3.0X2.8(小形丸) FE
116 YWM0031 1 SEAL ｼｰﾙ English PL
117 YWM0051 1 SEAL ｼｰﾙ Japanese PL
118 YWM0070 1 SEAL ｼｰﾙ French PL
119 KPA0890 2 SEAL ｼｰﾙ PL
120 KPA0900 2 SEAL ｼｰﾙ Japanese/English PL
121 KPA0920 2 SEAL ｼｰﾙ English/French PL
CP-642ME PARTS LIST ver06
30 - 4
