MODULE
ERROR
CODE
Symptom and Cause ACTION
Service
Manual
Woori Align
Part
$89C2
Aligner inspected bad y dimension[28] (Head 2)
Y size of part measured by Aligner exceeds the tolerance of size Y registered. This
occurs caused by pickup(tombstome) with part upwards, failure of part pickup,
incorrectly inputted scan size of part, or incorrect align height of part.
12-3-1
12-3-3
12-3-7
12-3-8
$89C3
Aligner inspected bad y dimension[28] (Head 3)
Y size of part measured by Aligner exceeds the tolerance of size Y registered. This
occurs caused by pickup(tombstome) with part upwards, failure of part pickup,
incorrectly inputted scan size of part, or incorrect align height of part.
12-3-1
12-3-3
12-3-7
12-3-8
$89D1
Aligner inspected low x quality[29] (Head 1)
X score of part measured is too low(less than 80 scores). This occurs caused by
slip of part during align.(Rotation of part exceeds degree of 15.)
$89D2
Aligner inspected low x quality[29] (Head 2)
X score of part measured is too low(less than 80 scores). This occurs caused by
slip of part during align.(Rotation of part exceeds degree of 15.)
12-3-1
$89D3
Aligner inspected low x quality[29] (Head 3)
X score of part measured is too low(less than 80 scores). This occurs caused by
slip of part during align.(Rotation of part exceeds degree of 15.)
12-3-3
$89E1
Aligner inspected low y quality[30] (Head 1)
Y score of part measured is too low(less than 80 scores). This occurs caused by
slip of part during align.(Rotation of part exceeds degree of 15.)
12-3-7
$89E2
Aligner inspected low y quality[30] (Head 2)
Y score of part measured is too low(less than 80 scores). This occurs caused by
slip of part during align.(Rotation of part exceeds degree of 15.)
12-3-8
$89E3
Aligner inspected low y quality[30] (Head 3)
Y score of part measured is too low(less than 80 scores). This occurs caused by
slip of part during align.(Rotation of part exceeds degree of 15.)
Vision Part $AA00
Vision Fiducial Data Ready Error
Occurs when data not inputted exists in Fiducial Data exists or error occurs.
Check that Fiducial Data in use is inputted correctly, and if not inputted, input the data correctly.
$AA01
Vision Fiducial Acquisition Error
Occurs when grab is not possible when grabbing the Vision Fiducial image.
Check the Vision H/W Type. (Cognex, SSA)
Check the linked condition of Camera Cable.
7-3-1
$AA02
Vision Fiducial Inspection Error
Occurs when it fails to find out Fiducial Mark concerned when Vision Fiducial
Inspection.
Modify correctly the Vision Fiducial Mark Data concerned.
Check that scan size of part registered is identical to that of real part.
Check that Align height of part is proper.
Check that thickness of part registered is identical to that of real part.
Check that tolerance of part is suitable.
Check that picked up condition of part and value of Z-axis inputted are suitable.
Check for feeding condition of Feeder.
Check that scan size of part registered is identical to that of real part.
Check that Align height of part is proper.
Check that thickness of part registered is identical to that of real part.
Check that tolerance of part is suitable.
Check that picked up condition of part and value of Z-axis inputted are suitable.
Check for feeding condition of Feeder.
Check a Nozzle for abnormal conditions.
Adjust an Align speed.
Check for feeding conditions of Feeder.
- 20 -
0. Install & Driver
(CP-40)
Version Date WA QA CA Note
00 Nov04 O O O
Contents
1.Installation & Test Process
2.Work Base and Check
2.1 Request of Installation and Test
2.2 Copy of Contract Document
2.3 Supplying Specification
2.4 Order Entry Sheet
2.5 Sketch Map of Customer
3.Installation & Test Procedure
3.1 Warehousing Procedure
3.2 Equipment Carrying-in and Setting
3.3 Utility Check and Connection(Air,Electricity,Ground)
3.4 Interface Connection
3.5 Equipment Parameter Inspection and Diagnosis
3.6 Safety Device Check and Safety Education
3.7 Warming Up and Start
0. Install & Driver
(CP-40)
Version Date WA QA CA Note
00 Nov04 O O O
1.Installation & Test Process
: Business Vs C/S Vs Production Management(Forwarding)
1) Business : Apply the Related Documents to the Installation Team 3 Days before Installation, Request the Forwarding
Department of Production Management to Apply for an Assembly Insurance Taking out, and Request the
Installation Team for Field Check Depending on the Situation(Request Document for Cooperation and
Related Documents). When Goods Are Transferred to Customers, Check Invoice and Get Signatures in It
from Customers to Complete the Delivery.
2) Forwarding : Notify Weekly and Daily Forwarding Specifications to the Installation Team, and That Day Forwarding
Specifications to the Installer in the Installation Team.
At This Time, Also Notify the Arrival Time of Cars and Specifications of Forwarding Items(Notification
Form of Forwarding Specification).
3) Installation : On the Basis of the Working Details Notified from Business Team, Verify Forwarding Schedule and
Details from Production Management Team. If Required, Make Plans for Safety Management and
Working after Survey Field in Advance.
When Cars Arrive, Compare and Check Receipt and Invoice, Unload and Check Goods, and then
Sign the Receipt.
Confirm the Invoice with Salesperson and Confirm Delivery finally by Let Customers Confirm the
Specifications of Packing List.
After Confirming Delivery, Install Equipment According to Installation Guide, Check Installed State and
Performance of Equipment According to Checkout Sheet, Let Customer Confirm it and Get a Signal.
Store the Signed Checkout Sheet in the Department.
