CP40 service manual - 第12页
Contents Chapter Title Version Date WA QA CA Remarks 11 Utility P art 00 Nov.04 O O O 11-1 Fault Diagnosis Guide Table O O O 11-2 Fault Diagnosis O O O 11-3-1 Utility S pecification O O O 11-3-2 Input V oltage Check O O …
Contents
Chapter Title Version Date WA QA CA Figure
10 Cover Part 00 Nov.04 O O O
Cover and Bracket Types Change List of
CP-40C(V)(Compared with CP-40L(V))
O O O
CV
Contents
Chapter Title Version Date WA QA CA Remarks
11 Utility Part 00 Nov.04 O O O
11-1 Fault Diagnosis Guide Table O O O
11-2 Fault Diagnosis O O O
11-3-1 Utility Specification O O O
11-3-2 Input Voltage Check O O O
11-3-3 Air Ass'y O O O
11-3-4 Specified Pressure Check O O O
11-3-5 Air Filter & Auto Drainer O O O
11-3-6 CP-40 SPEC O O O
11-3-6-1 Differences from CP-40L/LV O O O
11-3-6-2 SPEC Verification O O O
11-3-7 CP-40 Grease Specification O O O
Contents
Chapter Title Version Date WA QA CA Remarks
12 Performance/Efficiency 00 Nov.04 O O O
12-1 Fault Diagnosis Guide Table O O O
12-2 Fault Diagnosis O O O
12-3-1 Part Pick Up Error O O O
12-3-2 Compliance Ass'y Check O O O
12-3-3 Part Bounce or Place Error O O O
12-3-4 Tray Feeder Pick Up Error O O O
12-3-5 IC Vision Check Error O O O
12-3-6 50M Head3 Setting O O O
50M
12-3-7 Aligner Offset Setting Method O O O
12-3-8 Auto MOUNTING INFORMATION O O O
12-3-9
CP40 Series Integrated Software Setup
Procedures
O O O
