41.1.英国向フェンス(オプション)(WAF)
41.1.UK fence(Option)(WAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 WAF5523 1 FENCE, SAFETY ﾌｪﾝｽ 安全 FE
2 WAF5070 1 PLATE ﾌﾟﾚｰﾄ FE
5 AWAF8540 2 COVER ｶﾊﾞｰ WAF1020+WWM0210 OT
6 WAF1080 4 RETAINER, COVER 押え ｶﾊﾞｰ AL
9 WAF1630 1 STAND ｽﾀﾝﾄﾞ FE
10 WAF5180 1 STAND ｽﾀﾝﾄﾞ FE
11 WAF5420 2 PLATE ﾌﾟﾚｰﾄ FE
12 WAF5100 4 STAND ｽﾀﾝﾄﾞ FE
13 GXZ2240 7 RETAINER, COVER 押え ｶﾊﾞｰ AL
15 GPZ2460 1 BKT BKT FE
16 WAF2160 1 BKT, RETAINER BKT 押え FE
17 H1073F 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL PCD345-01D-D24SP OT
18 S1056A 4 SILENCER ｻｲﾚﾝｻ AN101-01 OT
19 S2171A 6 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL6-01 OT
20 GPZ4221 1 BKT BKT OT
21 GPZ4290 1 COVER ｶﾊﾞｰ OT
22 GPZ4242 1 SPACER ｽﾍﾟｰｻ OT
23 S3197A 5 SW, LIMIT SW ﾘﾐｯﾄ XCK-J5970 OT
24 S3199A 5 SW, LIMIT SW ﾘﾐｯﾄ ZCK-Y09 OT
25 SZ42002 1 BOLT ﾎﾞﾙﾄ OT
26 M1003A 1 MAGNET ﾏｸﾞﾈｯﾄ KM025C OT
27 H2003T 2 SIGNAL, TOWER ｼｸﾞﾅﾙﾀﾜｰ SEF102AF-Y OT
29 AWEM-7301 1 BOX, SW BOX, SW OT
31 AWEE-7701 1 BOX TERMINAL BOX ﾀｰﾐﾅﾙ OT
33 H1018D 1 HANDLE ﾊﾝﾄﾞﾙ THA-299-Z OT
36 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
37 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X16L FE
38 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X16L FE
40 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L FE
41 H5340A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X16L FE
42 K5215A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M5X10L FE
43 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
44 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
45 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
46 W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
47 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
48 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
49 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
CP-642ME PARTS LIST ver06
41 - 1 - 2
41.1.英国向フェンス(オプション)(WAF)
41.1.UK fence(Option)(WAF)
41.1.英国向フェンス(オプション)(WAF)
41.1.UK fence(Option)(WAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
50 N1085A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0 FE
51 H5344A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X35L FE
52 H5296A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X40L FE
53 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
54 H5294A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X30L FE
55 WAF5610 2 RETAINER, COVER 押え ｶﾊﾞｰ AL
56 WAF5600 2 RETAINER, COVER 押え ｶﾊﾞｰ AL
57 WAF5550 2 RETAINER, COVER 押え ｶﾊﾞｰ AL
58 AWAF8640 1 COVER ｶﾊﾞｰ WAF5670+WWM0210 OT
59 AWAF8630 1 COVER ｶﾊﾞｰ WAF5660+WWM0210 OT
60 T5003N 4 HANDLE 取 手 THA-239-No7 OT
61 WAF0410 2 RETAINER, COVER 押え ｶﾊﾞｰ AL
