SAFETY FEATURES LOCKOUT 2.18 Technical Reference Manual C hapter Issue 14, Feb 18
SAFETY FEATURES
LOCKOUT
Chapter Issue 14, Feb 18 Technical Reference Manual 2.17
LOCKOUT
Electrical Lockout
WARNING
LETHAL VOLTAGE. DANGEROUS VOLTAGES EXIST IN THIS EQUIPMENT.
ENSURE ALL ELECTRONIC COVERS AND MAIN MACHINE COVERS ARE FITTED
BEFORE OPERATING THIS EQUIPMENT.
Electrical lockout of the printer is achieved by applying a padlock, or any other
suitable locking device, through the body and the switch shroud of the mains
isolator switch. This can only be achieved when the mains isolator switch is in
the OFF position.
To electrically lockout the printer, carry out the following procedure:
1. Close down the printer software.
2. Switch the mains isolator to the OFF position.
3. Pull the lockout tab out.
4. Fit a padlock or suitable locking device through the lockout point.
5. This completes the electrical lockout.
Mains Isolator Switch
NOTE
Switch shown in the positionOFF
Lockout Tab
SAFETY FEATURES
LOCKOUT
2.18 Technical Reference Manual Chapter Issue 14, Feb 18
COVERS
PRINTER COVERS
Chapter Issue 11, Jan 17 Technical Reference Manual 3.1
CHAPTER 3 COVERS
PRINTER COVERS
There are five printer cover designs:
• Type 1
• Type 2
• Type 3
• Type 4
• Type 5
