MACHINE CONTROL CAN BUS 7.70 Technical Reference Manual C hapter Issue 12, Feb 18 Drive Board/ ProActiv Interface Figure 7-19 ProActiv Drive JP1 - Node Interface to Drive Board (50 W ay Ribbon) N18SK14 N18SK13 Pin No. Si…
MACHINE CONTROL
CAN BUS
Chapter Issue 12, Feb 18 Technical Reference Manual 7.69
NPL05
N18PL08
N18SK10
Pin No.SignalPin No.Signal
1N/C 4N/C
2 DIG IN 2 5 N/C
30V 6N/C
Pin No.SignalPin No.Signal
1 DIG OUT 0 3 DIG OUT 1
20V 40V
Pin No.SignalPin No.Signal
1 USB SUPPLY 3 USB DATA +VE
2 USB DATA -VE 4 USB GROUND
4
1
6 Way Trident Connector
(with pins)
4
1
6 Way Trident Connector
(with pins)
1
4
USB Type B Socket
MACHINE CONTROL
CAN BUS
7.70 Technical Reference Manual Chapter Issue 12, Feb 18
Drive Board/
ProActiv Interface
Figure 7-19 ProActiv Drive
JP1 - Node Interface to Drive Board (50 Way Ribbon)
N18SK14
N18SK13
Pin No. Signal Pin No. Signal
1SQY +F 6SQY -R
2SQY -F 7N/C
3PE 8N/C
4PE 9N/C
5SQY +R
Pin No. Signal Pin No. Signal
1+ 42V SW 40V
20V 5N/C
3+ 24V US 6N/C
N18SK14
NOTE 250V RMS
JP1
N18SK13
9 Trident Power PlugWay
1
9 Way D Type Socket
1
6
MACHINE CONTROL
SIGNALS BREAKOUT CONNECTOR
Chapter Issue 12, Feb 18 Technical Reference Manual 7.71
SIGNALS BREAKOUT CONNECTOR
Mounted on the rear frame of the machine, the signals breakout connectors are
extensions of some of the I/Os from the NextMove Interface card. The Spare
Output and Inputs are available for machine options.
Pin 1
Pin 2
Pin 3
+12V
DIG IN 19
0V
Rail Clash Sensor
(Dual Lane machine only)
Wire 001
Wire 021
Wire 180
12VWire 021
Pin 1
Pin 2
Pin 3
DIG IN 5
0V
Moving Rail Home
Wire 166
Wire 001
Pin 1
Pin 2
Pin 3
+12V
DIG IN 0
0V
Spare Input
Wire 161
Wire 021
Wire 001
Pin 1
Pin 2
Pin 3
+12V
DIG IN 2
0V
Camera Y Home (linear motors)
Wire 021
Wire 163
Wire 001
8SK24 8SK25 8SK26 8SK27
8SK28
Pin 1
Pin 2
DIG OUT 4
0V Return
HTC Enable/Spare Output
Wire 185
Wire 050
Pin 1
Pin 1