62 AWAF8610 1 COVER ｶﾊﾞｰ WAF5640+WWM0210 OT
64 GXZ3020 8 RETAINER, COVER 押え ｶﾊﾞｰ AL
65 GXZ3120 4 MAGNET ﾏｸﾞﾈｯﾄ FE
66 GXZ3130 4 BKT BKT FE
67 GXZ3140 4 BKT BKT FE
68 GXZ3150 4 PLATE ﾌﾟﾚｰﾄ FE
70 AWAF8620 1 COVER ｶﾊﾞｰ WAF5650+WWM0210 OT
71 H5145H 6 BOLT, LEVELING ﾎﾞﾙﾄ ﾚﾍﾞﾘﾝｸﾞ TM-275-No3 FE
72 M1013H 4 MAGNET CATCH ﾏｸﾞﾈｯﾄ ｷｬｯﾁ TL-273-No1 OT
73 . 5 SEAL ｼｰﾙ STR13.5 PL
74 WAF0572 1 FENCE ﾌｪﾝｽ FE
75 WAF0582 1 FENCE ﾌｪﾝｽ FE
76 WAF0620 4 JOINT ｼﾞｮｲﾝﾄ FE
77 AGPZ8140 2 COVER ｶﾊﾞｰ GPZ4310+WWM0210 OT
78 GPZ4320 4 RETAINER, COVER 押え ｶﾊﾞｰ AL
79 WAF0840 2 BKT, FENCE BKT ﾌｪﾝｽ FE
80 WAF0850 2 PLATE, JOINT ﾌﾟﾚｰﾄ ｼﾞｮｲﾝﾄ FE
81 WAF5450 1 FENCE ﾌｪﾝｽ FE
82 WAF5461 1 FENCE ﾌｪﾝｽ 注1 Note 1(Option) FE
86 H5273A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L FE
87 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
88 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
89 W1042A WASHER, FLAT ﾜｯｼｬ 平 W4-3 FE
91 . SCREW, COUNTERSUNK 小ﾈｼﾞ 皿 M3X4L FE
92 WAF1310 2 BKT BKT FE
93 WAF1320 1 BKT BKT FE
CP-642ME PARTS LIST ver06
41 - 1 - 3
41.1.英国向フェンス(オプション)(WAF)
41.1.UK fence(Option)(WAF)
41.1.英国向フェンス(オプション)(WAF)
41.1.UK fence(Option)(WAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
94 WAF0380 2 BKT BKT FE
95 WAF1340 2 BKT BKT FE
97 WAF5530 2 COVER ｶﾊﾞｰ (H=950) FE
98 WAF0930 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ FE
99 WAF0940 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ FE
100 WAF0660 2 COVER ｶﾊﾞｰ (H=900∼965) FE
101 Y3033A 2 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KCH06-00 OT
102 WAF2150 2 BKT BKT FE
103 WAF5090 1 BKT, PIPING BKT 配線 FE
104 WAF5120 1 BKT, PIPING BKT 配線 FE
105 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L FE
111 GXZ2240 4 RETAINER, RAIL 押え ﾚｰﾙ AL
113 M6X10L SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 FE
114 MPZ6320 1 HOOK ﾌｯｸ FE
115 WAF5160 2 HOLDER ﾎﾙﾀﾞ FE
116 WAF5150 2 CLAMPER ｸﾗﾝﾊﾟ FE
117 . 2 KNOB, KNURLED ﾂﾏﾐﾛﾚｯﾄ KUM-36-M10 OT
118 H5343A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M8X30L FE
119 W1014A WASHER, CONICAL ﾜｯｼｬ皿 M-8-H FE
120 WAF5470 2 BKT, FENCE BKTﾌｪﾝｽ FE
121 WAF5540 2 RETAINER, COVER 押えｶﾊﾞｰ AL
122 WAF5560 1 RETAINER, COVER 押えｶﾊﾞｰ AL
123 WAF5570 1 RETAINER, COVER 押えｶﾊﾞｰ AL
124 WAF5580 1 RETAINER, COVER 押えｶﾊﾞｰ AL
125 WAF5620 2 RETAINER, COVER 押えｶﾊﾞｰ AL
126 AWAF8600 2 COVER ｶﾊﾞｰ WAF5630+WWM0210 OT
141 AWAF8650 1 COVER ｶﾊﾞｰ (Option) WAF5680+WWM0210 OT
142 GXD7050 2 HOOK ﾌｯｸ Handy terminal option FE
143 N4002A 2 SCREW ﾈｼﾞ M4X12 No.2 Handy terminal option FE
注1.手動幅替え用
Note 1 :
For manual change of the conveyor width.
CP-642ME PARTS LIST ver06
41 - 1 - 4
41.1.英国向フェンス(オプション)(WAF)
41.1.UK fence(Option)(WAF)
