JaNets Instruction Manual 13. Program Downloader
13-17
13.9.3.2 Uploading data for teaching
When you select [Production] – [Upload data for teaching], the “Upload data for teaching”
confirmation dialog box appears on the screen.
Figure 13.9-4 “Upload data for teaching” dialog box
When you select the <OK> button to close the dialog box above, the system starts teaching.
After the system finishes uploading data, it operates according to your choice of the menu item
“Ending Mode.”
Table 13.9-1 Ending Mode
Ending Mode
Description
Terminate in the state
that teaching is
completed.
Uploads a production program for teaching from a machine to be specified to upload
data and takes over the component pick-up coordinates. If at least one machine
fails to upload data, the system causes all machines to abort an uploading operation.
Cancel this production
Cancels the downloading state of a production program for teaching without uploading
the production program and taking over the component pick-up coordinates.
JaNets Instruction Manual 13. Program Downloader
13-18
13.9.4 Starting/finishing production
13.9.4.1 Download
After specifying a production program, download the production program to each machine
assigned to the specified production line. When you select the “Production” command from the
menu bar, and then the “Download” command from the “Production” menu (or click the “Download”
tool button of the toolbar), the confirmation dialog box for downloading appears on the screen.
When you select the “Yes” button, the dialog box closes and the system starts downloading the
production program.
When a production program is downloaded to each machine normally, the downloading conditions
are displayed on the Line Monitor.
* When the license of the External Output function is effective and the check box “Check to see if
the External Output Monitor has started up” is checked off of the menu item “Set confirmation
message” described in Section 13.14.2.3 “Confirmation message setting,” the system checks
to see if the External Output Monitor has started up after closing the confirmation dialog box.
If the External Output Monitor does not start up yet, the confirmation dialog box for downloading
the production program appears on the screen again. To download the production program,
click the <Yes> button. The dialog box closes, and then the system starts downloading the
program.
Figure 13.9-5 Data displayed on the Line Monitor after production programs are downloaded
13.9.4.2 Upload
When the system finishes producing PWBs according to the downloaded production program, it
automatically starts uploading the production program.
* When you do not check the check box “Automatically upload finished programs” of the “Upload”
menu item on the “Set Environments” screen described in the Section 13.14.2.1, no production
program is uploaded.
Press the “Start” button of each
machine to start producing PWBs.
JaNets Instruction Manual 13. Program Downloader
13-19
13.9.4.3 Notes on production with a production line including an inspection
machine/printer
If there is not any information on a program to be used for production with an inspection
machine/printer in a production program to be downloaded, the system does not download any
data to the corresponding machine. Automatic uploading is performed according to the
requirements shown in Table 13.9-2.
Table 13.9-2 Requirements for automatic uploading
if there is no program information to be used with a machine
Loading mode
Whether automatic uploading can be performed or not
Line
The system uploads data unless the last machine of a production line is an inspection machine.
When the last machine is an inspection machine, the system uploads data only if program
information to be used for production with the machine is located in a production program.
If there is no information, the system does not upload data. Open the “Terminate Production”
dialog box described in Section “Forced termination of production” (13.9.5), and then check the
“Change status to over” radio button and the “Download next production program reserved”
check box, and upload data.
Machine
The system does not upload data. Open the “Machine Direct Download/Upload” dialog box as
described in Section “Machine individual download/upload” (13.9.6), and then upload data in the
production completed state.
