Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts) Bildtafel (Figure) 29 Ausgabe (Edition) 11-03 Stamm Nr. Master Code Bezeichnung / Designation Stck. Qty. Pos.-Nr. Pos. No. Seiten-Nr. Page No. A rtik…

100%1 / 616
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 29
A
usgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Doppeltransport feste Seite links / Dual conveyor, fixed rail left
Order
137
24000053S01
2
29-16
ERILLENKUGELLAGER 5*11*5 685 2Z
DEEP-GROOVE BALL BEARING
138
00200342-01
4
29-15
EDRUCKFEDER 0,8*8,8*32 V2A
COMPRESSION SPRING VD-125
139
00200334-01
2
29-16
ENADELHUELSE 6*10*9 HK0609 ST
NEEDLE SLEEVE
140
00309407-01
4
29-15
SENKSCHRAUBE M4*6 DIN963
SLOTTED COUNTERSUNK HEAD SCREW
141
00317730-01
4
29-15
EDRUCKFEDER 1,2*13*57,7 V2A
PRESSURE SPRING 1,2*13*57,7 V2A
142
00317682-01
4
29-15
GEGENHALTER
RETAINER
143
00316017-02
12
29-15
EFUEHRUNGSLEISTE (73MM), RECHTS
GUIDE RAIL POS.27 WITH BALL BEARING
144
00327650-01
12
29-20
LP-FUEHRUNG FUER BEIDSEITIGE VERWENDUNG
PCB GUIDE FOR DOUBLE-SIDED USE
145
00311015-01
12
29-20
ZYLINDERSTIFT 3H8*5,6 A2
PARALLEL PIN
146
00200335S01
12
29-20
ERILLENKUGELLAGER DIN625 3*8*3 619/3-2Z
DEEP-GROOVE BALL BEARING
147
00200345-01
12
29-20
PASSCHEIBE 3*4,5*0,1 BLAESSINGER
ADJUSTING SHIM BLAESSINGER
148
00327999-01
4
29-15
LP-FUEHRUNG EICHTAUFN MA-NULLP KOMPLETT
PCB-GUIDE CALIBRATING DEV. MOUNT MC-ZERO
149
00327144-01
4
29-20
LP-FUEHRUNG EICHTEILAUFN MA-NULLPUNKT
PCB-GUIDE CALIBRATING DEV. MOUNT MC-ZERO
150
00316024-01
8
29-20
*ZYLINDERSTIFTE DM3H8X5,6 +-0,1
PARALLEL PINS DM3H8X5.6 +-0.1
151
00200335S01
8
29-20
ERILLENKUGELLAGER DIN625 3*8*3 619/3-2Z
DEEP-GROOVE BALL BEARING
152
00200345-01
8
29-20
PASSCHEIBE 3*4,5*0,1 BLAESSINGER
ADJUSTING SHIM BLAESSINGER
153
00317829-01
8
29-20
POSITIONSMARKE
POSITION MARK
154
00332534-02
2
29-15
LP-FUEHRUNG MITTE KOMPLETT
LP-GUIDE CENTER KOMPLETE
155
00332535-02
2
29-20
LP-FUEHRUNG MITTE F.BEIDS.VERWENDUNG
PCB GUIDE MIDDLE FOR DOUBLE-SIDED USE
156
00200344-01
16
29-20
ZYLINDERSTIFT 3H8*6 DIN7 A2
PARALLEL PIN
157
00200335S01
16
29-20
ERILLENKUGELLAGER DIN625 3*8*3 619/3-2Z
DEEP-GROOVE BALL BEARING
158
00200345-01
16
29-20
PASSCHEIBE 3*4,5*0,1 BLAESSINGER
ADJUSTING SHIM BLAESSINGER
29 47 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 29
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Doppeltransport feste Seite links / Dual conveyor, fixed rail left
Order
159
00332323-01
4
29-15
ELP-TRANSPORT MITTE S50 CASSETTE 3
PC-BOARD CONVEYER CENTER S50 CASSETTE
160
00330524-01
4
29-18
LAGER 2 FUER NIEDERHALTER LP-TR. S50
BEARING 2 F. PRESSURE PAD PCB-TRANP. S50
161
00200335S01
16
29-18
ERILLENKUGELLAGER DIN625 3*8*3 619/3-2Z
DEEP-GROOVE BALL BEARING
162
00200219-01
16
29-18
ZYLINDERSTIFT 3H8*8 DIN7 A2
PARALLEL PIN
163
00200345-01
16
29-18
PASSCHEIBE 3*4,5*0,1 BLAESSINGER
ADJUSTING SHIM BLAESSINGER
164
00330430-01
2
29-16
GLEITSTREIFEN FUER NIEDERHALTER LPH S50
SLID.STRIPE FOR HOLD-DOWN DEVICE LPH S50
165
00330465-01
4
29-15
GLEITSTREIFEN 2 FUER NIEDERHALTER LPTS50
SLID. STRIPE 2 FOR HOLD-DOWN DEV. LPTS50
166
00328305S01
2
29-15
EKIPPHEBEL LINKS, KOMPLETT
ROCKING LEVER LEFT SIDE COMPLETE
167
00317681-03
2
29-21
EKIPPHEBEL, LINKS
ROCKING LEVER LEFT
168
00095619-01
2
29-21
ZYLINDERSTIFT 4M5*14 DIN6325
PARALLEL PIN 4M5*14
169
00200195-01
2
29-21
ESCHEIBE
WASHER
170
24000053S01
2
29-21
ERILLENKUGELLAGER 5*11*5 685 2Z
DEEP-GROOVE BALL BEARING
171
00200334-01
2
29-21
ENADELHUELSE 6*10*9 HK0609 ST
NEEDLE SLEEVE
172
00329526-01
2
29-17
EZAHNRIEMEN LP-TRANSPORT 400 S50
TOOTHED BELT LP-TRANSOPRT
173
00327878-01
2
29-15
ERIEMENUMLENKUNG B,VERSCHIEBBAR
BELT REVERSE, B PUSHABLE
174
00328269-01
2
29-19
PLATTE
PLATE
175
00200194-01
2
29-19
ESYNCHRONSCHEIBE AL 13 T5/13-0 N.ZCHNG.
