JaNets Instruction Manual 13. Program Downloader
13-63
Output destination sub-folder
In the output destination sub-folder, set whether a sub-folder is created or not in the above
production line name folder.
Table 13.14-5 Folder setting
Output destination
sub-folder
Contents
Not Create
Does not a sub-folder.
Outputs a CSV file to a production line name folder.
Program Name
Creates the sub-folder of a production program name to output a CSV file to it.
Machine Name
Creates the sub-folder of the name of a machine which produces to output a CSV file to it.
* The machine name is the name set in the shop floor setup.
Date
Creates the sub-folder of start-of-production time to output a CSV file to it.
Figure 13.14-8 Sub-folder image (for machine name)
Output Timing
Make settings for the timing which outputs the production management information to a file.
Table 13.14-6 Output timing setting
Output timing
Contents
Only at the time of the
production completion
of the reserved PWBs
Outputs the production management information when production of the number of
sheets set up in the Section 13-8-2 and 13-8-7 is completed.
Per PWB
Outputs the production management information whenever production of one PWB is
completed.
Time
Outputs the production management information whenever a designated time (unit:
minute) passes.
This can be specified in the unit of one minute in the range of 1 minutes to 60 minutes.
The default time is five minutes.
Overwrite of an output file
Perform the setting related to file overwrite to output the production control information to a
file.
Table 13.14-7 File output setting
Overwrite of an output file
Contents
The existing file is
overwritten.
Overwrites the file when an output file exists in a save destination.
Therefore, only the production management information output at the end is saved.
No overwrite (output with a
different name)
Newly aerates a file and saves it every time when a file is output.
If you set a folder configuration for a "machine
name," the folder of the same name as a machine
name will be created.
JaNets Instruction Manual 13. Program Downloader
13-64
Output of Program Information
Specify whether to include information on a program being used for production in the CSV file.
Table 13.14-8 Setting of the “Output of Program Information”
Output of Program
Information
Contents
Yes
Includes program information in the production control information CSV file.
See Section 13.5.1 “CSV file output format” for the detailed file format.
No
Does not include any program information in the production control information CSV file.
“No” is selected by default.
13.14.2.6 Special for the model
Set the functions that are owned especially by each model.
<RX-7/RX-7R>
Common to the front and rear lanes:
When “Same for Both lanes” is checked off, the common production program to the front lane
and rear lane is downloaded. Otherwise, the production program is downloaded for the front
lane only.
* The production program is downloaded for front lane only even if a check mark is put into
“Common in Front/ Back Lanes” in case of RX-7 and RX-7R dual lane machine are set to
single lane setting or RX-7R single machine at shop floor set-up.
Figure 13.14-9 Environment – Special to the model
Select “Machine Options”
JaNets Instruction Manual 13. Program Downloader
13-65
13.14.2.7 Management of a production program
Make settings of a production program.
Figure 13.14-10 [Set Environments]- [Management of a production program]
Load
Make settings of loading of a production program.
Table 13.14-9 Setting of “Load”
Setting of “Load”
Description
Use a serial code to load
a production program
When you enable this setting, you can select a production program by reading a
serial code.
See Section 13.10 “Managing a Production Program with a Seral Code” for
details.
Search
Specify which production program and serial code association information is to be searched
for. When you enable the check box “Use a serial code to load a production program,” you
can make this setting.
Table 13.14-10 Setting of the menu item “Search”
What to search for
Description
Local
The system searches for association information saved locally.
Data Manager The system searches through the Data Manager server. If the Data Manager
connection license is invalid or if the Data Manger is set to be unused with the
JaNets launcher, you cannot select this radio button.
Select “Management of
a product”
