JaNets Instruction Manual 17 Program Explorer
17-35
17.5 Database Connection Condition
The Program Explorer obtains information from the database (server PC).
Figure 17.5-1 When the system is obtaining data from the database
* While the system is obtaining data from the database (server PC), you cannot operate the
Program Explorer at all.
17.6 Warning messages
<Warning conditions and the contents of warning messages>
Warning conditions
Contents of warning messages
When 100 or more files are operated at once
"W1405104 Because the number of selected data is
large, it takes much time to process it. May the
processing be continued?"
When free space on the database is less than
20MB after file registration and/or check-in are
executed.
“W1405103 Free space on the database server is
insufficient.”
17.7 Error Messages
<Error condition and its corresponding error message>
Error condition Error message
The system could not access the database (for
example, it is not connected to the database).
“Accessing the network caused an error. The
process will be aborted.” *1
An exception occurred in the database. “E1405004 Failed to access the database.”
When file registration and/or check-in fails
because of the shortage of free space in the
database
"E1405105 Free space on the database server is
insufficient.The process will be aborted."
*1 The system does not display the tree for files when it is not connected to the database yet at
this point because it cannot obtain any data. However, only the root hierarchy is displayed on
the production program tree and on the reservation file tree respectively.
* When a user tries to perform a certain operation for a file or a folder, you cannot perform any
operation for canceling the process for that operation from another location (such as a client
and application).
JaNets Instruction Manual 17 Program Explorer
17-36
17.8 Operation for Controlling a Production Program
This section describes the data condition of the client PC and that of the server PC (database)
when you control a production program with the Program Explorer.
① Registration and deleting
Client PC
Database (server PC)
Registration in the
server PC
Registration
The production program “A”
does not exist in the server PC
(database). This deleting
operation deletes a production
program in the database. (This
application operates a file
registered in the database
( server).)
A production program “A” is
created.
A.iss
(production program)
Delete
A.iss
(production program)
A.iss
(production program)
The same file exists.
JaNets Instruction Manual 17 Program Explorer
17-37
② Check out/Check in/Cancel the Check out/Get data/Operation
Client PC
Database (server PC)
Check out
Production program: editable
Production program: locked
(another user/client cannot edit it.)
A.iss
(production program)
Production program:
editing is finished.
Production program: unlocked
(updated to the data edited with
the client.)
Production program: unlocked
(Not updated to the data edited
with a client.)
Production program: unlocked
Production program: its
copy is created, but is not
reflected in the server PC.
Check in
Cancel check
out
Get data
Production program:
editing is finished.
A production program is
edited with the client PC.
A.iss
(production program)
A.iss
(production program)
A.iss
(production program)
A.iss
(production program)
A.iss
(production program)
A.iss
(production program)
A.iss
(production program)
