7. Rack Ass'y
(CP-40)
<Working Procedures>
1. If Applying
[MVME162PA-252se]
Due to Stopping Production of VME BOARD [MVME162PA-242], Set the Switch and Jumper as
Follows.
2. Parts to be Changed from the Stored Board
(1) Replace ROM of VME Board.
(2) Set Switch.
(3) Set Jumper.
- Remove No.J12 Short Pin.
- Install No.J14 [3&5],[4&6] Short Pin.
(4)
Set the Other Switches or Jumpers to Default.
3. Refer to the above Figure.
Version Date WA QA CA Note
00 Nov04 O O O
8. Fix Camera
(CP-40)
8-1. Trouble Diagnosis Guide Table
Malfunction
Fix Camera QFP Installation State Move Camera
Fix Camera Re-assembly 5
FixCameraPowerCable
Replacement
3
Fix Camera Connector Reconnection 2
Fix Camera Light Board Volume
Replacement
4
Fix Camera Light Board Cable
Reconnection
1
35mm Camera Check for Use 1
Special Nozzle Check for Use 2
Nozzle O-Ring Replacement 6
Z-Axis Height Adjustment 3
Head Camera Offset Adjustment 4 5
Complacence Ass'y Replacement 7
Fix Camera Focus Readjustment 5
Vision Board Reconnection 1
Move Camera Location Readjustment 3
Move Camera Cable Replacement 4
Camera Position Data Reset 2
Parts
Symptom
Check and Action
# Number Indicates Priority of Check Items.
8. Fix Camera
(CP-40)
NO Symptom Possible Cause Error Code Action
Instructio
n
1
Fix Camera Malfunction
Fix Camera is not Assembled Properly.
Re-assemble Fix Camera.
8-3-3
2 Fix Camera Cable Disconnection
Replace Fix Camera Power Cable.
8-3-1
3 Bad Connection of Connector
Reconnect Fix Camera Connector.
8-3-1
4 Bad VR for Light-Adjustment
Replace Fix Camera Light Board Volume.
8-3-1
5 BadConnectionofLightBoardCable
Reconnect Fix Camera Light Board
Cable.
8-3-1
6
Bad Installation State of
QFP
Bad Specification of Camera
Use 35mm Camera.
7 Nozzle Specification Modification
Use Special Nozzle.
8 Bad Nozzle O-Ring
Replace Nozzle O-Ring.
9 Bad Z-Axis Height of Head
Adjust Z-Axis Height.
10 Wrong Camera Position
Adjust Head Camera Offset.
11
Bad Complacence Ass'y Replace Complacence Ass'y .
12
Wrong Fix Camera Focus Readjust Fix Camera Focus.
8-3-3
13
Move Camera Malfunction
Bad Connection of Vision Board Reconnect Vision Board.
7-3-1
14
Wrong Move Camera Position Readjust Move Camera Position.
15
Move Camera Cable Disconnection Replace Move Camera Cable.
8-3-1
16
Bad Camera Position Data Reset Camera Position Data.
8-3-2
17
18
8-2. Trouble Diagnosis
