Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts) Bildtafel (Figure) 43 Ausgabe (Edition) 11-03 Stamm Nr. Master Code Bezeichnung / Designation Stck. Qty. Pos.-Nr. Pos. No. Seiten-Nr. Page No. A rtik…
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 43
A
usgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Kabelliste / Cable list
Order
100
00335205-01
1
43-11
KABEL HS50: SPURSIGNALE Z4-MOTOR
CABLE HS50: TRACK SIGNALS Z4-MOTOR
101
00335206-01
1
43-12
KABEL HS50: SPURSIGNALE DP4-MOTOR
CABLE HS50: TRACK SIGNALS DP4-MOTOR
54
00335207-01
1
43-9
KABEL HS50: BE/LP-KAMERA PORTAL 4
CABLE HS50: COMP./PCB-CAMERA PORTAL 4
37
00335211-01
1
43-13
KABEL HS50: SPEISUNG PC
CABLE HS50: POWER PC
38
00335212-01
1
43-13
KABEL HS50: SPEISUNG MONITOR 1
CABLE HS50: POWER MONITOR 1
39
00335213-01
1
43-13
KABEL HS50: SPEISUNG MONITOR 2
CABLE HS50: POWER MONITOR 2
43
00335219-01
1
43-13
KABEL HS50: UNGEREGELTE DC-SPANNUNG
CABLE HS50: UNREGULATED DC-VOLTAGE
44
00335221-02
1
43-13
KABEL HS50: STEUERSIGNALE STROMVERSORG.
CABLE HS50: CONTROL SIGNALS POWER SUPPLY
45
00335223-01
1
43-13
KABEL HS50: SSK PERIPHERIE
CABLE HS50: SSK PERIPHERY
46
00335224-02
1
43-13
KABEL HS50: POWER PXY
CABLE HS50: P150V
47
00335225-02
1
43-13
KABEL HS50: POWER NXY
CABLE HS50: N150V
48
00335226-02
1
43-13
KABEL HS50: HAUPTERDE
CABLE HS50: MAIN GROUND
72
00335228-02
1
43-24
KABEL HS50: SPEISUNG PORTALVERTEILER 1
CABLE S50: POWER PORTAL DISTRIBUTOR 1
73
00335229-02
1
43-25
KABEL HS50: SPEISUNG PORTALVERTEILER 2
CABLE S50: POWER PORTAL DISTRIBUTOR 2
74
00335230-02
1
43-26
KABEL HS50: SPEISUNG PORTALVERTEILER 3
CABLE S50: POWER PORTAL DISTRIBUTOR 3
75
00335231-02
1
43-27
KABEL HS50: SPEISUNG PORTALVERTEILER 4
CABLE S50: POWER PORTAL DISTRIBUTOR 4
99
00335232-02
1
43-22
KABEL S50: SPEISUNG RING
CABLE S50: POWER RING
100
00335235-02
1
43-23
KABEL HS50: SPEISUNG GURTSCHNEIDER 1
CABLE S50: POWER TAPE CUTTER 1
101
00335236-02
1
43-23
KABEL HS50: SPEISUNG GURTSCHNEIDER 2
CABLE S50: POWER TAPE CUTTER 2
102
00335237-02
1
43-23
KABEL HS50: SPEISUNG GURTSCHNEIDER 3
CABLE S50: POWER TAPE CUTTER 3
103
00335238-02
1
43-23
KABEL HS50: SPEISUNG GURTSCHNEIDER 4
CABLE S50: POWER TAPE CUTTER 4
104
00335240-02
1
43-23
KABEL HS50: SPANNUNGSVERSORGUNG LUEFTER
CABLE S50: POWER SUPPLY FAN
43 35 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 43
