Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 35
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Portalverteiler / Portal distributor
Order
23
00335140-01
2
35-3
EPORTALKABEL 2/4: CAN-BUS / BE-LP-KAMERA
PORTAL CABLE 2/4: CAN-BUS / BE-LP-CAMERA
24
00335141-01
2
35-3
EPORTALKABEL 2/4: SPUR X-ACHSE
GANTRY CABLE 2/4: TRACK X-AXIS
25
00335142-01
2
35-3
EPORTALKABEL 2/4: SPUR/MOTOR Z/DP-ACHSE
GANTRY CABLE 2/4: TRACK/MOTOR Z/DP-AXIS
26
00335143-01
2
35-3
EPORTALKABEL 2/4: SPUR/MOTOR STERN-ACHSE
GANTRY CABLE 2/4: TRACK/MOTOR STAR-AXIS
27
00335144-01
2
35-3
EPORTALKABEL 2/4: SPUR Y / MOTOR X-ACHSE
PORTAL CABLE 2/4: TRACK Y / MOTOR X-ACHSE
28
00335145-01
2
35-3
EPORTALKABEL 2/4: SPUR Y / MOTORX/Y-ACHSE
PORTAL CABLE 2/4: TRACK Y / MOTORX/Y-ACHSE
29
00335146-01
2
35-3
EPORTALKABEL 2/4: SPUR Y / MOTORX/Y-ACHSE
PORTAL CABLE 2/4: TRACK Y / MOTORX/Y-ACHSE
30
00335147-02
1
35-3
KABEL HS50: MOTOR X2-ACHSE
CABLE HS50: MOTOR X2-AXIS
31
00335149-02
1
35-3
KABEL HS50: MOTOR Y2-ACHSE
CABLE HS50: MOTOR Y2-AXIS
32
00335150-02
1
35-3
KABEL HS50: MOTOR STERN2-ACHSE
CABLE HS50: MOTOR STAR2-AXIS
33
00335151-01
1
35-3
KABEL HS50: MOTOR/TACHO Z2-ACHSE
CABLE HS50: MOTOR/TACHO Z2-AXIS
34
00335152-01
1
35-3
KABEL HS50: MOTOR/TACHO DP2-ACHSE
CABLE HS50: MOTOR/TACHO DP2-AXIS
35
00335153-01
1
35-3
KABEL HS50: CRASH-SIGNAL PORTAL 2
CABLE HS50: CRASH SIGNAL PORTAL 2
36
00335159-01
1
35-3
KABEL HS50: SPURSIGNALE X2-MOTOR
CABLE HS50: TRACK SIGNALS X2-MOTOR
37
00335160-01
1
35-3
KABEL HS50: SPURSIGNALE Y2-MOTOR
CABLE HS50: TRACK SIGNALS Y2-MOTOR
38
00335161-01
1
35-3
KABEL HS50: SPURSIGNALE STERN2-MOTOR
CABLE HS50: TRACK SIGNALS STAR2-MOTOR
39
00335163-01
1
35-3
KABEL HS50: SPURSIGNALE Z2-MOTOR
CABLE HS50: TRACK SIGNALS Z2-MOTOR
40
00335164-01
1
35-3
KABEL HS50: SPURSIGNALE DP2-MOTOR
CABLE HS50: TRACK SIGNALS DP2-MOTOR
41
00335165-01
1
35-3
KABEL HS50: BE/LP-KAMERA PORTAL 2
CABLE HS50: COMP./PCB-CAMERA PORTAL 2
42
00335172-02
1
35-4
KABEL HS50: MOTOR X3-ACHSE
CABLE HS50: MOTOR X3-AXIS
43
00335174-02
1
35-4
KABEL HS50: MOTOR Y3-ACHSE
CABLE HS50: MOTOR Y3-AXIS
44
00335175-02
1
35-4
KABEL HS50: MOTOR STERN3-ACHSE
CABLE HS50: MOTOR STAR3-AXIS
35 8 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 35
