JaNets Instruction Manual 13. Program Downloader
13-72
Table 13.16-8 Lane-by-lane information (RX-7 series)
ID code
Label (Title)
Description
Lane-by-lane information
6
Lane
Lane number
ProductNum
Number of produced PWBs
R-ProductNum
Number of finished PWBs in placement at right station
L-ProductNum
Number of finished PWBs in placement at left station
BlockNum
Number of finished circuits in placement
TimePwbIn
PWB loading wait time
TimePwbOut
PWB unloading wait time
R-TotalTactTime
Total tact time at right station
L-TotalTactTime
Total tact time at left station
TotalCycleTime
Total cycle time
TotalThroughput(Line)
Total line tact
TotalThroughput(Machine)
Total machine tact
PickNum
Total number of picks
PlaceNum
Number of placed components
PickErrorNum
Number of pick-up errors
TombPickErrorNum
Number of tombstone errors
RecErrorNum
Frequency of recognition errors
CompoHeightError
Number of abnormal-height components
ScrapRate
Number of forcible scraps
PickRate
Pickup rate
PlaceRate
Placement rate
LossFactor
Component loss factor
NoCompoStopNum
Frequency of non-component stop
MarkErrorStopNum
Number of BOC mark recognition errors
PwbErrorStopNum
Frequency of PWB transport error stop
PickErrorStopNum
Frequency of pickup error stop
CompoRecErrorNum
Frequency of component recognition error stop
FeederTroubleStopNum
Frequency of feeder trouble stop
MaintenanceTroubleStopNum
Number of maintenance warning stops
MachieTroubleStopNum
Frequency of machine trouble stop
BadMarkNum
Number of detected bad marks
AdhesionNum
Number of component carry-back times
StockOutNum
Number of component drops
R-TactTime
Right-station tact time
L-TactTime
Left-station tact time
CycleTime
Cycle time
Throughput(Line)
Line tact
Throughput(Machine)
Machine tact
JaNets Instruction Manual 13. Program Downloader
13-73
Table 13.16-9 Supply position information (RX-7 series)
ID code
Label (Title)
Description
Supply position information
7
Pos
Supply position
CompoName
Component name
PickNum
Total number of component picks
PlaceNum
Number of placed components
PickErrorNum
Number of pick-up errors
TombPickErrorNum
Number of tombstone errors
RecErro
ｒ
Num
Frequency of recognition errors
CompoHeightError
Number of abnormal-height components
ScrapRate
Number of forcible scraps
PickRate
Pickup rate
PlaceRate
Placement rate
LossFactor
Component loss factor
NoCompoNum
Frequency of non-component
AdhesionNum
Number of component carry-back times
StockOutNum
Number of component drops
Table 13.16-10 Head information (RX-7 series)
ID code
Label (Title)
Description
Head information
8
Nozzle Nozzle index
PickNum Total number of component picks
PlaceNum Number of placed components
PickErrorNum Number of pick-up errors
TombPickErrorNum Number of tombstone errors
RecErrorNum Frequency of recognition errors
CompoHeightError Number of abnormal-height components
ScrapRate Number of forcible scraps
PickRate Pickup rate
PlaceRate Placement rate
LossFactor Component loss factor
AdhesionNum Number of component carry-back times
StockOutNum Number of component drops
JaNets Instruction Manual 13. Program Downloader
13-74
Table 13.16-11 Nozzle information (RX-7 series)
ID code
Label (Title)
Description
Nozzle information
9
NozzleID
Nozzle ID
NozzleNumber
Serial number
NozzleName
Nozzle name
PickNum
Number of picked up components
PlaceNum
Number of placed components
PickErrorNum
Frequency of non-pickup errors
TombPickErrorNum
Frequency of tombstone pick-up errors
RecErrorNum
Frequency of recognition errors
CompoHeightError
Number of abnormal-height components
ScrapRate
Number of forcible scraps
PickRate
Pickup rate
PlaceRate
Placement rate
LossFactor
Loss rate
AdhesionNum
Number of detected adhesion
StockOutNum
Number of detected stockout
Table 13.16-12 Production control information (RX-6 dual transport machine)
ID code
Label (Title)
Description
Production control information
10
ProductNum Number of produced boards
ProductCir Number of produced circuits
PickNum Total number of picked components
PlaceNum Total number of placed components
BadMarkNum Number of detected bad marks
BocMarkNum Number of BOC mark recognition errors
AreaMark Number of area mark recognition errors
NoCompo Number of stops due to “No components”
TimeRun Total production execution time
TimePwbIn PWB carry-in wait time
TimePwbOut PWB carry-out wait time
TimePwb PWB transport wait time
TimeRepair Maintenance time
TimeTrouble Trouble stop time
TimeSomeStop Momentary stop time
TimeNoCompo Stop time due to “No components”
PwbWaitDualTime PWB wait time
LaneId Transport lane (0: front. 1: rear)
