Modular dual conveyor
Page 58 / 60 23.11.2021
Pos. Item no. Description Part marking
INPUT BELT
443 03054347-01 LB TRANSMITTER PLACEM. AREA 1 Spare
444 03054349-01 LB TRANSMITTER INTERMEDIATE
AREA
SPARE PART
445 00370179-03 LIGTH BARRIER TRANSMITTER
PLACEM. BELT 2
Spare
446 00370180-02 LIGHT
BARRIER,TRANSMITTER,OUTPUT
BELT
SPARE PART
447 00370385-01 LASER LIGHT BARRIER
TRANSM.MODUL BB1 CPL
SPARE PART
448 00370386-01 LASER LIGHT BARRIER
TRANSM.MODUL BB2 CPL
SPARE PART
00303099-01 O-RING 2*1,5 NRB 70 B WEAR PART
450 03054446-01 SENSOR PLATE COMPLETE
451 00365765-01 LIMIT SWITCH FOR WIDTH
ADJUSTMENT
Spare Part
452 00316831-01 MICRO SWITCH V4N T7 SERIES SPARE PART
453 00845004-01 HEXAGON SOCKET HEAD CAP
SCREW M2 X 8-A2
454 00367226-02 BOARD HOLDER
455 00359424-01 CONVERSION BOARD TRANSPORT SPARE PART
456 00315647S01 DISTANCE BOLT M3*30 I/A 6KT5,5
ST
457 00364715S01 COMPRESSION SPRING
0,63X5,63X26
SPARE PART
458 00364873-02 SLIDEWAY LINING *
459 00360781-01 CABLE GUIDE
460 00367533-01 COVER, CONVERSION BOARD, SIDE
PANEL
00365724-01 CABLE PCB CONVEYOR SIDE PANEL
B
461 03032834-01 SIDE PANEL C, CPL.
462 03032836-01 SIDE PART BASE UNIT RIGHT
463 00359310-02 TAPE DRIVE SPARE PART
464 00364848-01 SIDE WALL FLANGE 1, CPL.
465 00364849-01 SIDE FLANGE 2, CPL.
466 00366225-01 TRANSMITTER PIECE 2
467 00360781-01 CABLE GUIDE
Modular dual conveyor
Page 59 / 60 23.11.2021
Pos. Item no. Description Part marking
468 00367533-01 COVER, CONVERSION BOARD, SIDE
PANEL
469 00364847S01 TOOTHED BELT SYNCHROFLEX 2.5
T5/1160
WEAR PART
470 00359917S01 TOOTHED BELT SYNCHROFLEX 2.5
T5/1315
WEAR PART
471 03041087S01 TOOTHED BELT SYNCHROFLEX 2.5
T5/1440
WEAR PART
00365725-01 CABLE PCB CONVEYOR SIDE PANEL
C
473 03032835-01 SIDE PANEL D, CPL.
474 03032837-01 SIDE PART BASE UNIT LEFT
475 00366224-01 TRANSMITTER PIECE 1 SPARE PART
476 00359284-03 DRIVE UNIT SPARE PART
477 00364847S01 TOOTHED BELT SYNCHROFLEX 2.5
T5/1160
WEAR PART
478 00359917S01 TOOTHED BELT SYNCHROFLEX 2.5
T5/1315
WEAR PART
479 03041087S01 TOOTHED BELT SYNCHROFLEX 2.5
T5/1440
WEAR PART
480 00364848-01 SIDE WALL FLANGE 1, CPL.
481 00364849-01 SIDE FLANGE 2, CPL.
482 00360781-01 CABLE GUIDE
483 00367533-01 COVER, CONVERSION BOARD, SIDE
PANEL
484 00365719-01 MOTOR CABLE INPUT BELT
485 00365720-01 MOTOR CABLE PLACEMENT AREA 1 SPARE PART
486 00365761-01 MOTOR CABLE INTERMEDIATE BELT
487 00365762-01 MOTOR CABLE PLACEMENT AREA 2
488 00365763-01 MOTOR CABLE OUTPUT BELT
00365726-01 CABLE PCB CONVEYOR SIDE PANEL
D
490 00369741-01 HEXAGONAL SHAFT SW8, CPL. SPARE PART
491 00368026-01 CABLE FIXING FLAT RIBBON CABLE
492 03006010-01 CLAMP CPL.
493 00365544-04 CONTROL UNIT COMPL. PCB DUAL
CONVEYOR
Spare
00367677-03 SUBRACK: CONVEYOR CONTROL
495 00370397S03 TRANSPORT CONTROL TSP-301
Modular dual conveyor
Page 60 / 60 23.11.2021
Pos. Item no. Description Part marking
496 00370398-03 I/O-BOARD CONVEYOR CONTROL
TSP-301E
00365546-02 ADAPTER CABLE POWER SUPPLY
00369003-01 CABLE SMEMA INTERFACE TRACK 1
UPSTR. ST.
00369004-01 CABLE SMEMA INTERF. TRACK 1
DOWNSTR. ST.
00369005-02 ADAPTER CABLE SMEMA INTERFACE
TRACK 2V
00369006-02 ADAPTER CABLE SMEMA INTERFACE
TRACK 2N
00365547-02 BUS CABLE TO EXTENSION BOARD
00369054-04 GROUNDING WIRE HOUSING
00369053-04 GROUNDING WIRE CONVEYOR
CONTROL
00365548-02 MOTOR CABLE / SENSOR CABLE
TRACK 1
SPARE PART
00365549-02 MOTOR CABLE / SENSOR CABLE
TRACK 2
SPARE PART
00372329-01 CABLE: DISTRIBUTOR PCB
BARCODE READER
SPARE PART
03004138-01 TUBE MAIN DISTRIBUTOR
CONVEYOR
497 00119680S01 MAGNETIC PIN SUPPORT AS OF
HS60/HF
