MODULE ERROR CODE Symptom and Cause ACTION Service Manual $509, 1, "[Stick Feeder] ", "Unit=%d Stick=%d " Stick link No. is incorrect. Stick Link No. shall be 1~10. $510, 1, "[Stick Feeder] "…
MODULE
ERROR
CODE
Symptom and Cause ACTION
Service
Manual
$402, 1,
"[Tape Feeder] ", "Station=%d Feeder=%d "
Feeder No. is incorrect.
Feeder No. shall be 1~76(for Tray Feeder) or 1~52(Stick Feeder). 4-3-5
$403, 1
"[Tape Feeder] ", "Station=%d Feeder=%d "
Feeder type is incorrect.
Use the suitable Feeder. 4-3-2
$406, 0,
"[Tape Feeder] ", "Station=%d Feeder=%d "
Z position is incorrect.
Z position shall be -10~15mm.
$407, 0,
"[Tape Feeder] ", "Station=%d Feeder=%d "
R value of angle is incorrect.
Angle R value shall be degree of -360~+360.
$408, 1,
"[Tape Feeder] ", "Station=%d Feeder=%d "
Link station No. of Feeder is incorrect.
Link Station No. of Feeder shall be 1~2.
$409, 1,
"[Tape Feeder] ", "Station=%d Feeder=%d "
Link No. of Feeder is incorrect.
Link No. of Feeder shall be 1 ~ 52.
$410, 1,
"[Tape Feeder] ", "Station=%d Feeder=%d "
Linked to itselt or forming the loop is not allowable.
Link to other Feeder No.
$411, 0,
"[Tape Feeder] ", "Station=%d Feeder=%d "
Linked to other parts.
Link to Feeder using the same part.
$412, 1,
"[Tape Feeder] ", "Station=%d Feeder=%d "
Dump Box is incorrect.
Use the suitable Dump Box.
$1400,
$1404, 0,
$1405, 0,
"[Tape Feeder] ", "Station=%d Feeder=%d Head=%d "
Y value is incorrect.
Y value shall be in system area.
PMT Error
Code Table
$500,
$501, 1,
$502, 1,
"[Stick Feeder] ", "Unit=%d Stick=%d "
Stick No. is incorrect.
Stick No. shall be 1~10.
$506, 0,
"[Stick Feeder] ", "Unit=%d Stick=%d "
Pickup height Z of Stick is incorrect.
Z position shall be -10~15mm.
$507, 0,
"[Stick Feeder] ", "Unit=%d Stick=%d "
R value of angle is incorrect.
Angle R value shall be degree of -360~+360.
$508, 1,
"[Stick Feeder] ", "Unit=%d Stick=%d "
Stick Unit link No. is incorrect.
Stick Unit Link No. shall be 1~10.
X value shall be in system area.
"[Stick Feeder] ", "Unit=%d Stick=%d "
Stick Unit No. is incorrect.
Stick Unit No. shall be 1~10.
"[Tape Feeder] ", "Station=%d Feeder=%d Head=%d "
X value is incorrect.
- 40 -
MODULE
ERROR
CODE
Symptom and Cause ACTION
Service
Manual
$509, 1,
"[Stick Feeder] ", "Unit=%d Stick=%d "
Stick link No. is incorrect.
Stick Link No. shall be 1~10.
$510, 1,
"[Stick Feeder] ", "Unit=%d Stick=%d "
Linked to itselt or forming the loop is not allowable.
Link to other Stick No.
$511, 0,
"[Stick Feeder] ", "Unit=%d Stick=%d "
Linked to other parts.
Link to Stick using same part.
$512, 1,
"[Stick Feeder] ", "Unit=%d Stick=%d "
Dump Box is incorrect.
Use the suitable Dump Box.
$514, 0,
"[Stick Feeder] ", "Unit=%d Stick=%d "
Z value of Stick Feeder Dump position is incorrect.
Z value of Dump Box shall be -10~15mm.
$1500,
$1504, 0,
$1505, 0,
"[Stick Feeder]", "Unit=%d Stick=%d Head=%d"
Y value of Stick Feeder Pickup position is incorrect.
