JaNets Instruction Manual 4. User Management
4-8
4.6 Adding a Group
Click the <Add> button on the Group setting screen above, and set the information on a new
group through the wizard.
Figure 4.6-1 Adding a group
Group Name : You have to enter data in this field. You can specify up to 64 half-width
characters as a group name. You can use all characters except for the
following: double-width (two-bytes) characters, “ / ¥ [ ] : (colon) ; (semicolon) |
= , (comma) + * ? < > . (period) and a user ID specified with blank characters
only.
Description : You can specify up to 256 half-width characters. You may enter any characters
here.
Figure 4.6-2 Operational privileges setting screen
* See Section 4.9 “Operational Privileges of Each Application” for details of the operational
privileges.
Select application
whose operational
privileges are to be
set.
Application
selecting area
Operational privileges setting area
Set the operational privileges of each application.
Checked: having the corresponding operational privilege
Not checked: Not having the corresponding operational privilege
JaNets Instruction Manual 4. User Management
4-9
An application to be displayed in the launcher can be selected by display setting.
The applications to be set are displayed in the launcher for each of the group setting in which the
user belongs and the user setting.
Figure 4.6-3 Display setting screen
4.7 Deleting a Group
You can delete a group by selecting the <Delete> button on the Group setting screen. However,
if there is any user in the group to be deleted, the system will not delete the group.
* The application is displayed by
checking off. It is not displayed by
removing a displayed check-off mark.
JaNets Instruction Manual 4. User Management
4-10
4.8 Setting the Properties
Select the <Properties> button on the Group setting screen, and then select a group whose
detailed information is to be displayed.
Figure 4.8-1 Properties setting screen (General)
Figure 4.8-2 Properties setting screen (Operational Privileges)
* If you change the operational privileges of a group of a user who is logging in the system now,
the new operational privileges are enabled after the corresponding application starts up next
time.
Operational privileges setting area
Application
selecting area
Select an
application
whose
operational
privileges are
to be set.
Set the operational privileges of each application.
Checked: having the corresponding operational
privilege
Not checked: Not having the corresponding
operational privilege
Operational privilege:
Displays the screen that allows you to
set the operational privileges of each
application.
