JaNets Instruction Manual
1. Overview
1-4
1.1.3 Configuration to be applied when a TraceMonitor option is added to the
system
When you add a Trace Monitor option to your system, you can collect information on each device.
*1: FlexlineCAD is a linking function.
*2: Line Manager is an option of Basic Editor.
*3: The external output function is an option of Line Manager.
*4: Data Manager is an option of Basic Editor.
*5: Output in the JSON format and Off-line Setup are options of the External Output Function.
*6: Device linkage function is an option of Line Manager.
*7: TraceMonitor (for data collection) is an option of Line Manager.
Basic Editor
Line Manager
TraceMonitor
（Data collection）
Shared
TraceMonitor
（Data display）
Shared
User
Management
Shopfloor
Setup
Language
Changer
Component
Database
Maintenance
Snapshot
Tool
Log Control
Tool
Create Data
Program
Editor
Job
Optimizer
Mark
Database
Feeder Set
Database
Machine
Program Relater
Tact
Simulation
Flexline CAD
External output function
Production
Create Data
Program
Downloader
Device linkage
function
Nozzle data
viewer
External output
monitor
External output function
Environment setting
Parts stock
management tool
Output in the
JSON format
Off-line Setup
JaNets Instruction Manual
1. Overview
1-5
Overview of the Functions
The overview of the functions of application programs configuring each JaNets is described below.
1.2.1 Basic Editor
This is basic software of JaNets.
Basic Editor can create and optimize a production program for each machine.
Name
Overview
JaNets Launcher
Launcher that starts up each application program of the JaNets.
Setting of the environment of the entire JaNets.
User Management
Editing operation of the registered information on each user
Setting of the operational privilege of each group.
Shopfloor Setup
Definition of the equipment configuration of the shop floor (such as a
machine, feeder and nozzle)
Setting of the environment such as a unit system.
Language Changer
Dynamic switching of the used language during execution of an application
program
Program Editor
Creation, editing and optimization of the production program (main unit
model)
Snapshot Tool
Collection and compression of an JaNets environment file
Log Control Tool
Setting of the conditions for outputting an operation log.
Analysis of a log with the Log Viewer
1.2.2 Line Manager
Line Manager is an option of Basic Editor.
The functions, which can be used when the Line Manager option is enabled, are provided with a
mark in the description or title in the document.
If the Line Manager option is added, the production program for each line can be created and
optimized in consideration of the line balance and also can perform tact simulation.
When JaNets is connected with the mounter and dispenser by LAN, it can perform online production.
And Nozzle data viewer can be available.
Name
Overview
Shopfloor Setup
Definition of the equipment configuration (floor, line, machine, feeder, nozzle,
etc.) of the shop floor.
Setting of the environment such as a unit system.
Program Editor
Creation, editing and optimization of the production program (*.iss).
Job optimizer
This application performs optimization to reduce feeder setup.
Machine Program
Relater
This application program converts (relates) a production program created
with a machine into the JaNets format when necessary.
Mark Database
Control of BOC mark and area fiducial mark.
Feeder Set Database
Control of feeder set data.
Tact simulation
Simulation of production time.
Flexline CAD
This application program converts CAD data or third party’s data into the
format for JUKI. (option)
Program Downloader
This application program downloads the created production program (*.iss)
to the machine and uploads it from the machine after completion of
production.
Nozzle data viewer
Viewing usage status of ID-equipped nozzles
Line
JaNets Instruction Manual
1. Overview
1-6
If the Line Manager option is added, the EPU and line can be selected for the line configuration in
the shop floor setup.
The operations of some functions may be changed depending on this line configuration setting. In
the explanation of the above, “EPU mode” is described when EPU is selected, and “line mode” is
described when the line is selected.
Only when the Line Manager option is added, it is described or is indicated for the
chapter No. in the explanation that is effective in the selected line mode.
1.2.3 External output function
This function is an option of Line Manager.
If the external output function is added, the machine information obtained from JaNets can be
output externally.
For details, refer to “Instruction Manual for the external output function.”
1.2.4 Data Manager
Data Manager is an option of Basic Editor. The descriptions and titles of functions you can use when
this Data Manager option is enabled are marked in this Manual.
Only in case of Basic Editor, its functions that can be used when a Data Manager option is installed
are different from those when two options, Line Manager are Data Mange are installed.
Basic Editor + Data Manager
Machine data and Component data can be shared with JaNets systems connected to Data
Manager.
Name
Overview
Shopfloor Setup
Sharing of definition data of the Shopfloor equipment
configuration (such as a machine, a feeder and a nozzle) and
environmental setup information such as a unit system
Component Database
Sharing of Component data
Basic Editor + LineManager + Data Manager
Floor, line and machine data, component, mark, feeder-setup data, production program and
reservation file data can be shared between JaNets systems connected to Data Manager.
Name
Overview
Shopfloor Setup
Sharing of definition data of the Shopfloor equipment
configuration (such as a floor, a line, a machine, a feeder and a
nozzle) and environmental setup information such as a unit
system
Program Explorer
Sharing of production programs and reservation files
Control of a master file of production programs
Component Database
Sharing of Component data
Mark Database
Sharing of BOC mark and area fiducial mark data
Feeder Set Database
Sharing of feeder set data
Line
Data Manager