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Kabelliste / Cable list
Order
55
00335241-01
1
43-10
KABEL S50: GEREGELTE DC SPANNUNG
CABLE S50: REGULATED DC-VOLTAGE
56
00335242-01
1
43-10
KABEL S50: SPEISUNG DC/DC (48V) WANDLER
CABLE S50: POWER DC/DC (48V) CONVERTER
105
00335244-02
1
43-19
KABEL HS50: SPEISUNG PERPHERIE BUCHSE 1
CABLE S50: POWER PERIPHERY BUSH 1
106
00335245-02
1
43-20
KABEL HS50: SPEISUNG PERPHERIE BUCHSE 2
CABLE S50: POWER PERIPHERY BUSH 2
107
00335246-02
1
43-21
KABEL HS50: SPEISUNG PERPHERIE BUCHSE 3
CABLE S50: POWER PERIPHERY BUSH 3
108
00335247-02
1
43-22
KABEL HS50: SPEISUNG PERPHERIE BUCHSE 4
CABLE S50: POWER PERIPHERY BUSH 4
109
00335248-02
1
43-22
KABEL HS50: STEUERSIGNALE SEKTOR4
CABLE S50: CONTROL SIGNALS SECTOR 4
76
00335249-02
1
43-24
KABEL HS50: KAMERABELEUCHTUNG PORTAL 1
CABLE S50: CAMERA ILLUMINATION PORTAL 1
77
00335250-02
1
43-24
KABEL HS50: SPG-VERSORGUNG SCHRITTMOTOR1
CABLE HS50: POWER SUPPLY STEP. MOTOR 1
78
00335251-02
1
43-25
KABEL HS50: KAMERABELEUCHTUNG PORTAL 2
CABLE HS50: CAMERA ILLUMINATION PORTAL 2
79
00335252-02
1
43-25
KABEL HS50: SPG-VERSORGUNG SCHRITTMOTOR2
CABLE HS50: POWER SUPPLY STEP. MOTOR 2
80
00335253-02
1
43-26
KABEL HS50: KAMERABELEUCHTUNG PORTAL 3
CABLE HS50: CAMERA ILLUMINATION PORTAL 3
81
00335254-02
1
43-26
KABEL HS50: SPG-VERSORGUNG SCHRITTMOTOR3
CABLE HS50: POWER SUPPLY STEP. MOTOR 3
82
00335255-02
1
43-27
KABEL HS50: KAMERABELEUCHTUNG PORTAL 4
CABLE HS50: CAMERA ILLUMINATION PORTAL 4
83
00335256-02
1
43-27
KABEL HS50: SPG-VERSORGUNG SCHRITTMOTOR4
CABLE HS50: POWER SUPPLY STEP. MOTOR 4
61
00335257-02
1
43-10
KABEL HS50: FLASH-LEITUNG STEUEREINSCHUB
CABLE HS50: FLASH-CABLE CONTROL UNIT
110
00335258-02
1
43-19
KABEL HS50: RINGLEITUNG SPG. SEK4 - SEK1
CABLE HS50: RING CIRCUIT VOLT.SEC4-SEC1
111
00335259-02
1
43-19
KABEL HS50: RINGLTG. SICHERHEIT SEK4-1
CABLE HS50: RING CIRCUIT SAFETY SEC4-1
112
00335260-02
1
43-19
KABEL HS50: RINGLTG. SICHERHEIT SEK1-2
CABLE HS50: RING CIRCUIT SAFETY SEC1-2
113
00335261-02
1
43-19
KABEL HS50: RINGLEITUNG SPG. SEK1 - SEK2
CABLE HS50: RING CIRCUIT VOLT.SEC1-SEC2
133
00335262-02
1
43-19
KABEL HS50: SEKTORVERT.1 - LP-EINGABE RE
CABLE HS50: SECT.DIST.1-PCB-INPUT RIGHT
146
00335263-01
4
43-19
ESCHUTZHAUBENSCHALTER SEKTOR 1 BIS 4
SAFETY HOOD SWITCH SECTOR 1 TO 4
43 36 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 43
A
usgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Kabelliste / Cable list
Order
114
00335264-02
1
43-20
KABEL HS50: RINGLTG. SICHERHEIT SEK2-3
CABLE HS50: RING CIRCUIT SAFETY SEC2-3
115
00335265-02
1
43-20
KABEL HS50: RINGLEITUNG SPG. SEK2 - SEK3
CABLE HS50: RING CIRCUIT VOLT.SEC2-SEC3
134
00335266-02
1
43-20
KABEL HS50: SEKTORVERT.2 - LP-AUSGABE LI
CABLE HS50: SECT.DIST.2-PCB-OUTPUT LEFT
116
00335268-02
1
43-21
KABEL HS50: RINGLTG. SICHERHEIT SEK3-4
CABLE HS50: RING CIRCUIT SAFETY SEC3-4
117
00335269-02
1
43-21
KABEL HS50: RINGLEITUNG SPG. SEK3 - SEK4
CABLE HS50: RING CIRCUIT VOLT.SEC3-SEC4
135
00335271-02
1
43-21
KABEL HS50: SEKTORVERT.3 - LP-AUSGABE RE
CABLE HS50: SECT.DIST.3-PCB-OUTPUT RIGHT
136
00335275-02
1
43-22
KABEL HS50: SEKTORVERT.4 - LP-EINGABE LI
CABLE HS50: SECT.DIST.4-PCB-INPUT LEFT
118
00335281-02
1
43-22
KABEL HS50: VERL. SCHLUES./START/STOP/BEZ
CABLE S50: KEY-OP.SW./ON-OFF-BUTT./COMP.
23
00335283-01
1
43-4
EKABEL HS50: SCHLUESSELSCH./START/STOP/BEZ
CABLE HS50: KEY-OP.SW./ON-OFF-B./COMP.C.
119
00335284-02
1
43-22
KABEL HS50: VERL. START/STOP-TASTE
CABLE S50: CONTROL PANEL AIR SUPPLY
24
00335285-01
1
43-4
EKABEL HS50: START/STOP-TASTE PN. SEITE
CABLE HS50: ON-OFF-BUTTON COMPR.AIR SIDE
120
00335286-01
1
43-22
EKABEL HS50: VERLAENGERUNG HAUPTSTOERANZ.
CABLE S50: EXTENSION MAIN ERROR DISPLAY
129
00335288-02
1
43-22
KABEL HS50: PNEUMATIK HAUPTLUFTVENTIL
CABLE HS50: MAIN AIR VALVE
121
00335293-02
1
43-22
KABEL HS50: PIPETTENWECHSLER 1A (SEK4)
CABLE HS50: PIPETTE CHANGER 1A (SEC4)
122
00335294-02
1
43-22
KABEL HS50: PIPETTENWECHSLER 2A (SEK4)
CABLE HS50: PIPETTE CHANGER 2A (SEC4)
123
00335295-02
1
43-22
KABEL HS50: PIPETTENWECHSLER 3A (SEK4)
CABLE HS50: PIPETTE CHANGER 3A (SEC4)
124
00335296-02
1
43-22
KABEL HS50: PIPETTENWECHSLER 4A (SEK4)
CABLE HS50: PIPETTE CHANGER 4A (SEC4)
102
00335306-02
2
43-1
EKABEL HS50: START/STOP/NOTH. LP EIN/AUSG
CABLE HS50: ON-/EMERG.-OFF BUTT.PCB I/O
100
00335307-01
2
43-1
EKABEL HS50: START/STOP/HAUBE LP EIN/AUSG
CABLE HS50: ON-BUTTON/COVER PBC IN/OUTP.
102
00335315-02
1
43-9
KABEL HS50: CAN-BUS1 COM1 - KOPPLUNG2
CABLE HS50: CAN-BUS1 COM1 - COUPLER 2
66
00335316-01
1
43-25
KABEL HS50: CAN-BUS1 KOPPL.2-PORTALV.2
CABLE HS50: CAN-BUS1 COUPLER2-PORTAL D.2
67
00335317-01
1
43-24
KABEL HS50: CAN-BUS1 PORTALVERTEILER 2-1
CABLE HS50: CAN-BUS1 PORTAL DISTRIB. 2-1
