5-A 基 板搬送部 (L) PCB Tran sport Unit( L) パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N6 10 012 84 6AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - M45 ( KN610012846AA-18-1 )
Ref
No.
Remarks
R
1
Q'ty
4-I
基
板
位置
決
めリフト (L)
Board Positioning Lift(L)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610012845AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
1
51 N210036610AA
BOLT
2
137 N510017376AA
Hexagon socket head cap screw M4X6-10.9 A2J(Trivalent)
BOLT
2
140 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
WASHER
2
155 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
2
159 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
Sensor
1
178 N610026832AA Sensor:-B1032
Sensor
1
179 N610026833AA Sensor:-B1033
Sensor
1
180 N610026834AA Sensor:-B1034
Sensor
1
181 N610026835AA Sensor:-B1035
Sensor
1
183 N610026839AA Sensor:-B1043
M44
--
( KN610012845AA-22-9 )
5-A
基
板搬送部
(L)
PCB Transport Unit(L)
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012846AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M45
( KN610012846AA-18-1 )
Ref
No.
Remarks
R
1
Q'ty
5-A
基
板搬送部
(L)
PCB Transport Unit(L)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610012846AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
FRAME
1
2 N210025923AC
GUIDE
1
3 KXFB01J3A00
GUIDE
1
4 KXFB01J2A00
GUIDE
2
5 N210025925AC
PLATE
2
7 N210025927AC
BRACKET
1
8 N210025928AA
PULLEY
1
9 KXFB02QLB00
PLATE
2
10 N210042506AB
BRACKET
1
11 N210102838AA
BRACKET
1
12 N210102834AA
STRIPPER BOLT
4
15 N610023171AA
PULLEY
5
16 N610116865AA
A
BOLT
8
17 N510017535AA
SSS 003 Hexagon socket button head screw M4X8-10.9 A2S (Trivalent)
SPRING
4
18 N510029955AA 87UR10-30
BELT
2
20 N510022408AA
A
XVT-952 8.5*2290E
RING
2
21 N210088855AA
MOTOR
1
22 KXF0DZDRA00
S
103H7832-0312(DDA)
SCREW
1
23 N510018377AA
Hexagon socket set screw Cup point M5X10-45H A2S (Trivalent)
SCREW
4
24 N510018370AA
Hexagon socket set screw Cup point M4X4-45H A2J (Trivalent)
BOLT
4
25 N510017305AA
Hexagon socket head cap screw M3X10-10.9 A2J (Trivalent)
BOLT
16
28 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
4
29 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
4
30 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
WASHER
2
32 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
10
33 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
12
34 N510020099AA Thick washer for M4
Sensor
1
35 N610026837AA Sensor:-B1037
Sensor
1
36 N610026838AA Sensor:-B1040
COLLAR
8
37 N210053425AB
WASHER
4
41 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
M46
--
( KN610012846AA-18-1 )
