8. Fix Camera (CP-40) (Display1) (Display3) (Display2) (Display5) (Display4) Version Date WA QA CA Note 00 Nov04 O O O
8. Fix Camera
(CP-40)
After Setting as the above, Select OK to Finish.
In System Setup Window, Selecting =>
Calibration
makes
Auto Calibration Window Displayed
In Auto Calibration Window, Set Camera to Fix Camera1
(Display1).
In Fix Camera Calibration, Select
FIX CAM(Display2).
If Selecting
FIX CAM
, the below Figure is Displayed
(Display3).
If Clicking Next Twice in the below Figure, Fix Camera Calibration is Automatically Executed
(Display4).
Version Date WA QA CA Note
00 Nov04 O O O
8. Fix Camera
(CP-40)
(Display1)
(Display3)
(Display2)
(Display5)
(Display4)
Version Date WA QA CA Note
00 Nov04 O O O
8. Fix Camera
(CP-40)
Version Date WA QA CA Note
00 Nov04 O O O
If Fix Camera Calibration is Completed Automatically, Measured Data is Displayed.
=> If the Measured Data Specifies SPEC, Select OK.
At this time, Select Head Offset of Head Offset Calibration and Perform Head Offset Calibration Simultaneously
(Display5).
If Selecting Head Offset and then Clicking Next Nine Times, Head Offset is Measured Automatically
.
=> HEAD OFFSET is X,Y SPEC : +-0.05.
<< FIX CAMERA CALIBRATION DATA by Specification >>
XYR
20mm UPWARD VISION 40+-1
um
/PIXEL 40.5+-1
um
/PIXEL +-0.15 DEGREE
35mm UPWARD VISION 70+-1
um
/PIXEL 71+-1
um
/PIXEL +-0.15 DEGREE
45mm UPWARD VISION 90+-1
um
/PIXEL 91+-1
um
/PIXEL +-0.15 DEGREE
