15.1.第6 ST(画像処理)(WGC)
15.1.ST 6(Vision processing)(WGC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 K4012H 2 CABLE ｹｰﾌﾞﾙ DTXC-12P05 OT
2 K2008A 5 CAP ｷｬｯﾌﾟ BNC-BRI OT
3 K2001T 4 CAP ｷｬｯﾌﾟ HR10-7R-C OT
4 K131C 1 CAMERA, CCD ｶﾒﾗ CCD XC-75 OT
5 WGC0300 1 HOLDER ﾎﾙﾀﾞ FE
7 WGC0190 1 PLATE ﾌﾟﾚｰﾄ FE
8 WGC0182 1 BKT BKT FE
9 WGC0171 1 BKT BKT FE
10 WGC0031 2 SPACER ｽﾍﾟｰｻ PL
11 WGC0050 2 PLATE ﾌﾟﾚｰﾄ FE
12 WGC0060 4 BUSHING ﾌﾞｯｼｭ PL
13 WGC0070 4 WASHER ﾜｯｼｬ FE
14 WGC0043 1 BKT BKT FE
15 WGC0220 2 STOPPER ｽﾄｯﾊﾟ PL
16 WGC0232 1 BKT BKT FE
17 S5022A 4 SOCKET ｿｹｯﾄ FS-285W OT
18 MPG0162 2 PLATE ﾌﾟﾚｰﾄ FE
19 R1016A 2 LAMP ﾗﾝﾌﾟ FL4BLB OT
20 MPG1231 1 REFLECTING PLATE 反射板 FE
21 MPG0175 1 REFLECTING PLATE 反射板 FE
23 R4023C 1 LENS ﾚﾝｽﾞ FML-26016 OT
24 H5449D 1 BOX, PRISM BOX ﾌﾟﾘｽﾞﾑ MFPB2-1000 OT
25 H5057T 1 HOLDER, LIGHT ﾎﾙﾀﾞ ﾗｲﾄ FKPW25-2100FB OT
26 H5057Z 1 HOLDER, LIGHT ﾎﾙﾀﾞ ﾗｲﾄ FKPW25-2100LR OT
27 R10195 1 LAMP ﾗﾝﾌﾟ MFP32-2100 OT
28 H1004Z 3 LIGHT EMITTING BODY 発光体 MHF-50LII-214C OT
29 S2001T 3 SHUTTER ｼｬｯﾀ FSH-08NCC OT
30 WGC0112 1 STAND ｽﾀﾝﾄﾞ FE
31 WGC1060 1 COVER ｶﾊﾞｰ FE
32 AWGC8011 1 COVER ｶﾊﾞｰ WGC0163+BHPZ0170 OT
33 WGC0142 1 PLATE ﾌﾟﾚｰﾄ FE
34 T5012T 1 HANDLE 取手 THA-240(No.8) OT
35 M1010T 1 MAGNET CATCH ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-77 OT
36 T2127H 2 HINGE 蝶番 TH78SUS No.5 OT
39 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L FE
40 H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L FE
41 H5278A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X15L FE
42 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
CP-642ME PARTS LIST ver06
15 - 1 - 3
15.1.第6 ST(画像処理)(WGC)
15.1.ST 6(Vision processing)(WGC)
15.1.第6 ST(画像処理)(WGC)
15.1.ST 6(Vision processing)(WGC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
43 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L FE
44 H5291A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X18L FE
45 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
46 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
47 H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L FE
48 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L FE
49 H5327A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X30L FE
50 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
51 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
52 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
53 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
54 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
55 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
56 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
57 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
59 W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L FE
61 K5204A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M3X8L FE
62 K5208A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L FE
63 K5172A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M5X15L FE
64 N1076A NUT, HEX ﾅｯﾄ 六角 M3 P=0.5 FE
65 N1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8 FE
66 WGC0090 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ OT
68 WGC0241 1 BKT BKT FE
69 WGC0250 1 PLATE ﾌﾟﾚｰﾄ FE
70 H5341A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X20L FE
71 H5345A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X40L FE
72 W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
73 W1046A WASHER, FLAT ﾜｯｼｬ ﾋﾗ 4W-8 FE
76 WWZ0242 1 PLATE ﾌﾟﾚｰﾄ FE
77 WWZ0271 1 PLATE ﾌﾟﾚｰﾄ FE
78 K5049N 3 CONNECTOR ｺﾈｸﾀ F-H-D7S OT
79 K5049L 3 CONNECTOR ｺﾈｸﾀ F-H-D7B OT
80 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L FE
81 WGC1050 1 COVER, LOWER ｶﾊﾞｰ 下 FE
82 WGC4620 1 PLATE ﾌﾟﾚｰﾄ FE
83 WGC4650 1 HOLDER ﾎﾙﾀﾞ FE
84 K1133X 1 CAMERA, CCD ｶﾒﾗ CCD IK-542FS OT
85 R4040A 1 LENS ﾚﾝｽﾞ FML-37082 OT
CP-642ME PARTS LIST ver06
15 - 1 - 4
15.1.第6 ST(画像処理)(WGC)
15.1.ST 6(Vision processing)(WGC)
15.1.第6 ST(画像処理)(WGC)
15.1.ST 6(Vision processing)(WGC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
86 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
87 H5215A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M5X10L FE
88 MPG1400 1 SEAL ｼｰﾙ English PL
89 MPG1410 1 SEAL ｼｰﾙ French PL
CP-642ME PARTS LIST ver06
15 - 1 - 5
