New Functions in Setup Center 3.3
Support of Packaging Unit Chains With More Than 3 Packaging Units
20 Version Description SIPLACE Setup Center 3.3
5.5 Support of Packaging Unit Chains With More Than 3
Packaging Units
In the past Setup Center only supported packaging unit chains with a maximum length of 3 packaging
units (e. g. tape reels). Now, it is possible to manage packaging unit chains with a maximum of 30
packaging units.
With the support of the IPTE Multi Stick Feeder and the Tray Stack Feeder it was necessary to support
longer packaging unit chains as well.
In the Setup Center configuration settings it is now possible to allow chains with more than three
packaging units for normal feeders as well.
E.g. with a max. packaging unit chain length of four it would be possible to have a chain length of four
packaging units on one track at the station.
5.6 Blocking Tracks instead of Tearing Down Tracks
Setup Center 3.3 sets a lock on components, which are physically set-up on the line but are not included
in the currently downloaded Setup. Previous Setup Center Versions performed a teardown instead.
Now such tracks are only blocked in Setup Center and on the line. This means the verification status of
the component is still available in the SC DB. Hereby the information of the component on the specific
feeder and track remains untouched in the SC DB.
If such components are included again in a downloaded Setup later on, the blocked tracks are
automatically re-activated.
There is no need to repeat the setup verification again for such tracks.
This is a big improvement especially for customers using the Partial Setup Download feature in the
SIPLACE Pro Line Control GUI.
In the past components that were not present in the downloaded Setup were just torn down in Setup
Center. Later on, it was necessary to repeat the setup verification for such tracks.
In case components are set-up on the wrong tracks on the line such tracks are also only blocked and
not torn down.
NOTE:
Traceability customers using Setup Center 3.3 who want to use packaging unit chains with more
than three packaging units need to upgrade to Traceability 3.1 first.
Traceability 3.1 is a prerequisite for the use of packaging unit chains with more than three
packaging units. Otherwise, the traceability data will be incorrect.
New Functions in Setup Center 3.3
Support of MAT-Label Version 2.4 (ZVEI Sepc. V2.4)
Version Description SIPLACE Setup Center 3.3
21
5.7 Support of MAT-Label Version 2.4 (ZVEI Sepc. V2.4)
The MAT-Label V2.4 is supported in Setup Center 3.3 as defined in the ZVEI Spec Data Matrix Code
Label. It is also supported as PDF417 format.
Setup Center 3.3 delivers the fixed, predefined regular expression for the MAT-Label.
Setup Center stores the entire raw information of the Barcode and additionally extracts all data for which
Setup Center offers existing database attributes.
The following MAT label fragments are stored together with the relevant barcode fragments in Setup
Center:
The following MAT label fragments are not stored as single fields in the Setup Center database.
However, the contents of these MAT label fragments is not lost but it is stored in the
"RawComponentBarcode" field in the Setup Center database.
MAT Label Fragments Setup Center Barcode Fragments
Supplier-ID + Package-ID UniqueID
Customer Part Number Component
Quantity OriginalQuantity
Manufacturer Number Manufacturer
Date of Manufacturing ManufactureDate
Expiration Date ExpiryDate
Supplier-ID Supplier
Batch-No. #1 Batch
MS-Level MsdLevel
MAT Label Fragments Setup Center Database
Manufacture Part Number
RawComponentBarcode
Ordering Code
Manufacture Location
Revision Level / Index
Additional Part Information
RoHS
Purchase Order Number
Shipping Note Number
Package-ID
Batch-No. #2
Supplier Data
New Functions in Setup Center 3.3
Support of Datalogic 2D Barcode Reader
22 Version Description SIPLACE Setup Center 3.3
5.8 Support of Datalogic 2D Barcode Reader
With SC 3.3 the Datalogic 2D barcode reader PM8500 is supported. The new barcode reader can read
2D as well as 1D barcodes.
5.9 Changing Fill Level of Previous Reel During Refill on the
Machine
Changing fill level of previous reel during refill on the machine.
During a component refill action on the line it is now possible to change the fill level of the previous reel
on the refilled track via the scanner (changing the length of previous reel).
5.10 MES-Process Interlocking Supported in Setup Center
An external Manufacturing Execution System (MES) can block and unblock material lots managed in
Setup Center.
For the whole MES-Process Interlocking solution also Traceability 3.1 and OIB 2.1 is required.
The MES Process Interlocking feature requires a license for each SIPLACE line.