A
usgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Portalverteiler / Portal distributor
Order
45
00335176-01
1
35-4
KABEL HS50: MOTOR/TACHO Z3-ACHSE
CABLE HS50: MOTOR/TACHO Z3-AXIS
46
00335177-01
1
35-4
KABEL HS50: MOTOR/TACHO DP3-ACHSE
CABLE HS50: MOTOR/TACHO DP3-AXIS
47
00335178-01
1
35-4
KABEL HS50: CRASH-SIGNAL PORTAL 3
CABLE HS50: CRASH SIGNAL PORTAL 3
48
00335184-01
1
35-4
KABEL HS50: SPURSIGNALE X3-MOTOR
CABLE HS50: TRACK SIGNALS X3-MOTOR
49
00335185-01
1
35-4
KABEL HS50: SPURSIGNALE Y3-MOTOR
CABLE HS50: TRACK SIGNALS Y3-MOTOR
50
00335186-01
1
35-4
KABEL HS50: SPURSIGNALE STERN3-MOTOR
CABLE HS50: TRACK SIGNALS STAR3-MOTOR
51
00335187-01
1
35-4
KABEL HS50: SPURSIGNALE Z3-MOTOR
CABLE HS50: TRACK SIGNALS Z3-MOTOR
52
00335188-01
1
35-4
KABEL HS50: SPURSIGNALE DP3-MOTOR
CABLE HS50: TRACK SIGNALS DP3-MOTOR
53
00335189-01
1
35-4
KABEL HS50: BE/LP-KAMERA PORTAL 3
CABLE HS50: COMP./PCB-CAMERA PORTAL 3
54
00335190-02
1
35-5
KABEL HS50: MOTOR X4-ACHSE
CABLE HS50: MOTOR X4-AXIS
55
00335192-02
1
35-5
KABEL HS50: MOTOR Y4-ACHSE
CABLE HS50: MOTOR Y4-AXIS
56
00335193-02
1
35-5
KABEL HS50: MOTOR STERN4-ACHSE
CABLE HS50: MOTOR STAR4-AXIS
57
00335194-01
1
35-5
KABEL HS50: MOTOR/TACHO Z4-ACHSE
CABLE HS50: MOTOR/TACHO Z4-AXIS
58
00335195-01
1
35-5
KABEL HS50: MOTOR/TACHO DP4-ACHSE
CABLE HS50: MOTOR/TACHO DP4-AXIS
59
00335196-01
1
35-5
KABEL HS50: CRASH-SIGNAL PORTAL 4
CABLE HS50: CRASH SIGNAL PORTAL 4
60
00335202-01
1
35-5
KABEL HS50: SPURSIGNALE X4-MOTOR
CABLE HS50: TRACK SIGNALS X4-MOTOR
61
00335203-01
1
35-5
KABEL HS50: SPURSIGNALE Y4-MOTOR
CABLE HS50: TRACK SIGNALS Y4-MOTOR
62
00335204-01
1
35-5
KABEL HS50: SPURSIGNALE STERN4-MOTOR
CABLE HS50: TRACK SIGNALS STAR4-MOTOR
63
00335205-01
1
35-5
KABEL HS50: SPURSIGNALE Z4-MOTOR
CABLE HS50: TRACK SIGNALS Z4-MOTOR
64
00335206-01
1
35-5
KABEL HS50: SPURSIGNALE DP4-MOTOR
CABLE HS50: TRACK SIGNALS DP4-MOTOR
65
00335207-01
1
35-5
KABEL HS50: BE/LP-KAMERA PORTAL 4
CABLE HS50: COMP./PCB-CAMERA PORTAL 4
66
00335316-01
1
35-3
KABEL HS50: CAN-BUS1 KOPPL.2-PORTALV.2
CABLE HS50: CAN-BUS1 COUPLER2-PORTAL D.2
35 9 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 35
