5. Electric Device (CP-40) 5-3. 240V 10A Connected 5-2. 120V 20A Connected Version Date WA QA CA Note 00 Nov04 O O O
5. Electric Device
(CP-40)
5. Voltage Change and Check
5-1. 200V 10A Connected
5-2. 220V 10A Connected
Version Date WA QA CA Note
00 Nov04 O O O
5. Electric Device
(CP-40)
5-3. 240V 10A Connected
5-2. 120V 20A Connected
Version Date WA QA CA Note
00 Nov04 O O O
5. Electric Device
(CP-40)
5-3-2. CP-40 Power Block Diagram
CP and CR Power Block Diagram
Trans Former
CP1 CP2
CR1-1 CR1-2 CR9 CR2-1 CR2-2
AC100V
AC220V
AC24V
AC220V
AC100V
24V
Legend
Version Date WA QA CA Note
00 Nov04 O O O