SYNCHRONIZING DISK AL13T5/13-0
176
00200334-01
2
29-19
ENADELHUELSE 6*10*9 HK0609 ST
NEEDLE SLEEVE
177
00200178-01
2
29-19
EBOLZEN
BOLT
178
00300558-01
2
29-19
EDU-SCHEIBE
DU DISC
179
00200195-01
2
29-19
ESCHEIBE
WASHER
180
00095304-01
2
29-19
SENKSCHRAUBE M3*6 DIN965
SLOTTED COUNTERSUNK HEAD SCREW
29 48 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 29
A
usgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Doppeltransport feste Seite links / Dual conveyor, fixed rail left
Order
181
00332329-01
2
29-15
GLEITSTREIFEN F. NIEDERHALTER
SLIDING STRIPE F. HOLDING-DOWN DEVICE
182
00332322-01
2
29-15
LP-TRANSPORT MITTE S50 CASSETTE 2
PC-BOARD CONVEYER CENTER S50 CASSETTE
183
00330523-01
2
29-18
LAGER 3 FUER NIEDERHALTER LP-TRP. S50
BEARING 3 F. PRESSURE PAD PCB-TRANP. S50
184
00200335S01
8
29-18
ERILLENKUGELLAGER DIN625 3*8*3 619/3-2Z
DEEP-GROOVE BALL BEARING
185
00200219-01
8
29-18
ZYLINDERSTIFT 3H8*8 DIN7 A2
PARALLEL PIN
186
00200345-01
8
29-18
PASSCHEIBE 3*4,5*0,1 BLAESSINGER
ADJUSTING SHIM BLAESSINGER
187
00333686-01
2
29-16
ENIEDERHALTER 2 LP-TRANSPORT S50 LPH S50
PRESSURE PAD 2 PCB CONVEYOR S50 LPH S50
188
00345979-01
2
29-17
RIEMENFUEHRUNGSBLECH MITTE LPH S50
BELT GUIDE PLATE MIDDLE LPH S50
189
00845014-01
4
29-17
ZYLINDERSCHRAUBE M3*8 DIN912
HEXAGON SOCKET HEAD CAP SCREW
198
00331949-02
2
29-14
LP-TRANSPORT MITTE S50 WANGE 2
PCB CONVEYOR MIDDLE S50 SIDE PANEL 2
199
00330372-01
2
29-22
WANGE MITTE 2 LP-TRANSPORT S50
SIDE PANEL MIDDLE 2 PCB-CONVEYOR S50
200
00329191-01
2
29-22
ELP-NIEDERHALTER, S50
PCB PRESSURE PAD S50
201
00332321-01
2
29-23
ELP-TRANSPORT MITTE S50 CASSETTE 1
PC-BOARD CONVEYER CENTER S50 CASSETTE
206
00303193-01
20
29-22
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
207
00329522-01
4
29-24
EZAHNRIEMEN LP-TRANSPORT 495 S50
TOOTHED BELT LP-TRANSOPRT
208
00200345-01
24
29-22
PASSCHEIBE 3*4,5*0,1 BLAESSINGER
ADJUSTING SHIM BLAESSINGER
209
00200338-01
4
29-22
ERILLENKUGELLAGER 9*26*8 629-2Z
BALL BEARING 9 * 26 * 8 629-2Z
210
00317683-02
4
29-23
ELAGERACHSE 2
BEARING AXIS 2
211
00333708-01
6
29-22
ACHSE FUER FUEHRUNGSLAGER LPH S50
AXIS FOR GUIDE BEARING LPH S50
212
00095485-01
4
29-22
SICHERUNGSRING 9*1 DIN471
RETAINING RING
213
00095304-01
24
29-22
SENKSCHRAUBE M3*6 DIN965
SLOTTED COUNTERSUNK HEAD SCREW
214
00327902-01
12
29-22
DU-STREIFEN 1MM DICK
DU STRIP 1MM THICKNESS
29 49 -
