1. Head Part
(CP-40)
8. Replace Faulty Part Among H1~H3 of Vacuum Generator.
9. In Case of Weak Blow, Adjust it Using Adjust Screw.
H1
H2
H3
Blow Adjust Screw
Block End of Compliance with Finger.
Vacuum Generator
J6707016A
Version Date WA QA CA Note
00 Nov04 O O O
1. Head Part
(CP-40)
1-3-6. WA Cleaning Method
<Installation State and Abandonment Rate>
If WD-40 or Glass Cleansing Fluid is Applied to W/A Aligner Sensor, Diffuser Film and Cover Glass Adhesive are Dissolved. If
User Applies Vinyl Tape to Aligner Window Optionally, Inferiority of Installation State and Abandonment Rate may be Caused.
<WA Cleaning Method>
1. W/A Cleaning
Because W/A Diffuser and Cover Glass are Exposed, They Should be Maintained
Cleanly. Fingerprint or Dust may Influence Installation State.
2. Cycle
1) Diffuser : Once a Month
2) Cover Glass : Every Third Week
3) Besides the Above Cycles, Perform Cleaning When Abandonment Rate of Part
is Increased and Installation State is Bad.
3. Method
1) Diffuser : Using Soft and Dry Cotton Cloth, Wipe Gently in the Same Direction with Pattern..
# Caution : Never Use Solvent such as Water, Alcohol, Glass Cleansing Fluid, etc.
Only Use Dry Cloth.
2) COVER GLASS :
- Using Soft and Dry Cotton Cloth, Wipe Gently in the Same Direction.
-
If Foreign Materials are still Left, Wipe Gently in the Same Direction with Soft and Dry Cotton Cloth Applied with a little Ethyl Alcohol.
- Using Soft and Dry Cotton Cloth, Remove Residual Ethyl Alcohol(Wipe in the Same Direction).
# Caution : (1)
If Wiping in the Both Directions, Foreign Materials may not be Removed or Damage to Glass may be Caused.
(2) Never Use Any Solvent except for Ethyl Alcohol.
Version Date WA QA CA Note
00 Nov04 O
1. Head Part
(CP-40)
1-3-7. CA => WA Change
1. Preparation
Version Date WA QA CA Note
00 Nov04 O O
Material Refer to Attached Materials.
S/W MMI INSTALL CD
Tool Cross and Flat-head Screwdrivers(Large, Small), Digital Tester
<Procedures>
1. Commonly Usable Part
a. Brackets of Cyber Aligner and Woori Aligner on the Front Middle Plate (with Fixing Hole)
(When Used Commonly, WA Bracket is Attached to the Position with CA I/F Board Removed)
b. Power Supply Middle Plate of CA and WA
c. For CP40CV Equipment, CE is not Added Newly and there is no Additional Items to Wago Terminal.
(Only WA is Attached to CA Equipment and CE Part is not Changed.)
2. Part to be Changed (Equipment Modification Method)
a. Remove the Material Shown in 40_CA Removal of this Document from the Equipment(25 Sorts).
(Part to be Excepted from CP40CV Equipment)
b. Prepare to Attach the Material Shown in 40_WA Addition of this Document to Equipment(17 Sorts)
.
(Material to be Added to CP40CV Equipment)