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Portalverteiler / Portal distributor
Order
67
00335317-01
1
35-2
KABEL HS50: CAN-BUS1 PORTALVERTEILER 2-1
CABLE HS50: CAN-BUS1 PORTAL DISTRIB. 2-1
68
00335318-01
1
35-2
EKABEL HS50: CAN-BUS1 PORTALV.1 - KOPPL.1
CABLE HS50: CAN-BUS1 PORTAL D.1-COUPL.1
69
00335320-01
1
35-4
KABEL HS50: CAN-BUS1 KOPPL.3-PORTALV.3
CABLE HS50: CAN-BUS1 COUPLER3-PORTAL D.3
70
00335321-01
1
35-4
KABEL HS50: CAN-BUS1 PORTALVERTEILER 3-4
CABLE HS50: CAN-BUS1 PORTAL DISTRIB. 3-4
71
00335322-01
1
35-5
KABEL HS50: CAN-BUS1 PORTALV.4 - KOPPL.4
CABLE HS50: CAN-BUS1 PORTAL D.4-COUPL.4
00337853-02
1EKABELBAUM PORTALVERTEILER HS50
CABLE TREE PORTAL DISTRIBUTOR HS50
72
00335228-02
1
35-2
KABEL HS50: SPEISUNG PORTALVERTEILER 1
CABLE S50: POWER PORTAL DISTRIBUTOR 1
73
00335229-02
1
35-3
KABEL HS50: SPEISUNG PORTALVERTEILER 2
CABLE S50: POWER PORTAL DISTRIBUTOR 2
74
00335230-02
1
35-4
KABEL HS50: SPEISUNG PORTALVERTEILER 3
CABLE S50: POWER PORTAL DISTRIBUTOR 3
75
00335231-02
1
35-5
KABEL HS50: SPEISUNG PORTALVERTEILER 4
CABLE S50: POWER PORTAL DISTRIBUTOR 4
76
00335249-02
1
35-2
KABEL HS50: KAMERABELEUCHTUNG PORTAL 1
CABLE S50: CAMERA ILLUMINATION PORTAL 1
77
00335250-02
1
35-2
KABEL HS50: SPG-VERSORGUNG SCHRITTMOTOR1
CABLE HS50: POWER SUPPLY STEP. MOTOR 1
78
00335251-02
1
35-3
KABEL HS50: KAMERABELEUCHTUNG PORTAL 2
CABLE HS50: CAMERA ILLUMINATION PORTAL 2
79
00335252-02
1
35-3
KABEL HS50: SPG-VERSORGUNG SCHRITTMOTOR2
CABLE HS50: POWER SUPPLY STEP. MOTOR 2
80
00335253-02
1
35-4
KABEL HS50: KAMERABELEUCHTUNG PORTAL 3
CABLE HS50: CAMERA ILLUMINATION PORTAL 3
81
00335254-02
1
35-4
KABEL HS50: SPG-VERSORGUNG SCHRITTMOTOR3
CABLE HS50: POWER SUPPLY STEP. MOTOR 3
82
00335255-02
1
35-5
KABEL HS50: KAMERABELEUCHTUNG PORTAL 4
CABLE HS50: CAMERA ILLUMINATION PORTAL 4
83
00335256-02
1
35-5
KABEL HS50: SPG-VERSORGUNG SCHRITTMOTOR4
CABLE HS50: POWER SUPPLY STEP. MOTOR 4
84
00335116-01
1
35-2
KABEL HS50: TACHO X1-ACHSE
CABLE HS50: TACHO X1-AXIS
85
00335148-01
1
35-3
KABEL HS50: TACHO X2-ACHSE
CABLE HS50: TACHO X2-AXIS
86
00335173-01
1
35-4
KABEL HS50: TACHO X3-ACHSE
CABLE HS50: TACHO X3-AXIS
87
00335191-01
1
35-5
KABEL HS50: TACHO X4-ACHSE
CABLE HS50: TACHO X4-AXIS
35 10 -
