JaNets Instruction Manual 13. Program Downloader
13-73
Table 13.16-9 Supply position information (RX-7 series)
ID code
Label (Title)
Description
Supply position information
7
Pos
Supply position
CompoName
Component name
PickNum
Total number of component picks
PlaceNum
Number of placed components
PickErrorNum
Number of pick-up errors
TombPickErrorNum
Number of tombstone errors
RecErro
ｒ
Num
Frequency of recognition errors
CompoHeightError
Number of abnormal-height components
ScrapRate
Number of forcible scraps
PickRate
Pickup rate
PlaceRate
Placement rate
LossFactor
Component loss factor
NoCompoNum
Frequency of non-component
AdhesionNum
Number of component carry-back times
StockOutNum
Number of component drops
Table 13.16-10 Head information (RX-7 series)
ID code
Label (Title)
Description
Head information
8
Nozzle Nozzle index
PickNum Total number of component picks
PlaceNum Number of placed components
PickErrorNum Number of pick-up errors
TombPickErrorNum Number of tombstone errors
RecErrorNum Frequency of recognition errors
CompoHeightError Number of abnormal-height components
ScrapRate Number of forcible scraps
PickRate Pickup rate
PlaceRate Placement rate
LossFactor Component loss factor
AdhesionNum Number of component carry-back times
StockOutNum Number of component drops
JaNets Instruction Manual 13. Program Downloader
13-74
Table 13.16-11 Nozzle information (RX-7 series)
ID code
Label (Title)
Description
Nozzle information
9
NozzleID
Nozzle ID
NozzleNumber
Serial number
NozzleName
Nozzle name
PickNum
Number of picked up components
PlaceNum
Number of placed components
PickErrorNum
Frequency of non-pickup errors
TombPickErrorNum
Frequency of tombstone pick-up errors
RecErrorNum
Frequency of recognition errors
CompoHeightError
Number of abnormal-height components
ScrapRate
Number of forcible scraps
PickRate
Pickup rate
PlaceRate
Placement rate
LossFactor
Loss rate
AdhesionNum
Number of detected adhesion
StockOutNum
Number of detected stockout
Table 13.16-12 Production control information (RX-6 dual transport machine)
ID code
Label (Title)
Description
Production control information
10
ProductNum Number of produced boards
ProductCir Number of produced circuits
PickNum Total number of picked components
PlaceNum Total number of placed components
BadMarkNum Number of detected bad marks
BocMarkNum Number of BOC mark recognition errors
AreaMark Number of area mark recognition errors
NoCompo Number of stops due to “No components”
TimeRun Total production execution time
TimePwbIn PWB carry-in wait time
TimePwbOut PWB carry-out wait time
TimePwb PWB transport wait time
TimeRepair Maintenance time
TimeTrouble Trouble stop time
TimeSomeStop Momentary stop time
TimeNoCompo Stop time due to “No components”
PwbWaitDualTime PWB wait time
LaneId Transport lane (0: front. 1: rear)
JaNets Instruction Manual 13. Program Downloader
13-75
Table 13.16-13 Dispenser production control information (KD-2077)
ID code
Label (Title)
Description
Dispenser production control information
11
StationId
Station ID
ProductNum
Number of produced boards
ProductCir
Number of produced circuits
TimeRun
Total production execution time
TimePwb
PWB transport wait time
TimePwbIn
PWB carry-in wait time
TimePwbOut
PWB carry-out wait time
TimeSomeStop
Momentary stop time
TimeRepair
Maintenance time
TimeTrouble
Trouble stop time
TimeNoAdhesive
Stop time due to a shortage of adhesive
TimeDown
Sum total of production stop times
PlaceNum
Number of placed PWBs after completion of application
BadMarkNum
Number of detected bad marks
BocMarkNum
Number of BOC mark recognition errors
NoAdhesive
Number of stop times due to a shortage of adhesive
Table 13.16-14 Dispenser head information (KD-2077)
ID code
Label (Title)
Description
Dispenser head information
12
StationId Station ID
ProductLinkNum Dispenser production control information link No.
HeadNo Head unit
HeadId Head ID
ShotNum Number of application times
CheckNum Number of execution times
MinLimitError Application diameter lower limit error for each PWB
MaxLimitError Application diameter upper limit error for each PWB
AveMinError Average application diameter lower limit error
AveMaxError Average application diameter upper limit error
DiamMinError Directly measured diameter lower limit error
DiamMaxError Directly measured diameter upper limit error
Imbalance Application unbalance error
