MACHINE CONTROL CAN BUS 7.46 Technical Reference Manual C hapter Issue 12, Feb 18 N4PL2 N4PL3 N4SK1 Pin No. Signal Pin No. Signal 1N / C 6N / C 2C A N _ L 7C A N _ H 3C A N _ G N D 8N / C 4N / C 9N / C 5N / C 9 Wa y D T …
MACHINE CONTROL
CAN BUS
Chapter Issue 12, Feb 18 Technical Reference Manual 7.45
PL1
PL2
N4PL1
Pin No. Signal Pin No. Signal
1 24V US 3 Fabric Feed Brake
20V 40V
1
4 Way Trident Socket
Pin No. Signal Pin No. Signal
1 Solvent Pump (DUI) 3 Fabric Feed Motor
20V 40V
1
4 Way Trident Socket
Pin No. Signal Pin No. Signal
124V US 40V
2 0V 5 12V
324V SW 60V
4
1
6 Way Trident Connector
(with pins)
MACHINE CONTROL
CAN BUS
7.46 Technical Reference Manual Chapter Issue 12, Feb 18
N4PL2
N4PL3
N4SK1
Pin No. Signal Pin No. Signal
1N/C 6N/C
2CAN_L 7CAN_H
3CAN_GND 8N/C
4N/C 9N/C
5N/C
9 Way D Type Plug
1
6
Pin No. Signal Pin No. Signal
1N/C 6N/C
2CAN_L 7CAN_H
3CAN_GND 8N/C
4N/C 9N/C
5N/C
9 Way D Type Plug
1
6
Pin No. Signal Pin No. Signal
1 +12V 4 +12V
2 Solvent Low Sensor 5 Fabric Low/Fabric Usage
30V 60V
4
1
6 Way Trident Socket
MACHINE CONTROL
CAN BUS
Chapter Issue 12, Feb 18 Technical Reference Manual 7.47
N4SK2
N4SK3
N4SK4
N4SK5
Pin No. Signal Pin No. Signal
1 Cleaner Home Clamps 3 Cleaner Home Clamps
20V 40V
1
4 Way Trident Socket
Pin No. Signal Pin No. Signal
1 Solvent Pump (DUI) 3 Fabric Feed Motor Motor
20V 40V
1
4 Way Trident Socket
Pin No. Signal Pin No. Signal
1 +12V 4 +12V
2 Cleaner Home 5 Cleaner Home
30V 60V
4
1
6 Way Trident Socket
Pin No. Signal Pin No. Signal
1N/C 3N/C
20V 40V
1
4 Way Trident Socket