Stick Feeder Pickup position Y value shall be in system area.
$1513, 0,
"[Stick Feeder]", "Unit=%d Stick=%d Head=%d"
Y value of Stick Feeder dump position is incorrect.
Dump position Y value shall be in system area.
$600,
$601, 1,
$602, 1,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Tray No. is incorrect.
Tray No. shall be 1~20.
$604, 1,
"[Tray Feeder] ", "Unit=%d Tray=%d "
No. of Tray X is incorrect.
No. of Tray X usable shall be 1~99.
$605, 1,
"[Tray Feeder] ", "Unit=%d Tray=%d "
No. of Tray Y is incorrect.
No. of Tray Y usable shall be 1~99.
$606, 0,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Tray X length is incorrect.
Tray X length shall be 10~800mm.
$607, 0,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Tray Y length is incorrect.
Tray Y length 10~800mm.
$610, 0,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Z value of Tray Pickup height is incorrect.
Z value shall be -10~15mm.
$611, 0,
"[Tray Feeder] ", "Unit=%d Tray=%d "
R value of Tray Pickup angle is incorrect.
Angle R value shall be degree of -360~+360.
"[Stick Feeder]", "Unit=%d Stick=%d Head=%d"
X value of Stick Feeder Pickup position is incorrect.
Stick Feeder Pickup position X value shall be in system area.
"[Tray Feeder] ", "Unit=%d Tray=%d "
Tray Unit is incorrect.
Tray Unit No. shall be 1~3.
- 41 -
MODULE
ERROR
CODE
Symptom and Cause ACTION
Service
Manual
$612, 1,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Tray Unit link No. is incorrect.
Tray Unit Link No. shall be 1~3.
$613, 1,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Tray link No. is incorrect.
Tray Link No. shall be 1~20.
$614, 1,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Linked to itselt or forming the loop is not allowable.
Link to other Tray No.
$615, 0,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Linked to other parts.
Link to Tray using same part.
$616, 1,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Tray Dump Box is incorrect.
Use the suitable Dump Box.
$617, 0,
"[Tray Feeder] ", "Unit=%d Tray=%d "
Height Z value of Tray Dump position is incorrect.
Height Z value of Tray Dump position shall be -10~15mm.
PMT Error
Code Table
$1600,
$1608, 0,
$1609, 0,
"[Tray Feeder]" , "Unit=%d Tray=%d Head=%d "
Y value of Tray Pickup position is incorrect.
Tray Pickup position Y value shall be in system area.
$700,
$701, 0, 12-3-3
$702, 0,
"[Part] ", "Cycle=%d Head=%d "
Length of part is incorrect.
Length of part shall be 0.1~55mm. 12-3-3
$703, 0,
"[Part] ", "Cycle=%d Head=%d "
Height of part is incorrect.
Height of part shall be 0.1~11mm. 12-3-3
$704, 0,
"[Part] ", "Cycle=%d Head=%d "
Simultaneous pickup offset value is set as larger than part size.
Simultaneous pickup offset value shall be less than size of part.
$705, 0,
"[Part] ", "Cycle=%d Head=%d "
Placement speed level is incorrect.
Select the suitable placement speed level. Placement speed level shall be in Slowest ~ Fastest. 12-3-7
$706, 1,
"[Part] ", "Cycle=%d Head=%d "
No. of retrying for part pickup is incorrect.
Retrying No. of part pickup shall be NONE ~ 4 TIMES.
If NONE, initial placement not to be given at first.
12-3-7
$713, 0,
"[Part] ", "Cycle=%d Head=%d "
Pickup Delay time is incorrect.
Pickup Delay time shall be 0~10000ms.
$714, 0,
"[Part] ", "Cycle=%d Head=%d "
Placement Delay time is incorrect.
Placement Delay time shall be 0~10000ms.
"[Tray Feeder] ", "Unit=%d Tray=%d Head=%d "
X value of Tray Pickup position is incorrect.
Tray Pickup position X value shall be in system area.
"[Part] ", "Cycle=%d Head=%d "
Width of part is incorrect.
Width of part shall be 0.1~55mm.
- 42 -
